Slanted layout: This layout presents the two 455 kHz side sonar beams and the 200 kHz down-looking
sonar beam as three panels of historical data. This layout is presented as three slanted panels. New
information appears on the right, and scrolls to the left.
9
1
1 Depth
Temp: water surface temperature
2
3 Speed: speed of boat
4 Course: the current direction the boat is traveling measured in degrees from North
5 VLT: Voltage
Left Side 455 kHz Sonar History Window
6
In all of these layouts, the sonar information from the side-looking beams reveals bottom contour, structure
and fish similar to the down-looking beam, but the area covered is to the left and right of the area shown
in the down-looking portion, so you actually see more of the bottom. The distance covered by the right and
left beams is based on the depth setting for the down-looking beam, up to a maximum of 160 feet.
Side Beam View, Slanted Layout
6
2
9
7
3 4
81
9
5
200 kHz Sonar History Window
Right Side 455 kHz Sonar History Window
Water Surface Line
Upper Depth Range
Lower Depth Range
10
11
8
7
8
9
10
11
