K8N8X-LA (Dom) specifications summary

CPU
Chipset
System Bus
Memory
Expansion slots
IDE
Onboard Audio
Onboard LAN
Onboard IEEE 1394
Hardware monitoring
Rear panel I/O
Internal I/O
BIOS features
Industry Standard
Form factor
Socket 754 for AMD Athlon™64 processor
AMD 64 architecture that enables 32- and 64-bit computing
NVIDIA nForce 3 250
800 MHz
2 x 184-pin DDR DIMM sockets for up to 2GB memory
Supports PC3200/2700/2100/1600 double-sided DDR
1 x AGP 8X slot
3 x PCI slots
1 x ASUS proprietary PCI expander connector
2 x UltraDMA100/66/33 connectors, PIO Mode 3/4
Supports ATAPI IDE, CD-ROM, CD-R, CD-RW and LS-120
2 x Serial ATA connectors
RealTek ALC650 6-channel audio CODEC subsystem
AC'97 2.2 compliant
CK8S MAC + Realtek RTL8201BL LAN PHY
TI TSB43AB22A supports 2 x IEEE1394 ports with 400/200/
100Mbps data transfer rate
Super I/O integrated monitoring of CPU and system fan
rotations and CPU temperature
1 x Parallel port
1 x Serial port
1 x PS/2 keyboard port
1 x PS/2 mouse port
4 x USB 2.0 ports
1 x RJ-45 port
1 x IEEE 1394 port
Line In/Line Out/Microphone ports
2 x USB 2.0 connectors for additional 4 USB ports
1 x IEEE 1394 connector for additional 1394 port
CPU fan connector
20-pin ATX power connector
4-pin ATX power connector
S/PDIF out connector
CD/AUX audio connectors
Front Audio connector
4Mb Flash ROM, AMI BIOS with Enhanced ACPI,
DMI, Green, PnP features
USB 2.0/1.1, PCI 2.2
Micro-ATX form factor: 9.6 in x 9.6 in (24.5 cm x 24.5 cm)
