Security Notice

Power supply

This Digital Video Recorder uses DC 12 voltage indoor power supply. The voltage of the
power must be verified before using. When the DVR is not in use for a long time, pull out the
plug from the socket and disconnect the power.
Security
This DVR is for indoor use only; in order to avoid the danger of a short circuit or electric
shock, please do not expose the DVR to rain or a moist environment. If any solid or liquid
enters the unit's case, please turn off the power supply immediately, and ask for qualified
technician to check the DVR before restart the unit.
This DVR is precise instrument; do not attempt to repair any component of the DVR by
yourself as this will void your warranty. If your DVR malfunctions in any way, please contact
a dealer in your area or Swann Technical Support directly.
Installation
Please choose appropriate site to install the DVR, to ensure well adequate ventilation around
the DVR to avoid excessive heat. Do not install the DVR near a radiator, ventilating trunk, heat
sources, under direct sunshine, dusty location, or anywhere there is a chance of mechanical
librations or impact.
Features of this DVR
Video input: 8 channels input; video output: 3 output.
Audio input: 4channels input; audio output: 2 output
Four optional levels of image quality: very high, high, normal, low. Record and playback
frame rate changeable for recording.
Compression mode: Modified MJEPG.
Compatible with NTSC and PAL format.
Support alarm recording and time recording.
Multi-function searches: be able to distinguish different alarm records and time records from
ordinary records; be able to search by time, segment or event.
Support various playback modes: pause, several fast forward and backward play modes.
Support zoom, auto function, watermark security
8 alarm inputs and 1 relay alarm output.
Equipped with remote device and PTZ control enable.
Support video loss alarm and motion detection functions.
Triplex operation can play back and search play while it is recording.
Support network view.
Support USB backup and CD-RW backup.
480 frames (NTSC, PAL is 400) per second for view, 120 frames (NTSC, PAL is 100) per
second for recording.
PLEASE NOTE: The information on this Installation Guide was correct at time of printing.
Product features and specifications are subject to change without notification.
8 Channel Digital Video Recorder
1
