Find GENUINE Replacement Parts at
www.dirtdevil.com
• Please read these instructions
carefully before using your Dirt
Devil
Bagless Canister.
®
• Let us help you put your vacuum
together or answer any questions,
call:
1-800-321-1134
(USA & Canada)
www.dirtdevil.com
WARNING:
Cleaner assembly may include small parts.
Small parts can present a choking hazard.
Warranty Registration
• Online at: www.dirtdevil.com
• Mail: Royal Appliance Mfg
7005 Cochran Rd.
Glenwillow, Ohio 44139
Español - página E1
OWNER'S MANUAL
Operating and Servicing Instructions
This cleaner uses the
FILTER TYPE
following parts:
For quick reference, please record your
vacuum information below.
Model #:
Mfg. Code:
(Mfg. code located on the lower backside of cleaner)
©2006 All rights reserved # 1-113422-000
F21
6/06
Advertisement
Table of Contents
Related Manuals for Dirt Devil F21
Summary of Contents for Dirt Devil F21
- Page 1 OWNER’S MANUAL Operating and Servicing Instructions Find GENUINE Replacement Parts at This cleaner uses the FILTER TYPE www.dirtdevil.com following parts: • Please read these instructions carefully before using your Dirt Devil Bagless Canister. ® • Let us help you put your vacuum together or answer any questions, call: 1-800-321-1134 (USA & Canada)
-
Page 2: Safety Instructions
THIS VACUUM CLEANER IS INTENDED FOR HOUSEHOLD USE ONLY. IMPORTANT SAFETY INSTRUCTIONS When you use an appliance, basic precautions should always be followed, including the following: • READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE. • ALWAYS FOLLOW THESE SAFETY INSTRUCTIONS. • DO NOT LEAVE VACUUM CLEANER UNATTENDED WHEN PLUGGED IN. • WARNING: FULLY ASSEMBLE VACUUM CLEANER BEFORE OPERATING. • REGULARLY CHECK THE FILTERS TO CLEAN OR REPLACE. • WARNING: THE CORDS, WIRES, AND/OR CABLES SUPPLIED WITH THIS PRODUCT CONTAINS CHEMICALS, INCLUDING LEAD OR LEAD COMPOUNDS, KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. WASH HANDS AFTER USING. WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY: • Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing. - Page 3 • Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they may be present. • Store the vacuum cleaner indoors. Put the vacuum cleaner away after use to prevent tripping accidents. •...
-
Page 4: Table Of Contents
CONGRATULATIONS You are now the proud owner of a Dirt Devil . We trust your new purchase ® will bring you many years of satisfaction. Our company has designed and developed this product with you in mind. We are very proud of our products and hope that you are equally satisfied with their quality and performance. Thank you for your support of Dirt Devil ® products. Visit our website at www.dirtdevil.com TABLE OF CONTENTS Safety Instructions ....... . . Page 2, 3 Features . -
Page 5: Features
FEATURES 1. Front Cover 15. Headlight 2. Cord Rewind Button 16. Motorized Power Nozzle 3. Variable Speed Control 17. Hose Connection 4. Carry Handle 18. Dirt Container Release 5. On/Off Button Button 6. Easy Glide Wheels 19. Filter 7. Extension Wand 20. Hose Plug 8. Dust Brush 21. Dirt Container 9. Crevice Tool 22. Height Level Indicator 10. Upholstery Tool 23. Brushroll Reset Button 11. Tool Caddy 24. Height Adjust Lever 12. Brushroll On/Off Button... -
Page 6: Attachments
HOW TO ASSEMBLE: CONTINUED ATTACH EXTENSION WAND ATTACH MOTORIZED POWER NOZZLE Insert handle end of hose Insert extension wand into extension wand. Push into the motorized power firmly until wand locks into nozzle. Push firmly until place. wand locks into place. TOOL STORAGE Attach tool caddy to extension Attachments are packaged wand by snapping into place. -
Page 7: How To Operate
DIRT CONTAINER & FILTER: REMOVAL & REPLACEMENT WARNING: TO REDUCE THE RISK OF INJURY FROM MOVING PARTS - UNPLUG BEFORE SERVICING. FILTER TYPE For F21 filter replacement, please visit our website at www.dirtdevil.com to buy online or call customer service at 1-800-321-1134. REMOVE HOSE REMOVE DIRT CONTAINER Firmly grasp hose plug and pull until plug Press dirt container release button and lift front cover (Diagram is released (Diagram 1). - Page 8 DIRT C ONTAINER & F ILTER R EMOVAL & R EPLACEMENT: C ONTINUED EMPTY DIRT CONTAINER REMOVE FILTER ASSEMBLY Hold dirt container over garbage can and To remove filter assembly, lift Remove filter screen by turning clockwise. NOTE: Do press “Empty Dirt” button to empty. Snap up and out of dirt container.
