Panasonic WV-CS954 Brochure & Specs

Superb Image Quality with Added Intelligence
The new Panasonic WV-CS954 Super Dynamic III dome
camera is equipped with a 30x optical zoom lens.
Combined with a 10x digital zoom, for a total zoom capability
up to 300x, this camera can identify distant subjects.
With its Pixel Based 128x Dynamic Range, the WV-CS954
works beautifully even when contrast changes from scene to
scene. Area free natural contrast image correction ensures
accurate reproduction, whatever the subject. Horizontal resolution
is also significantly higher, 540 lines (typical) in color or 570 lines
in B/W. Plus, images stay clear and sharp in lighting as low as
0.5 lux (0.05 fc, in color) and 0.04 lux (0.004 fc, in B/W).
Adaptive Digital Noise Reduction eliminates streaking from
objects such as headlights. Its 0.065°/sec. ultra slow speed fine
control and powerful zoom let you zoom in smoothly on your
subject. Whatever the situation, WV-CS954 offers dramatic
improvement in subject identification.
Additional intelligent features include Auto Image Stabilizer
to eliminate blurring if the camera is shaken. Scene Change
Detection to send the alarm signal if the camera is interfered with,
Auto Tracking of intruders, and 256 preset positions.
Combining extraordinary image quality with added intelligence,
the WV-CS954 brings unprecedented reliability to 24-hour surveillance.
KEY FEATURES
•
All-in-one color surveillance dome camera unit.
•
The new Pixel Based 128x Dynamic Range with area free natural
contrast image correction adjusts moment-to-moment changes in
contrast to view subjects accurately in all areas and positions.
•
Higher horizontal resolution of 540-line (typical) at color mode, and 570-line at B/W mode.
•
Minimum illumination of 0.5 lux (0.05 fc) at color mode, and 0.04 lux
(0.004 fc) at B/W mode (Sens. up; off, AGC High).
•
Innovative intelligent features:
Auto image stabilizer function for applications where vibration or wind
*
is a concern, e.g. passing vehicles.
Scene change detection alarms when lens is covered, spray painted,
*
removed, defocused or camera angle is changed.
Auto tracking function tracks moving objects and keeps them centered in
*
the field of view. Perfect for restricted areas and after hour applications.
•
Day/Night operation can be selected to automatically or manually switch
from color to B/W.
•
Privacy zone masking function.
•
Linear 32x electronic sensitivity enhancement function.
•
Digital motion detector.
•
30x optical zoom lens (3.8 - 114 mm at F1.4) plus 10x electronic digital
zoom for total zoom capacity of 300x.
•
Auto focus lens.
•
Digital-FLIP by memory allows automatic 180° turn.
•
Patrol Learn function (8 zone total).
•
Auto panning function with 256 preset positions.
•
360° endless panning.
•
Panning speed of max. 400°/s at preset mode and 0.065°/s super
fine control at manual mode.
•
Image Hold function during panning.
•
Multiplex-coaxial or RS-485 data communication.
•
Four (4) alarm inputs and two (2) outputs terminals.
•
16 alphanumeric character display.
•
Internal/Line-lock/Multiplexed Vertical Drive (VD2) synchronization.
•
24V AC, 60Hz power source.
•
Optional smoked dome cover, ceiling and wall mounts brackets are
available for various applications.
Super Dynamic III
Color Dome Camera
WV-CS954
