Direct Vent Gas Appliance
• Important operating and
maintenance instructions
included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or
the gas supplier.
Installation and service of this appliance should be
performed by qualified personnel. Hearth & Home
Technologies suggests NFI certifi ed or factory-trained
professionals, or technicians supervised by an NFI certifi ed
professional.
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand and follow
•
these instructions for safe
installation and operation.
Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07
Owner's Manual
Leave this manual with
•
party responsible for
use and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation and cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
appliance.
• A l e r t c h i l d r e n a n d a d u l t s t o h a z a r d s o f h i g h
temperatures.
High temperatures may ignite clothing or other
fl ammable materials.
• Keep clothing, furniture, draperies and other combustibles
away.
This appliance has been supplied with an integral
barrier to prevent direct contact with the fi xed glass
panel. Do NOT operate the appliance with the barrier
removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts installation must
be performed by a licensed plumber or gas fi tter;
See Table of Contents for location of additional
Commonwealth of Massachusetts requirements.
Installation and service of this appliance should be performed
by qualifi ed personnel. Hearth & Home Technologies suggests
NFI certifi ed or factory-trained professionals, or technicians
supervised by an NFI certifi ed professional.
Installation and Operation
1

Advertisement

Table of Contents
loading

Related Manuals for Heatilator CNXT4236IT

Summary of Contents for Heatilator CNXT4236IT

  • Page 1 Installation and service of this appliance should be performed by qualifi ed personnel. Hearth & Home Technologies suggests NFI certifi ed or factory-trained professionals, or technicians supervised by an NFI certifi ed professional. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 2 DO NOT REMOVE OR COVER THIS LABEL. VENTED GAS FIREPLACE - NOT FOR USE WITH SOLID FUEL. FOYER À GAZ À ÉVACUATION - NE DOIT PAS ÊTRE UTILISÉ AVEC UN COMBUSTIBLE SOLIDE. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 3: Table Of Contents

    D. High Altitude Installations ..... 43 Note: An arrow ( ) found in the text signifi es change in content. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 4: Listing And Code Approvals

    fi bers, plastics, or other material that can ignite and burn, whether fl ame proofed or not, or whether plastered or unplastered shall be considered combustible materials. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 5: Requirements For The Commonwealth Of Massachusetts

    The sign shall read, in print size no See Gas Connection section for additional Common- less than one-half (1/2) inch in size, “GAS VENT wealth of Massachusetts requirements. DIRECTLY BELOW. KEEP CLEAR OF ALL OBSTRUC- TIONS”. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 6: Getting Started

    Safety glasses Level Manometer Voltmeter Tape measure Non-corrosive leak check solution 1/2 - 3/4 in. length, #6 or #8 Self-drilling screws One 1/4 in. female spade connection (for optional fan) Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 7: Framing And Clearances

    52-5/8 59-3/4 1067 1286 1819 1286 1337 1092 1220 1518 CNXT4842 55-1/4 23-1/2 78-1/4 55-1/4 55-1/4 59-3/4 1219 1403 1988 1403 1403 1245 1220 1518 Figure 3.1 Appliance Locations Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 8: Construct The Appliance Chase

    WARNING Fire Risk • Construct chase to all clearance specifi cations in manual. • Locate and install appliance to all clearance specifi cations in manual. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 9: Clearances

    0 in. Rough Rough Rough Rough Opening Opening Opening Opening Model (Width) (Height) (Depth) (DVP Pipe) CNXT4236 38-3/4 23-1/2 1067 CNXT4842 38-3/4 23-1/2 1219 Figure 3.2 Clearances to Combustibles Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 10: Mantel Projections

    Mantel Leg or Perpendicular Wall 1 in. (25 mm) min. to perpendicular wall 3-1/2 in. (89 mm) min. from fireplace opening to perpendicular wall Figure 3.4 Clearances to Perpendicular Wall Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 11: Termination Locations

