1. Motherboard layout

PS/2
T: Mouse
B: Keyboard
COM1
DDR DIMM2 (64/72 bit, 184-pin module)
DDR DIMM1 (64/72 bit, 184-pin module)
Bottom:
Top:
USB1
1394
USB2
Bottom:
Top:
USB1
RJ-45
USB2
Top:Line In
Realtek
Center:Line Out
RTL8201
Below:Mic In
SPDI/F
CD_IN
AUX_IN
FRONT_AUDIO
ALC650
ASUS K8N8X-LA (Dom) Motherboard
24.5cm (9.64in)
Socket 754
CPU_FAN
Accelerated Graphics Port (AGP)
K8N8X-LA
PCI 1
PCI 2
PCI 3
F1
ATX12V
SATA1 SATA0
nVIDIA
nFORCE3
TI
TSB43AB22A
FRONT_1394
FRONT_USB2
CLPWD
Super
I/O
4Mb
BIOS
BAT1
CLRTC
BUZZER1
FRONT_PANEL1
FRONT_USB1
1