-
Page 9: Lightbulb: Removal & Replacement
EXHAUST FILTER: REMOVAL & REPLACEMENT EXHAUST FILTER ( Located on the back of the cleaner.) Grasp tab and pivot down while Push tab and pivot to the side to Remove exhaust filter from pulling out exhaust cover. remove exhaust filter frame. exhaust filter frame and tap on inside of garbage can to remove excess dust and dirt. -
Page 10: Troubleshooting Guide
TROUBLESHOOTING GUIDE WARNING: TO REDUCE RISK OF PERSONAL INJURY - UNPLUG CLEANER BEFORE SERVICING PROBLEM POSSIBLE REASON POSSIBLE SOLUTION Cleaner won’t run 1. Power cord not firmly plugged into 1. Plug unit in firmly. outlet. 2. Blown fuse or tripped breaker. 2. Check fuse or breaker in home. Replace fuse/reset breaker. - Page 12 5. El control de velocidad variable está 5. Ajuste del control de velocidad variable - Pág. E7. con cuidado antes de usar su ajustado demasiado bajo. aspiradora sin bolsa Dirt Devil ® Polvo escapando de 1. Vacíe el recipiente de polvo - Pág. E8.
- Page 13 ESTA ASPIRADORA ESTÁ DISEÑADA PARA USO DOMÉSTICO SOLAMENTE. FILTRO DE DESCARGA: RETIRO Y REEMPLAZO INSTRUCCIONES DE SEGURIDAD IMPORTANTES FILTRO DE DESCARGA (Ubicado en la parte posterior de la aspiradora.) Cuando use un electrodoméstico se deben seguir siempre las precauciones básicas, incluyendo las siguientes: • LEA TODAS LAS INSTRUCCIONES ANTES DE USAR ESTE APARATO. • SIEMPRE SIGA ESTAS INSTRUCCIONES DE SEGURIDAD. • NO DEJE LA ASPIRADORA SIN VIGILANCIA CUANDO ESTÉ CONECTADA. • ADVERTENCIA: ENSAMBLE TOTALMENTE LA ASPIRADORA ANTES DE USARLA. • REVISE C ON F RECUENCIA L OS F ILTROS P ARA L IMPIARLOS O R EEMPLAZARLOS. Tome la lengüeta y gírela hacia Empuje la lengüeta y gírela hacia Retire el filtro de descarga del...
- Page 14 gasolina, ni la use en áreas donde éstos puedan encontrarse presentes. RECIPIENTE DE POLVO Y FILTRO: RETIRO Y REEMPLAZO: • Mire la superficie externa de su aspiradora y siga todas las instrucciones de las CONTINUACIÓN etiquetas y señales. VACÍE EL RECIPIENTE DE POLVO RETIRO DEL CONJUNTO DEL FILTRO • No use extensión de cordón con esta aspiradora. •...
- Page 15 Royal Appliance Mfg. Co. garantiza al consumidor que esta aspiradora no tiene defectos ni de material ni de TIPO DE FILTRO Para el filtro de reemplazo F21, por favor visite nuestro sitio Web en www.dirtdevil.com para mano de obra. La garantía comienza en la fecha de compra original. Vea la caja para información de la duración comprar en línea o llame a servicios al cliente al 1-800-321-1134.
- Page 16 CARACTERÍSTICAS CÓMO ENSAMBLAR: CONTINUACIÓN COLOCACIÓN DE LA LANZA COLOCACIÓN DE LA BOQUILLA DE EXTENSIÓN ELÉCTRICA MOTORIZADA Inserte el extremo del Inserte la lanza de extensión en asa de la manguera en la boquilla eléctrica motorizada Empuje con firmeza hasta que la lanza de extensión. quede trabada. Empuje con firmeza hasta que quede trabada.