    Clearances from Cap Surfaces specifi ed. • Do not pack air space with insulation or other materials. Failure to keep insulation or other materials away from vent pipe may cause fi re. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 12 A Gas Termination Wood or Fuel Oil Termination tions supplied with the decorative cap cover. 6 in. 20 in. (152 mm) min. (508 mm) min. Figure 4.3 Multiple Vertical Termination Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 13 O Horizontal clearance between two horizontal termination caps – 12 in. (30 cm) minimum. Figure 4.4 Minimum Clearances for Terminations Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 14: Vent Information And Diagrams

    8-1/2 in. vertical run. A length of straight pipe is allowed DVP24MI 3 to 24 in. (76 to 610 mm) DVP Pipe between two 45° elbows (see Figure 5.1). (see chart) Figure 5.2 DVP Pipe Effective Length Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 15: Vent Diagrams

    25 ft/7.62 m 25 ft/7.62 m 25 ft/7.62 m * You may install the elbow directly on top of the CNXT4236 or CNXT4842. Figure 5.3 Top Vent-Horizontal Termination-One Elbow Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 16 See Figure 5.6 for information about installing elbows horizontally. min. max. max. 1 ft 24 ft 19 ft .30 m 7.32 m 5.79 m Installed Vertically Figure 5.5 Three Vertically Installed 90° Elbows Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 17 24 in./610 mm 25 ft/7.62 m 25 ft/7.62 m 25 ft/7.62 m 25 ft/7.62 m 25 ft/7.62 m Installed Vertically Installed Horizontally Figure 5.6 Two or Three Elbows, some Horizontal Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 18 12 ft (3.66 m) min. 60 ft (18.29 m) max. Maximum horizontal run is 100% of vertical, but cannot exceed 26 ft (7.92 m) Figure 5.8 Vertical Termination - Two Elbows Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 19 See Section E. Figure 5.9 Vertical Termination - Three Elbows (some horizontal) Rear Vent—Horizontal Termination—No Elbow 18 in. (457 mm) max. Figure 5.10 Horizontal Termination - No Elbows Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 20 4 ft/1.22 m 12 ft/3.66 m 8 ft/2.44 m 5 ft/1.52 m 15 ft/4.57 m 8ft/2.44 m 6 ft/1.83 m 18 ft/5.49 m Figure 5.12 Horizontal Termination - Two Elbows Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 21 4 ft/1.22 m 12 ft/3.66 m 8 ft/2.44 m 5 ft/1.52 m 15 ft/4.57 m 8 ft/2.44 m 6 ft/1.83 m 18 ft/5.49 m Figure 5.13 Horizontal Termination - Three Elbows Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 22 See Section E. Figure 5.15 Vertical Termination - Two Elbows Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 23: Vertical Termination - Three Vertical Elbows

    See Section E. Figure 5.16 Vertical Termination - Three Vertical Elbows Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 24: Installing Vertical Termination Baffl E

    Remove top by gently lowering toward side just removed and gently twisting out. See Figure 5.21. Figure 5.18 Baffl e Bent to 90° Angle Figure 5.21 Remove Top Refractory Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 25 fl ue collar. See Figure 5.23. Figure 5.23 Baffl e in Place 6. Reinstall refractory in reverse order of removal (see #3). 7. Replace the glass (refer to Section 12.H.). 8. Start the appliance. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 26: Vent Clearances And Framing

    If your local inspector requires the wall shield fi restop on both sides of the wall, then both wall shield fi restops must have a heat shield attached to them. Figure 6.3 Exterior Wall Hole Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 27: Install The Ceiling Firestop

    3 fasteners per side Ceiling firestop Ceiling firestop installed below ceiling. installed above ceiling. Figure 6.5 Installing Ceiling Firestop & Attic Insulation Shield Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 28: Install Attic Insulation Shield

