PRECAUTIONS

R WARNING HIGH VOLTAGE! NEVER
an antenna or internal antenna connector while trans-
mitting. This may result in an electrical shock or burn.
R WARNING HIGH VOLTAGE! NEVER
the antenna in a place where a person could easily
touch the antenna while transmitting. This could result
in an electrical shock or burn.
R WARNING! NEVER
receptacle on the repeater rear panel. This could
cause a fire or damage the repeater.
R WARNING! NEVER
such as a 24 V battery, to the DC power receptacle
on the repeater rear panel. This could cause a fire or
damage the repeater.
CAUTION: NEVER
let metal, wire or other objects
touch any internal part or connectors on the rear panel
of the repeater. This may result in an electric shock.
CAUTION: NEVER
expose the repeater to rain,
snow or any liquids.
DO NOT
use or place the repeater in areas with tem-
peratures below -25°C or above +55°C. Be aware that
temperatures can exceed +80°C, resulting in perma-
nent damage to the repeater if left there for extended
periods.
DO NOT
place the repeater in excessively dusty en-
vironments or in direct sunlight.
DO NOT
put anything on top of the repeater. This will
obstruct heat dissipation.
Place the repeater in a secure place to avoid inadver-
tent use by children.
BE CAREFUL:
The heatsink will become hot when
operating the repeater continuously for long periods.
BE CAREFUL:
If a linear amplifier is connected,
set the repeater's RF output power to less than the
linear amplifier's maximum input level, otherwise, the
linear amplifier will be damaged.
USE
only the specified microphone. Other micro-
phones have different pin assignments and may dam-
age the repeater.
Place the repeater in a secure place to avoid inadver-
tent access by children.
Icom, Icom Inc. and the Icom logo are registered trademarks
of Icom Incorporated (Japan) in Japan, the United States,
the United Kingdom, Germany, France, Spain, Russia and/or
other countries.
attach
install
apply AC to the DC power
apply more than 16 V DC,

VOICE CODING TECHNOLOGY

The AMBE+2™ voice coding Technology embodied in this
product is protected by intellectual property rights including
patent rights, copyrights and trade secrets of Digital Voice
Systems, Inc. This voice coding Technology is licensed
solely for use within this Communications Equipment. The
user of this Technology is explicitly prohibited from attempt-
ing to extract, remove, decompile, reverse engineer, or
disassemble the Object Code, or in any other way convert
the Object Code into a human-readable form. U.S. Patent
Nos. #5,870,405, #5,826,222, #5,754,974, #5,701,390,
#5,715,365, #5,649,050, #5,630,011, #5,581,656,
#5,517,511, #5,491,772, #5,247,579, #5,226,084 and
#5,195,166.

TABLE OF CONTENTS

IMPORTANT ............................................................... i
FORWARD ................................................................. i
EXPLICIT DEFINITIONS ............................................ i
SUPPLIED ACCESSORIES....................................... i
COUNTRY CODE LIST .............................................. i
PRECAUTIONS ......................................................... ii
VOICE CODING TECHNOLOGY .............................. ii
TABLE OF CONTENTS ............................................ ii
1 PANEL DESCRIPTION..................................... 1-4
■ Front panel ........................................................ 1
D Function display ............................................ 2
■ Rear panel ......................................................... 2
D Accessory connector .................................... 3
D I/O connector (for the PA unit) ....................... 4
2 INSTALLATION AND CONNECTIONS ............ 5-7
■ Unpacking ......................................................... 5
■ Selecting a location ........................................... 5
■ Grounding ......................................................... 5
■ Antenna connection .......................................... 5
■ Front panel connection ...................................... 6
■ Rear panel connection-
For the IC-FR5100H/IC-FR6100H ..................... 6
■ Rear panel connection-
For the IC-FR5100/IC-FR6100 .......................... 7
■ Power supply connection .................................. 7
■ Mounting the repeater ....................................... 7
D Using the supplied handle ............................. 7
3 OPERATION ......................................................... 8
■ Receiving and transmitting ................................ 8
D Repeater operation ....................................... 8
D Base station operation .................................. 8
4 MAINTENANCE ................................................... 9
■ Troubleshooting ................................................. 9
■ Fuse replacement ............................................. 9
D Line fuse replacement ................................... 9
5 OPTIONS ............................................................ 10
6 ABOUT CE ................................................... 11-12
