Vulcan-Hart VRB-36F Features & Dimensions

SPECIFICATIONS:
Heavy duty top fired gas broiler, Vulcan-Hart Model VRB-36F.
Stainless steel front and front top ledge. Sides and top finished in
black epoxy powder coat paint. 6" adjustable legs. 1
front gas manifold. Four 25,000 BTU/hr. heavy duty stainless
steel radiant burners, 100,000 BTU/hr. total input. Pilot ignition
system. Two infinite heat control valves. Floating grid rack
assembly with positive positioning control handle. Two section
1
cooking grid measures 25 / " x 25
2
drains into a large capacity grease collector. Finishing oven above
broiler with manual heat control measuring 28"w x 20"d x 13"h.
Exterior dimensions: 36"w x 38
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS AND FINISH WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32527 (10-03)
1 / " diameter
4
1
/ ". Full width floating drip pan
2
1 / "d x 78 1 / "h on 6" adjustable legs.
4 2
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
VRB-36F
HEAVY DUTY GAS RADIANT BROILER
WITH FINISHING OVEN
VRB-36F Top fired radiant gas broiler with
standard oven
STANDARD FEATURES
Stainless steel front and front top ledge. Sides and top finished
in black epoxy powder coat paint. 6" adjustable legs.
1 1 / " diameter front gas manifold.
4
Four 25,000 BTU/hr. heavy duty stainless steel radiant burn-
ers, 100,000 BTU/hr. total input.
Pilot ignition system.
Two infinite heat control valves.
Floating grid rack assembly with positive positioning control
handle. Two section cooking grid measures 25
Full width floating drip pan drains into a large capacity grease
collector.
Finishing oven above broiler with manual heat control
measuring 28"w x 20"d x 13"h.
Standard oven: 40,000 BTU/hr. burner with pilot ignition.
Porcelain enamel on steel oven hearth, rear panel and door
liner. One oven rack with four positions. Thermostat adjusts
from 250° to 500°F. Oven controls located in the cool zone.
Counterbalanced oven door. Oven interior measures 27
1 1
28 / "d x 14 / "h.
2 2
One year limited parts and labor warranty.
OPTIONS
Stainless steel side(s).
Stainless steel finishing back.
Electronic ignition.
Common stainless steel front top ledge up to 96" wide.
(Drawing required showing the position of each piece of
equipment.)
Cap and cover manifold end(s).
Leveling bolts in place of legs for curb mounting.
Stainless steel dolly frame with casters, up to 72" wide.
Rear gas connection.
1
lator) or 1 / "
4
ACCESSORIES
Set of four 5" diameter casters, two locking.
1 1 / " gas pressure regulator.
4
Flexible gas hose with quick disconnect and restraining
device. Consult price book for available sizes.
C.S.I. Section 11420
1 1
/ " x 25 /
2
1 /
Left Right
Left Right
3 / " (includes gas pressure regu-
4
".
2
"w x
2