    Bend all tabs inward 90° around the top of the shield. These tabs must be used to prevent blow-in insulation from getting between the shield and vent pipe, and to maintain clearance. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 29: Appliance Preparation

    Figure 7.1 Cover Plate, Top of Appliance Figure 7.4 Inner Plate, Top of Appliance • Remove the white insulation and set aside. See Figure 7.2. Figure 7.2 Remove White Insulation Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 30 Remove four screws holding outer shell cover. See Figure 7.7. Remove outer shell cover and set aside. Figure 7.10 Place inner collar on Rear of Appliance Figure 7.7 Outer Shell Cover Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 31 Figure 7.12 Cover Plate Placed on Rear of Appliance • Place the white insulation with the slot around the outer collar. See Figure 7.13. Figure 7.15 Outer Cover-Top Figure 7.13 Place Insulation over the Cover Plate Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 32 (Figure 7.7). Place the cover on top of appliance. See Figure 7.17. Replace four screws to hold plate in place. See Figure 7.18. Figure 7.19 Completed Conversion Figure 7.17 Place Cover Plate on Top of Appliance Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 33: Securing And Leveling The Appliance

    CAUTION Nailing Flanges Do NOT notch into the framing around the appliance (both sides) spacers. Figure 7.20 Proper Positioning, Leveling and Securing of an Appliance Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 34: Installing Vent Pipe

    If slip section seals are broken during the removal of the termination cap, gas will leak and a fi re or explosion may occur. do not break silicone seals on slip sections. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 35 If predrilling holes, do NOT penetrate inner pipe. Figure 8.2 Inner/Outer Figure 8.3 Snapped Make sure the seams are not aligned to prevent unintentional disconnection. CORRECT INCORRECT Figure 8.4 Seams Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 36 Only outer pipes are sealed, sealing the inner fl ue is not required. All unit collar, pipe, slip section, elbow and cap outer fl ues shall be sealed in this manner. Figure 8.7 Screws into Slip Section Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 37: Disassemble Vent Sections

    Improper support may allow vent to sag or Figure 8.9 Securing Horizontal Pipe Sections separate. Figure 8.10 Rotate Seams for Disassembly Figure 8.11 Align and Disassemble Vent Sections Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 38: Install The Heat Shield And Horizontal Termination Cap

    Pipe may separate if not properly joined. WARNING Do NOT connect a pipe section to a termination cap without using the telescoping fl ue section found on the termination cap. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 39 Figure 8.12 Venting through the Wall Note: Where required, an exterior wall fl ashing is available. When penetrating a brick wall, a brick extension kit is available for framing the brick. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 40: Install Roof Flashing And Vertical Termination Cap

    Inspect external vent cap regularly. Collar • Ensure no debris blocks cap. Screws • Combustible materials blocking cap may ignite. Caulk • Restricted air flow affects burner operation. Figure 8.15 Secure with Screws Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 41: Assemble And Install Storm Collar

    fl ashing. Figure 8.16 Assembling the Storm Collar Caulk around the top of the storm collar (see Figure 8.15). Figure 8.17 Assembling the Storm Collar Around the Pipe Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 42: Gas Information

    Natural Gas Propane Minimum Inlet Pressure 5.0 in. w.c. 11.0 in. w.c. Maximum Inlet Pressure 7.0 in. w.c. 14.0 in. w.c. Manifold Pressure 3.5 in. w.c. 10.0 in. w.c. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 43: High Altitude Installations

    Fire Risk Do NOT change the valve settings. • This valve has been preset at the factory. • Changing valve settings may result in fi re hazard or bodily injury. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 44: Electrical Information

    Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and CAUTION dangerous operation. Verify proper operation after servicing. Battery polarity must be correct or module damage will occur. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 45: Wsk-Mlt Multifunction Wall Switch

