Model No. NTL14122-INT.3
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
MEMBER CARE
UNITED KINGDOM
Website: iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
iFIT Inc.
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL
iconeurope.com

Advertisement

Table of Contents
loading

Related Manuals for NordicTrack NTL14122-INT.3

Summary of Contents for NordicTrack NTL14122-INT.3

  • Page 1 Model No. NTL14122-INT.3 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal MEMBER CARE UNITED KINGDOM Website: iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4, Westgate Court Silkwood Park...

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at actual size. 305284 NORDICTRACK and IFIT are registered trademarks of iFIT Inc. The Bluetooth word mark and logos are ® registered trademarks of Bluetooth SIG, Inc. and are used under license. Google Maps is a trademark of Google...

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. iFIT assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 20. When a person is walking on the treadmill, 26. Do not change the incline of the treadmill by the noise level of the treadmill will increase. placing objects under the treadmill. 21. Keep fingers, hair, and clothing away from 27.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new NORDICTRACK reading this manual, please see the front cover of this ® COMMERCIAL 1750 treadmill. The COMMERCIAL manual. To help us assist you, note the product model 1750 treadmill provides an impressive selection of fea- number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 6. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex keys materials until you finish all assembly steps.
  • Page 8 2. Make sure that the power cord is unplugged. Identify the Right Upright (114), and lay it near the Base (118) as shown. Next, connect the Belly Pan Wire (96) to the Upright Wire (120) in the Right Upright (114). The connectors should slide together eas- ily and snap into place with an audible click.
  • Page 9 4. Do not pinch the Wires (119, 120) during this step. With the help of a second person, hold the handrail assembly (D) on the Left and Right Uprights (113, 114). Attach the handrail assembly with four 3/8" x 2 3/4" Screws (2) and four 3/8"...
  • Page 10 6. Identify the Right Inner Grip (102), and attach it to the right side of the handrail assembly (D) with four #8 x 3/4" Screws (4); start all four Screws, and then tighten them. Do not overtighten the Screws. Attach the Left Inner Grip (101) to the left side of the handrail assembly (D) in the same way.
  • Page 11 8. Have a second person hold the console assem- bly (E) near the handrail assembly (D). Connect the wires (F) from the console assembly (E) to the wires (G) from the handrail assembly (D). The connectors should slide together easily and snap into place with an audible click.
  • Page 12 10. Rotate the console assembly (E) back to its original position. Firmly tighten the two M6 x 25mm Screws (8) that you attached in step 8. Next, identify the Right Pivot Cover (137). Attach the Right Pivot Cover to the Console Pivot Bracket (138) with an M4 x 20mm Screw (6);...
  • Page 13 12. Note: If the treadmill is assembled on a smooth surface, it may roll forward during this step. Raise the Frame (74) to the position shown. IMPORTANT: Do not raise the Frame past the vertical position. Have a second person hold the Frame until step 14 is completed.
  • Page 14 14. Remove the 5/16" Nut (49) and the 5/16" x 2 1/4" Bolt (27) from the bracket on the Latch Crossbar (76). 49 K Next, align the upper end of the Storage Latch (75) with the bracket on the Latch Crossbar (76), and insert the 5/16"...
  • Page 15 16. See HOW TO PLUG IN THE POWER CORD on page 16, and plug in the power cord. Then, see HOW TO USE THE MANUAL MODE on page 20, and adjust the incline of the treadmill to 10%. Next, identify the Right Base Cover (121). Position the large cutout (I) in the Right Base Cover around the Right Upright (114), and slide the Right Base Cover downward onto the Base...

