CYBEX VR3 Lat Pull Owner's And Service Manual page 39

9
11
11
8
11
9
11
11
9
11
11
9
11
11
9
11
11
9
11
11
Cybex VR3 12130 Lat Pull Owner's Manual
11
11
2
4
10
6
13
5
Light Stack Assembly Configuration
ITEM QTY PART NO.
1 1 11040-007
2 1 12000-378
3 1 12000-384
4 2 12000-388
5 2 12102-330
6 2 12210-351
7 2 12210-352
8 1 3900-441
9
9 10 HF579000
10 2 HS760106
11 15 HX570412
9
12 2 JS497600
13 2 11040-409
14 3 HY740000
15 1 11040-216
16 1 11040-301
9
9
9
TOURQUE SET SCREWS
300-350 IN./LBS
16
9
14
14
3
7
7
12
12
12020-020
DESCRIPTION
Top Weight Assembly 15
Support
Panel, Insert
Extrusion, Inc Wt Channel
Insert, Increment Weight
Spacer Tube
Plastic Insert
Decal, Cybex
Panel Fastner, 10-24 U Type
Washer, Flat, 1.75 X .688 X .140 T
BHSCS, 10-24 X .50, SS
Washer, 1.19ID X 1.75 OD X .12 THK
Molded Bumper
Set Screw
Belt Clamp
Belt Clamp insert
4
1
10
6
13
5
Service
Page 6-9
