Navigation Guidance

What to Do When...

About GPS Satellite Quality and Status

Touch
status.
Icon
Sky blue circle
106
106
and the GPS switch to open the GPS Data screen and check the GPS reception
Color
Green
Yellow
Gray
Red
Green (blinking)
Yellow (blinking)
Red (blinking)
Name
GPS position Navigation is connected to the GPS
quality indicator receiver and able to obtain GPS position
information in 3D. Navigation can
calculate both your horizontal and
vertical GPS position.
Navigation is connected to the GPS
receiver and able to obtain GPS position
information in 2D. Only the horizontal
position is calculated, Navigation cannot
calculate your vertical GPS position.
Navigation is connected to the GPS
receiver but cannot obtain GPS position
information.
Navigation has no connection to the GPS
receiver.
GPS connection Navigation is connected to the GPS
quality indicator receiver.
Navigation has no connection to the GPS
receiver but it is still trying to establish a
connection.
Navigation has no connection to the GPS
receiver and is not trying to establish a
connection.
The virtual sky shows the visible part of
the sky above you, with your position as
the center. The satellites are shown at
their current positions. The GPS receives
data from both the green and yellow
satellites. Signals from the yellow
satellites are only received, while green
ones are used by the GPS receiver to
calculate your present location.
Description
