1. Shroud latch
ECS00140
NOTICE
Make sure that all cables and wires are in
place when closing the shroud.
ESU10731

Shroud and covers

Securely fasten the shroud and covers before
operating the snowmobile. (See page 48 for
removal and installation procedures.)
PZ50RT / PZ50GT / PZ50MT
1. Air filter case cover
2. Front cover
Control functions
1. Top cover
2. Right upper cover
3. Right side cover
4. Right lower cover
1. Left side cover
PZ50VT
1. Shroud
2. Left upper cover
3. Left side cover
