www.nordictrack.com
USER'S MANUAL
Model No. NTL14011.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts
are damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-800-TO-BE-FIT
(1-800-862-3348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.nordictrackservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Advertisement
Table of Contents
Related Manuals for NordicTrack NTL14011.0
Summary of Contents for NordicTrack NTL14011.0
- Page 1 USER’S MANUAL Model No. NTL14011.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care.
-
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decals may not be shown at actual size. NORDICTRACK is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
14. To informed of all warnings and precautions. purchase a surge suppressor, see your local NORDICTRACK dealer, call the telephone 3. Use the treadmill only as described. number on the front cover of this manual, or see your local electronics store. - Page 4 DANGER: 20. Never leave the treadmill unattended while Always unplug the power it is running. Always remove the key, unplug cord immediately after use, before clean- the power cord, and press the power switch ing the treadmill, and before performing the into the off position when the treadmill is not maintenance and adjustment procedures in use.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK COMMERCIAL 1750 treadmill. The manual. To help us assist you, please note the product ® COMMERCIAL 1750 treadmill offers an impressive model number and serial number before contacting us. -
Page 6: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly. -
Page 7: Assembly
ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 6. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing materials until you finish all assembly steps. •... - Page 8 3. Identify the Left Upright (89), which is marked “Left.” Have a second person hold the Left Upright near the Base (97). See the inset drawing. Tie the wire tie in the Left Upright (89) securely around the end of the Wire Upright Wire (84).
- Page 9 5. Identify the Left and Right Base Covers (92, 93). Slide the Left Base Cover onto the Left Upright (89). Slide the Right Base Cover onto the Right Upright (90). Do not press the Base Covers into place yet. 6. With the help of a second person, hold the con- sole assembly near the Left Upright (89).
- Page 10 7. Insert the wires into the Left Upright (89) as you set the console assembly on the Left Upright and the Right Upright (90). Be careful not to Console pinch the Upright Wire (84). Assembly Attach the console assembly with four 5/16" x 1 1/2"...
- Page 11 9. Firmly tighten the four 3/8" x 2 3/4" Screws (7), and then tighten the four 3/8" x 1 1/4" Screws (8) (only one side is shown). Press the Left and Right Base Covers (92, 93) onto the Base (97) until they snap into place. 10.
- Page 12 11. Attach the upper end of the Storage Latch (53) to the Frame (56) with a 3/8" x 1 3/4" Bolt (6) and a 3/8" Nut (11). Note: It may be necessary to move the Frame (56) back and forth to align the Storage Latch with the Frame.
-
Page 13: The Chest Heart Rate Monitor
THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR • Do not expose the heart rate monitor to direct sunlight for extended periods of time; do not expose The heart rate it to temperatures above 122° F (50° C) or below 14° monitor consists of F (-10°... -
Page 14: Operation And Adjustment
OPERATION AND ADJUSTMENT HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same circuit. - Page 15 CONSOLE DIAGRAM FEATURES OF THE CONSOLE As you exercise, the console will display instant exer- cise feedback. You can also measure your heart rate The treadmill console offers an impressive array of using the handgrip heart rate monitor or the chest heart features designed to make your workouts more effec- rate monitor.
- Page 16 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the treadmill has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you become perature before you turn on the power.
- Page 17 HOW TO SET UP THE CONSOLE Next, enter a username and password and your e-mail address. Enter the activation code from the Before using the treadmill for the first time, set up the iFit Live flier that came with the treadmill. Touch console.
- Page 18 HOW TO USE THE MANUAL MODE Each time you press one of the buttons, the incline will gradually change until it reaches the selected 1. Insert the key into the console. incline setting. See HOW TO TURN ON THE POWER on page Note: The first time you adjust the incline, you must 16.
- Page 19 7. Turn on the fan if desired. If desired, adjust the Increase volume by pressing the volume increase and The fan features multiple decrease buttons on the speed settings and an console. auto mode. When the auto mode is selected, the speed of the fan will Decrease automatically increase...
