PART IDENTIFICATION CHART

Use the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual. The number following the key
number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it has
been preattached. Extra parts may be included.
M6 Washer M8 Split
(112)–8
Washer (103)–4
M8 Washer Wave Washer
(118)–2
(95)–8
M4 x 16mm M6 x 12mm M6 x 50mm M8 x 16mm
Screw (106)–8 Screw (111)–4 Screw (62)–4 Screw (102)–16
M8 x 25mm M10 x 95mm Screw (100)–4
Screw (121)–2
