FPA-5000 OPC-Server
3

Installation

3.1

Installation of FSM-5000-OPC Software

Task: FSM-5000-OPC is running on a PC.
Notice!
.NET Framework 2.0 must be installed to run FSM-5000-OPC. If it is not present install it from
the Pre-Requisites folder of the FSP-5000-RPS installation CD or download it from http://
www.microsoft.com/downloads/en/default.aspx
1.
2.
3.
4.
5.
6.
Notice!
The installation of FSM-5000-OPC is only released for the Windows operating systems listed
in Technical data, page 13. For other operating systems the installation may succeed but
was not tested and is therefore on your own risk.
3.2 Remote Access to the FSM-5000-OPC Server from the Building
Integration System (BIS)
Task: FSM-5000-OPC is running on a PC in your local network interconnected with the panel
network. The OPC client application runs on a PC of the Building Integration System (BIS) in
the same local network. It remotely accesses the FSM-5000-OPC server.
Server side PC
Notice!
Consider the naming conventions for users, groups and passwords ("MgtS-Service"
"BISUsers") given in this description. The Building Integration System (BIS) internally makes
use of these conventions. As BIS internally always assumes the same user and password by
convention it is not necessary to logon as a distinct user or enter the password. If you
remotely access the FSM-5000-OPC server with another client, you are free to choose names
and a password on the server side, as long as you specify the matching logon when your
client connects to the OPC server.

Bosch Sicherheitssysteme GmbH

On the setup disc open the folder that contains the FSM-5000-OPC installation.
Click "FPA5000OPCServer.msi" and follow the installation instructions.
Open the Configuration Editor:
Start → All Programs → Bosch → FPA5000OPC-Server and run Configuration Editor
or open Windows Explorer, navigate to
C:\Program Files\Bosch\FPA 5000OPC-Server and run ConfigEditor.exe
or for FSM-5000-OPC version 1.2 right click on the respective icon in the taskbar
notification area and choose "Configuration".
Under the "Communications" tab adopt the settings that were entered for the node
"FPA5000 OPC Server" in the RPS configuration.
Configure the Windows firewall. The configuration depends on the operating system and
the used firewall.
Restart the system.
FSM-5000-OPC will be running after restart, indicated by a notification icon in the taskbar
notification area.
User Guide
Installation | en 7
2013/05 | 2.0 | F.01U.261.550
