Commands Dialog Box Functions; Figure 3.15: Oscar Interface Name Modify Dialog Box; Table 3.6: Commands To Manage Routine Tasks For Your Target Devices - Avocent AutoView 3200 Installer/User Manual

Figure 3.15: OSCAR Interface Name Modify Dialog Box

2. Type a name in the New Name box. Names of target devices may contain all
printable characters.
3. Click OK to transfer the new name to the Names dialog box. Your selection is not saved until
you click OK in the Names dialog box.
4. Repeat steps 1-3 for each target device in the system.
5. Click OK in the Names dialog box to save your changes.
-or-
Click X or press
NOTE: If an IQ module has not been assigned a name, the EID is used as the default name.
To list target devices alphabetically by name:
Press or click Name in the Main dialog box.
Alt+N

Commands Dialog Box Functions

From the OSCAR interface Commands dialog box, you can manage your AutoView 3050/3100/
3200 switching system and user connections, enable the Scan and Broadcast modes and update
your firmware.

Table 3.6: Commands to Manage Routine Tasks for Your Target Devices

Features
Broadcast
Enable
Scan Enable
to exit the dialog box without saving changes.
Escape
Purpose
Begin broadcasting to your target devices. Configure a target device list for broadcasting
under the Setup dialog box.
Begin scanning your target devices. Set up a target device list for scanning in the Setup
dialog box.
Chapter 3: Local Port Operation 31
