ITEM QTY PART NO.
1 1 11040-216
2 1 11040-301
3 2 13000-364
4 1 4700-266
5 1 BH030207
7
8
3
Cybex VR3 12130 Lat Pull Owner's Manual
12430 VR3 Lat Pull
Graduated Stack Assembly Configuration
12301-007 Assembly
DESCRIPTION
Belt Clamp
Belt Clamp Insert
Bearing, Flange
Top Weight 15- 3 x 12
Pin, Weight Selector
2
9
5
TORQUE SET SCREWS
300-350 IN./LBS
6
ITEM QTY PART NO.
6 2 BR030206
7 2 BR030220
8 2 HS720004
9 3 HY740000
10 181.5" GB000202
1
9
7
8
4
DESCRIPTION
Ring, Retaining
Retaining Ring 1.250 Internal
Washer, Felt
Set Screw
Weight Stack Belt .95 Wide
(Not Shown)
3
6
Page 6-11
Service
