Owner’s Manual Room Air Conditioner with R-410A Heat Controller, Inc. CONTENTS 1. SAFETY PRECAUTIONS..............2 2. IMPORTANT SAFETY INSTRUCTIONS ..........4 3. NORMAL SOUNDS ................5 4. AIR CONDITIONER FEATURES ............5 5. INSTALLATION INSTRUCTIONS............10 6. CARE AND CLEANING ..............14 7. TROUBLESHOOTING TIPS...............15 ead This Manual Inside you will find many helpful hints on how to use and maintain your air conditioner properly. -
Page 5: Important Safety Instructions
Heat Controller, Inc. Room Air Conditioner with R-410A Owner’s Manual IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS For your safety For your safety WARNING WARNING NOTE NOTE The power supply cord with For some models, the power Do not store or use gasoline or other flammable vapors and liquids in... -
Page 6: Room Air Conditioner
Owner’s Manual Room Air Conditioner with R-410A Heat Controller, Inc. NORMAL SOUNDS WINDOW/WALL TYPE ROOM AIR CONDITIONER AIR CONDITIONER FEATURES High Pitched Chatter High efficiency compressors Normal sounds may have a high pitched chatter Vibration during the cooling cycle. Unit may vibrate and make noise... - Page 8 Owner’s Manual Room Air Conditioner with R-410A Heat Controller, Inc. AIR CONDITIONER FEATURES(CONTINUED) AIR CONDITIONER FEATURES NOTE: TO SELECT THE NOTE: AIR CONDITIONER FEATURES(CONTINUED) TO SELECT THE To choose operating mode, press the Mode OPERATING MODE: To choose operating mode, press the Mode OPERATING MODE: button.
- Page 9 Heat Controller, Inc. Room Air Conditioner with R-410A Owner’s Manual AIR CONDITIONER FEATURES (CONTINUED) AIR CONDITIONER FEATURES AIR CONDITIONER FEATURES(CONTINUED) AIR CONDITIONER FEATURES(CONTINUED) TIMER: AUTO START/ TIMER: AUTO START/ NOTE: TIMER: AUTO START/ STOP FEATURE: STOP FEATURE: NOTE: NOTE: First press the Timer button, the Timer on indicator...
-
Page 10: Additional Things You Should Know
Owner’s Manual Room Air Conditioner with R-410A Heat Controller, Inc. AIR CONDITIONER FEATURES AIR CONDITIONER FEATURES (CONTINUED) DO THIS: Press Check NOTE: Filter button Press the Clean Air button, the ion generator is ener gized and will help to remove pollen and energized impurities from the air, and trap them in the filter. -
Page 11: Installation Instructions
Heat Controller, Inc. Room Air Conditioner with R-410A Owner’s Manual INSTALLATION INSTRUCTIONS NOTE: These instructions describe installation in a typical wood framed window with a wood SLIDE -BY sash, or installation in a metal CASEMENT window. Modification may be necessary when installing in windows made differently than those shown in these instructions. - Page 12 Owner’s Manual Room Air Conditioner with R-410A Heat Controller, Inc. 1. Make sure you have all the necessary parts. Installation kit contents: Platform(1) Support brace(1) Adjustment bolt(1) 1/4” (1) Hex flange nut - 1 / 4 (1) Track seal(1) Side channel seal(1)
- Page 13 Heat Controller, Inc. Room Air Conditioner with R-410A Owner’s Manual Alternate screw location sill depth) (depending on the stool depth) sill. Platform tab Window seal Window track...
- Page 14 Owner’s Manual Room Air Conditioner with R-410A Heat Controller, Inc.
- Page 15 Heat Controller, Inc. Room Air Conditioner with R-410A Owner’s Manual Remove the two front retaining screws from the front frame. 2. Gently pull the front out and lift up to release it from the case. 3. Then release the coupler plugs.
- Page 16 Owner’s Manual Room Air Conditioner with R-410A Heat Controller, Inc. Insert 20. To replace the front First reconnect the coupler plugs, make the Exhaust control positioned through the front in the proper location. Then replace the retaining screws that holds the panel in place.
- Page 17 Heat Controller, Inc. Room Air Conditioner with R-410A Owner’s Manual glass panels must be removed before installation.
- Page 18 Owner’s Manual Room Air Conditioner with R-410A Heat Controller, Inc.
- Page 19 Heat Controller, Inc. Room Air Conditioner with R-410A Owner’s Manual Remove the two front retaining screws from the front frame. 2. Gently pull the front out and lift up to release it from the case. 3. Then release the coupler plugs.
-
Page 20: Care And Cleaning
Owner’s Manual Room Air Conditioner with R-410A Heat Controller, Inc. CARE AND CLEANING CARE AND CLEANING CAUTION WARNING! CAUTION Clean your air conditioner occasionally to keep it looking new. Be sure to unplug the unit Clean your air conditioner occasionally to keep it looking new. Be sure to unplug the unit before cleaning to prevent shock or fire hazards. -
Page 21: Troubleshooting Tips
Heat Controller, Inc. Room Air Conditioner with R-410A Owner’s Manual TROUBLESHOOTING TIPS Before calling for service, review this list. It may save you time and expense. This list includes common occurrences that are not the result of defective workman-ship or materials in this appliance. - Page 22 Owner’s Manual Room Air Conditioner with R-410A Heat Controller, Inc. Problem Solution Unit removing large quantity of moisture from humid room. This is normal during Water dripping excessively humid days. OUTSIDE when unit is cooling. Remote control not located within range. Place remote control within 20 feet & 180 , Remote Sensing radius of the front of the unit.
