Password Programming
Programming the Standalone
Switch Module
The system administrator must program a password for each
Remote Module connected to the Standalone Switch Module. To
do this, you should directly connect a Remote Module to the Switch
Module and program the passwords for all the Remote Modules
that will be connected to this Switch Module.
Connecting the Standalone Switch
Module to the Remote Module
Ideally you should initialize and test the Standalone Switch Module
by dialing out to the Public Service Telephone Network (PSTN) and
back into the DEFINITY ECS to establish a connection. Use
specific, customer-supplied call-in numbers and passwords. If this
is not possible, you must use a direct connection.
Follow these steps to directly connect a Remote Module and
telephone to the Standalone Switch Module you want to program:
1. Turn DIP switch 2 on the back of the Remote and Switch
Modules to the ON position. (This allows the connection of the
modules without a telephone line.)
2. Turn DIP switch 3 on the Remote Module to ON. This enables
the password menus.
3. Connect the Switch Module PORT jack to the 2-wire, 16-port
TN2181 circuit pack on the DEFINITY ECS (see the
DEFINITY® Communications System Generic 3, Installation for
Single-Carrier Cabinets manual, document #555-230-894,
comcode #107595423, for complete instructions).
