ASSEMBLY

To hire an authorized service technician to assemble the elliptical, call 1-800-445-2480.
Assembly requires two persons. Place all parts of the elliptical in a cleared area and remove the packing
materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver , an adjustable
wrench , and a rubber mallet .
Use the drawings below to identify small parts. The number in parentheses below each drawing is the key num-
ber of the part, from the PART LIST near the end of this manual. The number following the parentheses is the
quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it has been pre-
assembled.
M4 Split
M4
M8 Split
Washer Washer
M8 Jam Nut M10 Locknut
M8 Washer
Wave Washer
Washer
(102)–8
(79)–5 (81)–2
(112)–8
(88)–6
(111)–2
(90)–3
M4 x 16mm M4 x 32mm
M4 x 16mm
Round Head Round Head
Blunt Screw M4 x 47mm Screw
Screw (101)–8 Screw (105)–6
(104)–8 (108)–2
M8 x 23mm Shoulder M8 x 41mm Button
M8 x 23mm Button
Hub Screw (87)–8
Screw (115)–4 Screw (84)–4 Bolt (78)–4
M8 x 69mm Button M10 x 80mm Carriage
Bolt (80)–1 Bolt (82)–2
M10 x 127mm Button Screw (83)–2