    National Electric Code ANSI/NFGA No. 70- current (in the United States), or with the current CSA C22.1 CANADIAN ELEC- TRIC CODE (in Canada). Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 46 TEMPERATURE BLACK YELLOW SENSOR SWITCH BLACK FAN THERMOSTAT CONNECTION GROUND PIGTAIL CONNECTION * May be labeled as “W” or “Y”. GREEN BLACK Figure 10.2 Intellifi re (IPI) Wiring Diagram Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 47: Installing The Flame Solenoid

    Connect one yellow wire to one jumper wire hanging from the thermodisc. • Connect the other yellow wire to remaining jumper wire hanging from thermodisc. • See Figure 10.2 for wiring diagram. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 48: Install The Remote Cover Plate

    Make sure all wires are under the top of the cover plate and that there are no wires pinched between legs and the bottom pan. Figure 10.5 Bend Legs Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 49: Wsk-Mlt Operating Instructions

    Be sure to rinse off all leak check solution following testing. Figure 10.8 Wall Switch Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 50: Wall Switch Button Operation

    120 VAC power is restored. Auxilary Button • Button Press: Turns on auxilary power • Button Press: Turns off auxilary power Can be operated independently of all functions. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 51: Service Parts List

    Service Part # Solenoid HTI-17-006 Wall Switch/Key Pad HTI-12-007 Cover Plate HTI-21-007 Control Box HTI-13-007 Actuator Pins HTI-17-116 Switch Kit 060-511 Wire Assy Male Terminals 4003-128 Wire Assy 1-Male/1-Female Terminal 4003-129 Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 52: Finishing

    • May interfere with proper operation of glass • Seal joints between the fi nished wall and appliance assembly. top and sides using only a 300° F minimum sealant. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 53: Appliance Setup

    Using non-listed accessories may result in a safety hazard. • Only Hearth & Home Technologies approved accessories may be used safely. Figure 12.2 Placement of Lava Rock Figure 12.3 Placement of Vermiculite Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 54: Log Assembly

    Figure 12.6 Placing Left Top Log • Install right top log as shown in Figure 12.7 using locating pins to position log properly. Figure 12.7 Placing Right Top Log Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 55: Glass Assembly

    When the shutter adjustment handle is all the way up, the air shutter is in the fully open position. Latches Closed (both bottom and top) Glass Assembly Figure 12.8 Glass Assembly Figure 12.9 Air Shutter Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 56: Operating Instructions

    Glass door MUST be in place and sealed water. before operating appliance. • Only use glass doors certifi ed for use with the appliance. • Glass replacement should be done by qualifi ed technician. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 57: Lighting The Appliance

    B. Lighting the Appliance Intellifi re Ignition Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 58: After The Appliance Is Lit

    In an Intellifi re ignition system it is normal to see the pilot fl ame, but it should turn off when ON/OFF burn continually? switch is turned off. In a standing pilot system the pilot will always stay on. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 59: Troubleshooting

    “I” terminal module must be replaced. If there is a spark at “I” terminal, module is fi ne. Inspect pilot assembly for shorted sparker wire or cracked insulator around electrode. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 60 Verify module is securely grounded to metal chassis of appliance. Module voltage output/ Verify battery voltage is at least 2.7 volts. Replace batteries if voltage is below valve/pilot solenoid ohms 2.7. readings. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 61: Maintaining And Servicing The Appliance

    A i r p a s s a g e w a y s , g r i l l e s , c o n t r o l compartment. • Burner, burner ports. Risk of: • Fire • Delayed ignition or explosion • Exposure to combustion fumes • Odors Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 62: Maintenance Tasks

    Verify operation of remote. Replace batteries in remote transmitters and battery-powered receivers. Verify batteries have been removed from battery back-up in IPI systems to prevent premature battery failure or leaking. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 63: Reference Materials

    (60 mm) (165 mm) 5-7/8 in. 14-1/8 in. (149 mm) (365 mm) 27-1/4 in. (692 mm) Model # CNXT4236 24-1/4 1041 CNXT4842 30-1/4 1194 1067 Figure 16.1 Appliance Dimensions Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 64: Vent Components Diagrams

