Owner's
Manual
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following number :
Model#: 50-1750
STAMINA PRODUCTS
MADE IN CHINA
©
2010 Stamina Products, Inc.
2010, 09
Advertisement
Table of Contents
Related Manuals for Stamina 1750 Power Tower System
Summary of Contents for Stamina 1750 Power Tower System
- Page 1 CAUTION: Weight on this product should not exceed 250 lbs. This Product is Produced Exclusively by STAMINA PRODUCTS MADE IN CHINA 2040 N. Alliance, Springfield, MO 65803 Customer Service © 2010 Stamina Products, Inc. 1 (800) 375-7520 2010, 09 www.staminaproducts.com...
-
Page 2: Table Of Contents
Meijer.com OPERATIONAL INSTRUCTIONS TABLE OF CONTENTS Safety Instructions ........2 Conditioning Guidelines ......16 Before You Begin ........4 Warm-Up and Cool-Down ......17 Equipment Warning, Caution & Notice Labels ... 5 Workout Instructions ........ 18 Hardware Identification Chart ....6 Product Parts Drawing ...... -
Page 3: Customer Service
Monday - Thursday, 7:30 A.M. - 5:00 P.M., Central Time. Friday, 8:00 A.M. - 3:00 P.M., Central Time. TELEPHONE ONLINE MAIL CUSTOMER SERVICE CUSTOMER SERVICE CUSTOMER SERVICE STAMINA PRODUCTS, INC. Tel: 1 (800) 375-7520 Fax: (417) 889-8064 customerservice@staminaproducts.com ATTN: Customer Service www.staminaproducts.com P.O. Box 1071 Springfield, MO. 65801-1071... -
Page 4: Before You Begin
Read this manual carefully before using the Be sure to have the name and model number of 1750 Power Tower. the product available when you contact us. Although Stamina constructs its products with the finest materials and uses the highest standards Pull-Up Bar Upper Upright... -
Page 5: Equipment Warning, Caution & Notice Labels
Meijer.com EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the 1750 Power Tower. Please take a moment to familiarize yourself with all of the warning, caution, and notice labels. -
Page 6: Hardware Identification Chart
Meijer.com HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws. -
Page 7: Assembly Instructions
Meijer.com ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed. - Page 8 Meijer.com ASSEMBLY INSTRUCTIONS STEP 3 Insert the two SUPPORT BARS(4) between the BASE FRAMES(1) and the LOWER UPRIGHTS(3), then secure at top and bottom to the BASE FRAMES(1) and the LOWER UPRIGHTS(3) with HEX BOLTS(M8x1.25x70mm)(29), WASHERS(M8)(37), and NYLOCK NUTS(M8x1.25)(34). STEP 4 Insert the two UPPER UPRIGHTS(11) into the LOWER UPRIGHTS(3) and secure with HEX BOLTS (M10x1.5x65mm)(32), WASHERS(M10)(38), and NYLOCK NUTS(M10x1.5)(35).
- Page 9 Meijer.com ASSEMBLY INSTRUCTIONS STEP 6 Connect the two EXTEND ARMS(8) with the CONNECTING BRACE(10) and secure with the MOUNTING BRACKETS(6), HEX BOLTS(M10x1.5x70mm)(33), WASHERS(M10)(38), and NYLOCK NUTS(M10x1.5)(35). STEP 7 Attach the EXTEND ARM ASSEMBLY(8) to the LOWER UPRIGHTS(3) and the UPPER UPRIGHTS(11) with the LARGE MOUNTING BRACKETS(7), HEX BOLTS(M10x1.5x70mm)(33), WASHERS(M10)(38), and NYLOCK NUTS(M10x1.5)(35).
- Page 10 Meijer.com ASSEMBLY INSTRUCTIONS STEP 9 Attach the ARM CUSHIONS(13) to the EXTEND ARMS(8) with HEX BOLTS(M8x1.25x65mm)(28) and WASHERS(M8)(37). STEP 10 Attach the BACK CUSHION(14) to the CONNECTING BRACE(10) with HEX BOLTS(M8x1.25x20mm) (27) and WASHERS(M8)(37).