- Page 20 HOW TO USE AN ONBOARD WORKOUT If the speed or incline setting is too high or too low at any time during the workout, you can override 1. Insert the key into the console. the setting by pressing the Speed or Incline but- tons;...
- Page 21 HOW TO USE A SET-A-GOAL WORKOUT The workout will function in the same way as the manual mode (see pages 18 and 19). 1. Insert the key into the console. The workout will continue until you reach the goal See HOW TO TURN ON THE POWER on page that you set.
- Page 22 HOW TO USE AN IFIT LIVE WORKOUT Before some workouts will download, you must add them to your schedule on iFit.com. Note: To use an iFit Live workout, you must have For more information about the iFit Live work- access to a wireless network (see HOW TO USE THE outs, please see www.iFit.com.
- Page 23 HOW TO USE THE EQUIPMENT SETTINGS MODE reset position, and insert the key into the console. However, when you remove the key, the screen will The console features an equipment settings mode show a demo presentation. that allows you to select a language and the unit of measurement, to turn on and turn off the display demo To turn on or turn off the display demo mode, first mode, and to enable or disable the key.
- Page 24 HOW TO USE THE MAINTENANCE MODE The screen will show the progress of the update. When the update is complete, the treadmill will turn The console features a maintenance mode that allows off and then turn back on. If it does not, press the you to update the console firmware, calibrate the power switch into the off position.
- Page 25 HOW TO USE THE WIRELESS NETWORK MODE An information box will ask if you want to connect to the wireless network. Touch the Connect button The console features a wireless network mode that to connect to the network or touch the Cancel but- allows you to set up a wireless network connection.
- Page 26 HOW TO USE THE STEREO SOUND SYSTEM HOW TO USE THE INTERNET BROWSER To play music or audio books through the console’s Note: To use the browser, you must have access to a speakers, you must connect your MP3 player, CD wireless network including an 802.11b/n router with player, or other personal audio player to the console.
-
Page 27: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the Before moving the treadmill, fold it as described at the incline to 0 percent before you fold the treadmill. left. -
Page 28: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following c. Remove the key from the console, and then the simple steps below. Find the symptom that reinsert it. applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual. d. - Page 29 SYMPTOM: The walking belt slows when walked on Lower the treadmill (see HOW TO LOWER THE TREADMILL FOR USE on page 27). Remove the three #8 x 3/4" Screws (1). Carefully pivot the Motor a. Use only a surge suppressor that meets all of the Hood (71) off.
- Page 30 SYMPTOM: The walking belt is off-center or slips SYMPTOM: The iFit Live mode does not function when walked on correctly a. If the walking belt is off-center, first remove the a. If the iFit Live mode is not functioning correctly, key and UNPLUG THE POWER CORD.
-
Page 31: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. -
Page 32: Suggested Stretches
SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible. - Page 33 NOTES...
-
Page 34: Part List
PART LIST Model No. NTL14011.0 R1111A Key No. Qty. Description Key No. Qty. Description #8 x 3/4" Screw Reed Switch Clamp 5/16" x 3 3/4" Screw Reed Switch 3/8" x 2" Bolt Storage Latch 5/16" x 2" Screw Drive Motor 5/16"... - Page 35 Key No. Qty. Description Key No. Qty. Description Wheel Pulse Bar Bottom Console Base 1/2" Rear Leveling Foot Nut Console Hex Key Console Back 3/8" Flat Washer Fan Assembly #8 x 3/8" Screw Handrail Spacer #8 x 1 1/4" Screw Console Frame Bumper Pulse Bar Top...
-
Page 36: Exploded Drawing
EXPLODED DRAWING A Model No. NTL14011.0 R1111A... - Page 37 EXPLODED DRAWING B Model No. NTL14011.0 R1111A...
- Page 38 EXPLODED DRAWING C Model No. NTL14011.0 R1111A 101 113...
- Page 39 EXPLODED DRAWING D Model No. NTL14011.0 R1111A...
-
Page 40: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