    High Rise Termination Cap - Unpainted Stainless Steel (not approved for all units) DVP-HRC-ZC-SS High Rise Termination Cap - Zero Clearance - Unpainted Stainless Steel (not approved for all units) 4033-016 DVP-TRAP to DVP-HPC Side Filler Kit Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 65 10 in. (38 mm) (254 mm) 8 in. (203 mm) 14 in. (356 mm) 12 in. (305 mm) 5 in. (127 mm) DVP-HVS DVP-WS Vent Support Wall Shield Firestop Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 66 7-1/8 in. (308 mm) (181 mm) 5-3/4 in. (146 mm) COOL-ADD Cap Shield DVP-TRAPFL Flashing 13-7/8 in. 9-1/2 in. (352 mm) (241 mm) 14 in. (356 mm) DRC-RADIUS Cap Shield Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 67 12 in. (305 mm) DVP-FBHT 7-1/8 in. 12-1/8 in. Fire Brick Termination Cap (181 mm) (314 mm) 8-3/4 in. (222 mm) 1-5/8 in. (41 mm) DVP-HPC High Performance Cap Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 68 105 mm 143 mm TRAP2 6-3/4 in. 10-5/8 in. 171 mm 270 mm 12 in. Effective (305 mm) Length DVP-TRAP Horizontal Termination Cap DVP-TRAP1 DVP-TRAPK1 DVP-TRAP2 DVP-TRAPK2 DVP-HPC1 DVP-HPC2 Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 69 Effective Length 5-1/2 in. 8-3/8 in. 5-3/4 to 8-3/8 in. 140 mm 213 mm 146 to 213 mm 3° 87° 10-1/2 in. 267 mm 10-7/8 in. 276 mm DVP-HRC-ZC-SS Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 70: Service Parts List

