Owner's Manual
Standard: ANS Z83.26-2007 / CSA 2.37-2007 & ANS Z83.26a-2008/CSA 2.37a-2008
Gas-Fired Outdoor Infrared Patio Heaters
Deluxe Outdoor
Patio Heater
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
WARNING
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
WARNING
For Outdoor Use Only.
CAUTION:
Installer: Leave the instruction manual
with the user for future use.
Consumer: Please keep this manual
for future reference.
Model#: PTH40PGM
Read the instructions before use.
This appliance must be installed in
accordance with such regulations as
are in force.
DANGER
Advertisement
Table of Contents
Related Manuals for Napoleon PTH40PGM
Summary of Contents for Napoleon PTH40PGM
- Page 1 CAUTION: Installer: Leave the instruction manual with the user for future use. Consumer: Please keep this manual for future reference. Model#: PTH40PGM Read the instructions before use. This appliance must be installed in accordance with such regulations as Owner’s Manual are in force.
- Page 2 DANGER CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent or home. WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury, death or property damage.
- Page 3 NOTE:PLEASE READ THE FOLLOWING SAFETY RULES WARNING: Any guard or other protective device The installation must conform with local codes removed for servicing the heater must be or, in the absence of local codes, with the replaced prior to operating the heater. National Fuel Gas Code, ANSI Z223.1/NFPA 54, NFPA58 Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and...
- Page 4 NOTE:PLEASE READ THE FOLLOWING SAFETY RULES WARNING: Within a partial enclosure which includes an The pressure regulator and hose assembly sup- overhead cover and three side walls, as long as plied with the appliance must be used, replace- 30 percent or more of the horizontal periphery of ment pressure regulators and hose assemblies the enclosure is permanently open.
- Page 5 NOTE: PLEASE READ THE FOLLOWING SAFETY RULES: Perform a leak test with a soapy solution: 1. To check gas connections. 2. After connecting a new cylinder. 3. Upon re-assembly after disassembly. This heater is designed to operate with a standard 20 Ib propane cylinder with Approved Cylinder Connection.
-
Page 6: Parts List / Exploded View
PARTS LIST / EXPLODED VIEW 1 Center Reflector Cap 5 Reflector Caps 1 Burner Assembly 1 Upper Pole 1 Low Pole 1 Desk surface 1 Gas Hose & Regulator 1 Pole supporting board 15 M6 Nuts 18 6mm Washers 12 M6x10 Screws 3 M6x70 Double Pointed Bolts 5 M4x8 Bolts 3 M4x6 Bolts... - Page 7 ASSEMBLY WARNING: Read ALL assembly instructions Step 1 thoroughly and carefully to insure proper, safe assembly . Step 1 Insert low pole (5) into the pole supporting board (8) , fix it with 6 pcs 5mm washer (17) and 6 pcs M5×8 bolt (16) .
- Page 8 ASSEMBLY Step 3 Step 3 Connect the upper pole (4) on the low pole (5) , fix it with 3pcs M4×6 bolt (14) . Hardware Used M4X6 Bolts Step 4 Step 4 Insert the burner assembly (3) in the upper pole (4) , fix it with 5pcs 4mm washer (15) and 5pcs M4×8 bolt (13) .
- Page 9 ASSEMBLY Step 5 Step 5 Attach the center reflector cap (1) on the top of the four reflector cap (2) by twelve sets of M6x10 screw (11) , 6mm washer (10) and M6 nut (9) . Hardware Used M6 Nut x 12 6mm Washer x 12...
- Page 10 ASSEMBLY Step 7 Step 7 Open the door ,Put cylinder into the big hole on bottom panel and lock the cylinder chain . Tighten...
-
Page 11: Safety Check
SAFETY CHECK Check for leaks Your patio heater has been checked at all factory connections for leakage. To check the connection at the gas hose/regulator /cylinder. 1) Make leakage solution by mixing 1part liquid dish soap and 3 parts water. 2) Spoon or brush several drops (or use squirt bottle) of the solution onto hose connection, regulator &... - Page 12 IGNITER BATTERY INSTALLATION Instruction For Installing Battery Remove igniter button by turning counter-clockwise.Install “AAA” battery with positive terminal up as indicated in Ignition button diagram. Replace igniter button. Control knob Replace Battery Ignition button AAA battery...
-
Page 13: Operation
OPERATION WARNING: DO NOT ATTEMPT TO OPERATE HEATER UNTIL YOU HAVE READ AND UNDERSTAND ALL PRECAUTIONS . FAILURE TO DO SO CAN RESULT IN SERIOUS PERSONAL INJURY, DEATH, OR PROPERTY DAMAGE. WARNING Before turning gas supply ON FOR YOUR SAFETY: If at any time you are unable to Your heater was designed and approved for OUTDOOR light burner and smell gas, wait 5... - Page 14 OPERATION 3) Push and turn the control knob counter-clockwise to the "PILOT" position. Depress the control knob. Push and hold the igniter button until the pilot lights. 4) Once the pilot is lit, release the igniter button and continue to depress the control knob for 30 seconds. 5) After depressing the control knob for 30 seconds, release the control knob and turn it counter-clockwise to the “LOW”...
- Page 15 OPERATION CAUTION : AVOID INHALING FUMES EMITTED FROM THE HEATER'S FIRST USE. SMOKE AND ODOR FROM THE BURNING OF OILS USED IN MANUFACTURING WILL APPEAR. BOTH SMOKE AND ODOR WILL DISSIPATE AFTER APPROXIMATELY 30 MINUTES. THE HEATER SHOULD NOT PRODUCE THICK BLACK SMOKE. NOTE: The burner may be noisy when initially turned on.
-
Page 16: Locating Header For Use
LOCATING HEADER FOR USE CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT, ABOVE, BESIDE OR UNDER THIS HEATER WHILE IN USE, THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE SERIOUSLY DAMAGED. This heater is primarily used for the heating of outdoor patios, decks, spas, pools and open working areas. -
Page 17: Maintenance & Storage
MAINTENANCE/STORAGE CLEANING AND MAINTENANCE : To enjoy years of outstanding performance from your heater make sure you perform the following maintenance activities on a regular basis: Keep exterior surfaces clean. Yellow Tip Primarily Blue Use warm soapy water for cleaning. Never use Flame flammable of corrosive cleaning agents. - Page 18 MAINTENANCE/STORAGE Spiders and insects can nest in the burner or orifices. This dangerous condition can damage heater and render it NOTE: unsafe for use. Clean burner holes by using a heavy-duty Wait until heater is cool before pipe cleaner. Compressed air may help clear away covering.
-
Page 19: Troubleshooting
TROUBLESHOOTING PROBLEM PROBABLE CAUSE SOLUTION Pilot will not light Gas valve may be OFF Turn the gas valve ON Tank fuel empty Refill LP gas tank Air in supply system Purge air from lines Loose connection Check all fittings Debris around pilot Clean dirty area Pilot will not stay on Loose connection... -
Page 20: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY The appliance has been manufactured under the highest standards of quality and workmanship. We warrant to the original consumer purchaser that all aspects of this product will be free of defects in material and workmanship for one (1) year from the date of purchase. A replacement for any defective part will be supplied free of charge for installation by the consumer.
