Autopage C3-RS-915 LCD Operation Manual

Professional 2-way lcd remote car starter & alarm system with built in temperature & voltage sensor and two-way serial port data link
Hide thumbs
Table of Contents

Advertisement

Quick Links

http://www.msvmaster.lv
SVMASTER
-
-
C3-RS-915 LCD
PROFESSIONAL 2-WAY LCD REMOTE CAR STARTER & ALARM
SYSTEM
With
Built in Temperature & Voltage Sensor
And Two-way Serial Port Data Link
Compatible
OPERATION MANUAL
Please register your product at:
www.autopageusa.com
THIS PRODUCT IS DESIGNED FOR PROFESSIONAL INSTALLATION ONLY
http://www.msvmaster.lv
SVMASTER
-
-
1

Advertisement

Table of Contents
loading

Related Manuals for Autopage C3-RS-915 LCD

Summary of Contents for Autopage C3-RS-915 LCD

  • Page 1 SVMASTER C3-RS-915 LCD PROFESSIONAL 2-WAY LCD REMOTE CAR STARTER & ALARM SYSTEM With Built in Temperature & Voltage Sensor And Two-way Serial Port Data Link Compatible OPERATION MANUAL Please register your product at: www.autopageusa.com THIS PRODUCT IS DESIGNED FOR PROFESSIONAL INSTALLATION ONLY http://www.msvmaster.lv...

  • Page 2: Battery Charging

    http://www.msvmaster.lv SVMASTER Congratulations on your purchase of the RS-915 LCD remote start vehicle security system. We sincerely hope the purchase of the RS-915 remote start security system gives peace of mind to you. The RS-915 LCD is a state-of-the-art two-way communication system. Please take the time to read over this manual to thoroughly familiarize your self with the many features and options of the RS-915 LCD.

  • Page 3: Standard Lcd Icon Configurations

    http://www.msvmaster.lv SVMASTER B. STANDARD LCD ICON CONFIGURATIONS: The lock icon will be displayed when The unlock icon will be displayed when the door locked. the door unlock Sensor Bypass Hidden Alarm Mode Sensor 1 bypass under Arm mode The security system arm with hidden alarm function (silent alarm) Valet Mode Remote start and alarm functions shall...

  • Page 4: Buttons & Functions

    http://www.msvmaster.lv SVMASTER OPERATION: REMOTE TRANSMITTER OPERATION: Transmitter System Function Remark Button Lock Doors & Arm System Press and Hold for 3 seconds. Press Trunk Panic function button to stop panic function Car Locator Press when in armed mode Arm and Delete The 2 Stage Shock Press twice within 3 seconds.

  • Page 5: Active Arming - Lock & Arm

    http://www.msvmaster.lv SVMASTER E. ACTIVE ARMING – LOCK & ARM: button 1. Press on the transmitter. The siren will chirp once and parking light will flash once indicating that the system is now armed. The vehicle’s doors will lock upon arming if interfaced with the security system. DEFECTIVE SENSOR REMINDER: If the siren sounds 3 chirps, then you have left a door, trunk, or hood lid ajar.

  • Page 6: Disarming Without A Transmitter

    http://www.msvmaster.lv SVMASTER TWO STEPS DOOR UNLOCK (Optional): This feature will independently unlock the driver’s door only when disarming the security system. Pushing the button a second time within 3 seconds will unlock the other doors. AUTOMATIC RE-ARM: If this feature is selected, the security system will automatically re-arm itself in 60 seconds after disarming with remote transmitter.

  • Page 7: Car Locator

    http://www.msvmaster.lv SVMASTER Get into/out valet mode using the ignition key. Enter Valet Mode: a). Under disarm mode, turn the ignition to “ON” position. b). Press and hold valet switch for 2 seconds until the LED turns ON solid. The LED will remain on as long as the system is in 'valet mode'.

  • Page 8: System's Trigger Check

    http://www.msvmaster.lv SVMASTER Under ignition ON, press and hold the buttons at the same time for 2 seconds. The parking lights will turn on for 1.5 seconds to indicate the system has entered the anti car-jacking mode. 2. Once the system in anti car-jacking mode, the system will be triggered when any door is opened and closed while the ignition is “ON”.
  • Page 9 http://www.msvmaster.lv SVMASTER R. IGNITION CONTROL DOOR LOCK/UNLOCK. (Programmable Feature) If the vehicles door locks have been interfaced to the security system, the system will automatically lock the vehicle's doors when the ignition is turned “ON” and /or unlock the vehicle’s doors when the ignition is turned “OFF”.
  • Page 10 http://www.msvmaster.lv SVMASTER 3. While the LED is illuminated, press any button on the remote control transmitter to control a second vehicle security system. For LCD transceiver – 2 car operation : a. Press and hold button of LCD remote for 1 second until 2 beeps sound and then release the button.

  • Page 11: Temporary Stop Feature

    http://www.msvmaster.lv SVMASTER 2. Press the brake pedal. Note: If the brake pedal is pressed before the key is in the ON position, the engine will shut down. C. TEMPORARY STOP FEATURE: This feature allows the vehicle to remain running after the key has been removed from the ignition. This feature is useful for occasions when you wish to exit and lock the vehicle for short periods of time, but would like to leave the motor running and the climate control on.

  • Page 12: To Turn Off The Remote Start

    http://www.msvmaster.lv SVMASTER be shown on the LCD screen. This reading may be higher than actual ambient temperature due to the greenhouse effect and is relative only to the inside vehicle temperature. G. TO TURN OFF THE REMOTE START: When the engine is running (by remote start), if you want to stop it, 1.

  • Page 13: Hidden Alarm

    http://www.msvmaster.lv SVMASTER ADVANCED USER’S MODE: C. LCD REMOTE CONTROL TRANSCEIVER OPERATION: Enter: Press and hold Button until beep sound respond from LCD transceiver indicate into table 1 – 5 as below. Exit: Press the button to exit this mode. Table 1: ONE beep to confirm (Press and hold until ONE Beep is heard) Button LCD Display Button...

  • Page 14: Programming Lcd Remote

    http://www.msvmaster.lv SVMASTER times within 5 seconds icon flashing Temperature of the vehicle Press FOUR more Start timer and Press button to activate or times within 5 seconds cancel daily start. icon flashing Table 4: FOUR beeps to confirm (Press and hold until FOUR Beeps are heard) Button LCD display Button...
  • Page 15 http://www.msvmaster.lv SVMASTER - Toggle - Enables parking countdown. Parking There is a beep 5 min. before the Parking countdown countdown reaches 0. - Disables parking countdown. Illumination Default is Menu 3 SEC. - Toggle Basic operation with backlight 5 SEC .
  • Page 16 http://www.msvmaster.lv SVMASTER - Toggle power - While the power save mode, the LCD remote transceiver uses “0” current to save save the battery power. - Power save OFF Exit: Press any button of the LCD remote transmitter to exit the “Power Save Mode”. Daily Start Timer Daily Start Time Adjust Only (ex.
