ELECTRIC SALAMANDER BROILER
MODEL
VB73
VB73R
ESB36
ESB48
ESB60
For additional information on Vulcan-Hart or to locate an authorized
parts and service provider in your area, visit our website at www.vulcanhart.com
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
ML-52249
ML-52248
ML-52462
ML-52468
ML-52463
REPLACEMENT PARTS
P.O. BOX 696, LOUISVILLE, KY 40201-0696
CATALOG OF
MODEL VB73
TEL. (800) 814-2028
FORM 30906 Rev. A (09-06)
Advertisement
Related Manuals for Vulcan-Hart ESB36
Summary of Contents for Vulcan-Hart ESB36
-
Page 1: Replacement Parts
ESB36 ML-52462 ESB48 ML-52468 ESB60 ML-52463 For additional information on Vulcan-Hart or to locate an authorized parts and service provider in your area, visit our website at www.vulcanhart.com VULCAN-HART DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC WWW.VULCANHART.COM CATALOG OF REPLACEMENT PARTS MODEL VB73 P.O. - Page 2 VB & ESB SERIES REPLACEMENT PARTS ILLUS. PART PL-22336A 00-412251-00001 Knob - Infinite Switch (208 - 240 V.) ... 2 00-411503-00003 Switch - Infinite (208 V.) ... 2 00-411503-00002 Switch - Infinite (240 V.) ... 2 00-407727-00002 Knob - Three Heat Switch (480 V.) ... 1 00-355798-00001 Switch (480 V.) ...
- Page 3 ILLUS. PART PL-22337 00-410498-00004 Element - Electric Heat (L.H.)(208 V.) ... 1 00-410498-00006 Element - Electric Heat (R.H.)(208 V.) ... 1 00-410498-00003 Element - Electric Heat (L.H.)(240 V.) ... 1 00-410498-00005 Element - Electric Heat (R.H.)(240 V.) ... 1 00-410498-00001 Element - Electric Heat (L.H.)(480 V.) ... 1 00-410498-00002 Element - Electric Heat (R.H.)(480 V.) ...
- Page 4 VB & ESB SERIES REPLACEMENT PARTS ILLUS. PART PL-22109 00-408689-00001 Grid - Broiler ... 1 00-408709-00001 Pan - Drip ... 1 00-409962-00001 Pan - Grease Collector ... 1 BROILER GRID & DRIP PAN NAME OF PART – 4 – – 4 – AMT.
-
Page 5: Recommended Spare Parts List
REPLACEMENT PARTS VB & ESB SERIES RECOMMENDED SPARE PARTS LIST PART NAME OF PART AMT. 00-410498-00006 Right Element 208V ... 2 00-410498-00005 Right Element 240V ... 2 00-410498-00002 Right Element 480V ... 2 00-410498-00004 Left Element 208V ... 2 00-410498-00003 Left Element 240V ... 2 00-410498-00001 Left Element 480V ...