  • Page 16: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord (A) into the tion or break down, earthing provides a path of least socket on the treadmill (B).
  • Page 17 CONSOLE DIAGRAM workouts, record your workout results, set and track FEATURES OF THE CONSOLE fitness goals, and access many other features. The advanced treadmill console offers a selection of features designed to make your workouts more effec- When you use the manual mode of the console, you tive and enjoyable.
  • Page 18 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN The console features a tablet with a full-color touch IMPORTANT: If the treadmill has been exposed to screen. The following information will help you become cold temperatures, allow it to warm to room tem- familiar with the tablet’s advanced technology: perature before you turn on the power.
  • Page 19 HOW TO SET UP THE CONSOLE 5. Calibrate the incline system. Before using the treadmill for the first time, set up the First, touch the menu button (three horizontal lines symbol), touch Settings, touch Maintenance, touch console. Calibrate Incline, and then touch Begin to calibrate the incline system.
  • Page 20 HOW TO USE THE MANUAL MODE Note: If the walking belt is moving at a high speed and you adjust the incline below 0%, the 1. Insert the key into the console. speed of the walking belt may automatically decrease. See HOW TO TURN ON THE POWER on page 18.
  • Page 21 6. Turn on the fan if desired. HOW TO USE A FEATURED WORKOUT The fan has several Note: To use a featured workout, the console must speed settings, including be connected to a wireless network (see HOW TO an auto mode. While the CONNECT TO A WIRELESS NETWORK on page 27).
  • Page 22 To end the workout, touch the screen to pause the 4. Start the workout. workout, and then follow the prompts on the screen Touch Start Workout to start the workout. to end the workout and return to the home screen. During some workouts, an iFIT coach will guide When the workout ends, a workout summary will you through a video workout.
  • Page 23 If you make a mistake, you can touch Undo. HOW TO CREATE A DRAW-YOUR-OWN-MAP WORKOUT The screen will display the elevation and distance Note: To create a draw-your-own-map workout, the for your workout. If desired, you can change the console must be connected to a wireless network (see default speed.
  • Page 24 HOW TO USE AN IFIT WORKOUT 4. Select an iFIT workout from the home screen or the workout library. To use an iFIT workout, the console must be connected to a wireless network (see HOW TO CONNECT TO A Touch the buttons at the bottom of the screen to WIRELESS NETWORK on page 27).
  • Page 25 6. Create a list of favorite iFIT workouts if desired. HOW TO CHANGE CONSOLE SETTINGS To mark an iFIT workout as a favorite, simply view IMPORTANT: Some of the settings and features the overview or workout summary of the desired described may not be enabled.
  • Page 26 Note: Occasionally, a firmware update may cause 3. Customize the time zone and other settings. the console to function slightly differently. These To customize the time zone or other settings, touch updates are always designed to improve your Equipment Settings and then touch the desired exercise experience.
  • Page 27 To disconnect from a wireless network, touch and HOW TO CONNECT TO A WIRELESS NETWORK hold the name of the wireless network and then The console is Wi-Fi enabled, allowing you to set up a touch Forget. ® wireless network connection. If you are having problems connecting to an encrypted network, make sure that your password 1.

  • Page 28: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL Before moving the treadmill, fold it as described at the To avoid damaging the treadmill, adjust the incline left. CAUTION: Make sure that the storage latch to zero before you fold the treadmill.

  • Page 29: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The power turns off during use Regular maintenance is important for optimal a. Check the power switch (see drawing c at the left). performance and to reduce wear. Inspect and If the switch has tripped, wait for five minutes and properly tighten all parts each time the treadmill is then press the switch back in.
  • Page 30 c. Your treadmill features a walking belt coated with SYMPTOM: The walking belt slows when walked on high-performance lubricant. IMPORTANT: Never a. If an extension cord is needed, use only a 3-conduc- apply silicone spray or other substances to tor, 14-gauge (2 mm ) cord that is no longer than the walking belt or the walking platform unless 5 ft.
  • Page 31 SYMPTOM: The walking belt slips when walked on SYMPTOM: The displays of the console do not function properly a. First, remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. If the console does not boot up properly, or screws clockwise, 1/4 of a turn.

  • Page 32: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.
  • Page 33 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 34: Part List

    PART LIST Model No. NTL14122-INT.3 R0222A Key No. Qty. Description Key No. Qty. Description 3/8" x 1 1/4" Screw Clip 3/8" x 2 3/4" Screw M25 Nut Incline Stop Bracket M10 Nut #8 x 3/4" Screw 1/2" Plastic Bushing Ground Screw...
  • Page 35 Key No. Qty. Description Key No. Qty. Description Left Inner Grip Lower Console Cover Right Inner Grip Console Back Plate Right Outer Grip Saddle Bracket Right Upright Inner Cover Pivot Cover Right Inner Console Base Cover Console Left Handrail Right Handrail Pivot Front Cover Console Crossbar Pivot Back Cover...

  • Page 36: Exploded Drawing

    EXPLODED DRAWING A Model No. NTL14122-INT.3 R0222A...
  • Page 37 EXPLODED DRAWING B Model No. NTL14122-INT.3 R0222A...
  • Page 38 EXPLODED DRAWING C Model No. NTL14122-INT.3 R0222A...
  • Page 39 EXPLODED DRAWING D Model No. NTL14122-INT.3 R0222A...

  • Page 40: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
