Figure 5 SAS Disk Drive LEDs
Activity LED
1

Controls and Ports

The following section identifies the locations and functions of the front panel controls and ports.
The Power button, and server blade extraction lever, and the SUV cable port are located on the
front of the server. For more information about the Power button and server blade power states,
see "Server Power States" (page
Figure 6 Front Panel Controls and Ports
Extraction lever release
1
button
Power button
2
22 Overview
Status LED
2
39).
iLO 2 MP reset pinhole
3
button
Extraction lever
4
SUV port
5
Init (ToC) pinhole button
6
