Customizing The Data; Alerts - Garmin Fenix 2 Owner's Manual

Pool Length: Sets the pool length for pool swimming
a Pool Swim).
Rest Timer: Enables the rest data page for pool swimming.
Stroke Detection: Enables stroke detection for pool swimming.
Reset: Restores the factory default settings for the selected
activity.
In Menu: Shows or hides the selected activity in the activity
menu.
Customizing the Data Pages
You can show, hide, and change the order of data pages for
each activity. You can also edit the data fields for some data
pages.
1
Hold MENU.
2
Select Settings > Activity.
3
Select the activity to customize.
4
Select Data Pages.
5
Select Add Page, and follow the on-screen instructions to
add a new page (optional).
6
Select a page to edit data fields.
7
Select an option:
• Select Edit, and change the data fields.
• Select Move Up or Move Down to change the order of
the data pages.
• Select Delete to remove the data page from the page
loop.
Data Pages
Some data pages are available only for specific activities, and
some data pages require you to pair the device with an ANT+
sensor (Pairing ANT+ Sensors). Minimum, maximum, and chart
data are calculated from the time when you started the activity.
NOTE: Your body temperature affects the temperature reading.
To get the most accurate temperature reading, remove the
device from your wrist and wait 20 to 30 minutes.
Data Page Description
1 Field Displays one
configurable data field.
2 Fields Displays two
configurable data fields.
3 Fields Displays three
configurable data fields.
Altimeter Displays your current,
minimum, and
maximum elevation and
a chart of the elevation
history.
Barometer Displays the current,
minimum, and
maximum barometric
pressure and a chart of
the barometric pressure
history.
Compass Displays the compass,
with your direction of
travel at the top.
Temp Displays the current,
minimum, and
maximum temperature
and a chart of the
temperature history.
Map Displays the map.
Customizing Your Device
(Going for
ANT+ Activities
Sensor
None All
None All
None All
None All
None All
None All
tempe™ All
(optional)
None All except pool
swimming
Data Page Description
Heart Rate Displays your current,
minimum, and
maximum heart rate
and a chart of your
heart rate history.
Cadence Displays your current,
minimum, and
maximum cadence and
a chart of your cadence
history.
Power Displays your current,
minimum, and
maximum generated
power and a chart of
your power history.
Virtual Displays the Virtual
Partner Partner page (Using
Virtual Partner ®
Running Displays your running
Dynamics dynamics information
(Running Dynamics).
Alt. Zones Displays alternate time
zones (Adding a
Custom Time Zone).
Dual Grid Displays your GPS
coordinates.
Rest Displays your rest time
while swimming.
Time Displays the time and
date.
Current Run Displays data about
your current ski run.
Total Runs Displays data about
your total ski runs for
the current activity.
Workouts Displays the goal and
additional data for the
current workout step.

Alerts

You can set alerts for each activity, which can help you to train
toward specific goals, to increase your awareness of your
environment, and to navigate to your destination. Some alerts
are available only for specific activities. There are three types of
alerts: event alerts, range alerts, and recurring alerts.
Event alert: An event alert notifies you once. The event is a
specific value. For example, you can set the device to alert
you when you reach a specified elevation.
Range alert: A range alert notifies you any time the device is
above or below a specified range of values. For example,
you can set the device to alert you when your heart rate is
below 60 beats per minute (bpm) and over 210 bpm.
Recurring alert: A recurring alert notifies you every time the
device records a specified value or interval. For example,
you can set the device to alert you every 30 minutes.
Alert Name Alert Type Description
Battery Event You can set a low battery power alert.
Cadence Range You can set minimum and maximum
cadence values.
Calories Event, You can set the number of calories.
recurring
ANT+ Activities
Sensor
Heart rate All
monitor
(required)
Foot pod, Running, biking,
bike custom
cadence
sensor,
power
sensor,
Vector™,
HRM-Run
(optional)
Power Biking, custom
sensor,
Vector
None Running, biking,
custom
).
HRM-Run Running,
(required) custom
None All
None All
None Pool swimming
None All
None Downhill skiing
or snowboarding
None Downhill skiing
or snowboarding
None Workout,
custom
11