    C. Service Parts List CNXT4236 SERIES Service Parts Beginning Manufacturing Date: N/A Service Parts Diagram Ending Manufacturing Date: Active 36 in. Caliber NXT Series (Valve Assy.) Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 71 4031-252 4031-252 4031-252 Blower Assembly 4047-016 4047-016 4047-016 4047-016 Front Face 4040-274 4040-274 4040-274 4040-274 Installation Instructions/Owner’s Manual 4047-132 4047-132 4047-132 4047-132 Gas Operations Manual 71680 71680 71680 71680 Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 72 CNXT4236 SERIES Service Parts Beginning Manufacturing Date: N/A Service Parts Diagram Ending Manufacturing Date: Active 36 in. Caliber NXT Series Log/Grate Assembly Traditional Brick Refractory Herringbone Brick Refractory Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 73 4047-118 4047-118 Lava Rock Bag Assembly 4040-094 4040-094 4040-094 4040-094 Mineral Wool 14333B 14333B 14333B 14333B Vermiculite 28746 28746 28746 28746 Lava Rock (3lb. Bag) 4021-297 4021-297 4021-297 4021-297 Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 74 CNXT4236 SERIES Service Parts Beginning Manufacturing Date: N/A Valve Assembly Diagram Ending Manufacturing Date: Active 36 in. Caliber NXT Series Valve Assembly Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 75 4040-189 4040-189 4040-189 4040-189 Shutter Box Top 4040-190 4040-190 4040-190 4040-190 Valve Bracket 4040-193 4040-193 4040-193 4040-193 Pilot Bracket 4047-126 4047-126 4047-126 4047-126 Variable Valve 750-500 750-501 750-500 750-501 Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 76 CNXT4236 SERIES Service Parts Beginning Manufacturing Date: N/A Service Parts Diagram Ending Manufacturing Date: Active 36 in. Caliber NXT Series Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 77 Actuator Pins HTI-17-116 HTI-17-116 HTI-17-116 HTI-17-116 Heat Shield 4047-129 4047-129 4047-129 4047-129 Wire Assembly 593-590A 593-590A 593-590A 593-590A Control Module 593-592 593-592 593-592 593-592 Battery Pack 593-594A 593-594A 593-594A 593-594A Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 78 CNXT4842 SERIES Service Parts Beginning Manufacturing Date: N/A Service Parts Diagram Ending Manufacturing Date: Active 42 in. Caliber NXT Series (Valve Assy.) Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 79 Gas Operations Manual 71680 71680 71680 71680 Blower Assembly 4047-016 4047-016 4047-016 4047-016 Blower GFK160B GFK160B GFK160B GFK160B Valve Plate Gasket 4040-198 4040-198 4040-198 4040-198 Gasket 4031-252 4031-252 4031-252 4031-252 Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 80 CNXT4842 SERIES Service Parts Beginning Manufacturing Date: N/A Service Parts Diagram Ending Manufacturing Date: Active 42 in. Caliber NXT Series Log/Grate Assembly Traditional Brick Refractory Herringbone Brick Refractory Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 81 4047-118 4047-118 Lava Rock Bag Assembly 4040-094 4040-094 4040-094 4040-094 Mineral Wool 14333B 14333B 14333B 14333B Vermiculite 28746 28746 28746 28746 Lava Rock (3lb. Bag) 4021-297 4021-297 4021-297 4021-297 Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 82 CNXT4842 SERIES Service Parts Beginning Manufacturing Date: N/A Valve Assembly Diagram Ending Manufacturing Date: Active 42 in. Caliber NXT Series Valve Assembly Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 83 4040-189 4040-189 4040-189 4040-189 Shutter Box Top 4040-190 4040-190 4040-190 4040-190 Valve Bracket 4040-193 4040-193 4040-193 4040-193 Pilot Bracket 4047-126 4047-126 4047-126 4047-126 Variable Valve 750-500 750-501 750-500 750-501 Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 84 CNXT4842 SERIES Service Parts Beginning Manufacturing Date: N/A Service Parts Diagram Ending Manufacturing Date: Active 42 in. Caliber NXT Series Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 85 Actuator Pins HTI-17-116 HTI-17-116 HTI-17-116 HTI-17-116 Heat Shield 4047-129 4047-129 4047-129 4047-129 Wire Assembly 593-590A 593-590A 593-590A 593-590A Control Module 593-592 593-592 593-592 593-592 Battery Pack 593-594A 593-594A 593-594A 593-594A Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 86: Optional Components

    D. Optional Components Arts & Crafts Faux Front Modernist Faux Front FFCAC FFCM Jamestown Faux Front FFCJ Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 87 Arts & Crafts-style brushed nickel decorative faux front FFCJ42 Jamestown-style black decorative faux front FFCJ42PT Jamestown-style pewter decorative faux front DCKVP-NXT-B NC to LP Conversion Kit DCKVN-NXT-B LP to NG Conversion Kit Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 88 This page intentionally left blank. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 89 This page intentionally left blank. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...
  • Page 90 This page intentionally left blank. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

  • Page 91: Limited Lifetime Warranty

    If the Heatilator Appliance is found to be defective in either material or workmanship within one year of the date of original installation, HHT will provide replacement parts at no charge and pay reasonable labor and freight costs, and is for the period of one year following the date of original installation of the Appliance.

  • Page 92: Contact Information

    6748942, 6769426, 6774802, 6796302, 6840261, 6848441, 6863064, 6866205, 6869278, 6875012, 6880275, 6908039, 6919884, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408, 2313972; (Australia) 780250, 780403, 1418504 or other U.S. and foreign patents pending. Heatilator • Caliber CNXT Series • 4047-132 Rev P • 11/07...

This manual is also suitable for:

Cnxt4236ih cnxt4842ihCnxt4842iltCnxt4842itCnxt4236ilhCnxt4842ilhCnxt4236ilt ... Show all

Table of Contents