- Page 11 Meijer.com ASSEMBLY INSTRUCTIONS STEP 11 Attach the BENCH EXTEND ARMS(42) to the FOAM SUPPORT BAR(5) with HEX BOLTS (M10x1.5x115mm)(56), WASHERS(M10)(38), and NYLOCK NUTS(M10)(35). Do not tighten the bolts until STEP 12. STEP 12 Attach the REAR SUPPORT(40) to the BENCH EXTEND ARMS(42) with HEX BOLT(M10x1.5x115mm) ( 5 6 ) , WA S H E R S ( M 1 0 ) ( 3 8 ) , a n d N Y L O C K N U T ( M 1 0 ) ( 3 5 ) .
- Page 12 Meijer.com ASSEMBLY INSTRUCTIONS STEP 13: Refer to the detail view 1. Attach the SUPPORT LEG(41) to the REAR SUPPORT(40) with HEX BOLT (M8x1.25x70mm)(29), WASHERS(M8)(37), and NYLOCK NUT(M8)(34). NOTE: Do not over tighten HEX BOLTS(32, 57) as the BRACE TUBES(43, 44), BRACE SUPPORT(45), and CONNECTING BRACKET(46) must be able to pivot smoothly after HEX BOLTS(32, 57) are tightened.
- Page 13 Meijer.com ASSEMBLY INSTRUCTIONS STEP 16 Attach the BENCH CUSHION(47) to the LEFT and RIGHT BRACE TUBES(43, 44) with HEX BOLTS(M6x1x15mm)(55) and WASHERS(M6)(58).
-
Page 14: Operational Instructions
Meijer.com OPERATIONAL INSTRUCTIONS SWITCH THE BENCH The Bench is preset under the PULL-UP BAR(12). You will need to fold and switch the Bench to other side when you want to do the pull-up workout. Follow the process below to switch the Bench: 1. -
Page 15: Storage
Power Tower is regularly examined for damage and wear. Special attention should be given to the following: 1. Verify that the CAUTION LABEL(39) is in place and easy to read. Call Stamina Products immediately at 1-800-375-7520 for a replacement CAUTION LABEL(39) if it is missing or damaged. -
Page 16: Conditioning Guidelines
Meijer.com CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs. -
Page 17: Warm-Up And Cool-Down
Meijer.com WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place Stretching Stretching while your muscles are warm after a proper warm-up and again after your... -
Page 18: Workout Instructions
Meijer.com WORKOUT INSTRUCTIONS Dips: A variation can be to lower yourself from the start position to only halfway down. Start Finish Push-ups: A variation can be to lower yourself from the start position to only halfway down. Start Finish Lat Pull-ups: Variations can include using a medium or narrow grip. - Page 19 Meijer.com WORKOUT INSTRUCTIONS Vertical Knee Raise: Variations can include alternately raising each leg or bringing the legs up in a twisting motion. Start Finish Sit-ups: A variation can be to twist your torso as you sit up.
-
Page 20: Product Parts Drawing
Meijer.com PRODUCT PARTS DRAWING BACK FRONT... -
Page 21: Parts List
Meijer.com PARTS LIST PART# PART NAME Base Frame Cross Bar Lower Upright Support Bar Foam Support Bar Mounting Bracket Large Mounting Bracket Extend Arm Extend Arm Support Connecting Brace Upper Upright Pull-Up Bar Arm Cushion Back Cushion Foam Grip (ø30 x ø38 x 165mm) Foam Tube (ø22 x ø32 x 140mm) Foam Tube (ø22 x ø32 x 265mm) Foam Tube (ø22 x ø32 x 445mm) -
Page 22: Warranty
To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071, or email us at customerservice@staminaproducts.com, or call us at 1-800-375-7520. -
Page 23: Fax/Mail Ordering Form
Meijer.com FAX/MAIL ORDERING FORM Please do not return the product. For your convenience, Stamina's Customer Service Department can be reached by email at customerservice@staminaproducts.com or toll free at 1-800-375-7520 (in the U.S.). Should a part be missing or a defective part found, please call us from 7:30 A.M. to 5:00 P.M. Central Time, Monday through Thursday and 8:00 A.M.
