FujiFilm Frontier DL450 Specification

Frontier Dry Minilab DL450 Main Specifications
Model name DL450
Print method Piezoelectric inkjet system
Print capacity Approx. 950 prints/hr (4R-size), Approx. 305 prints/ hr (254
Print resolution 720 720 dpi

Paper
Roll paper 89 mm (3.5"), 102 mm (4"), 127 mm (5"), 152 mm (6"), 203 mm (8"), 254 mm (10"),
279 mm (11"), 305 mm (12")
Sheet paper Widths 203 mm (8") – 305 mm (12")
Lengths 188 mm (7.4") – 635 mm (25")
Paper Lengths
Minimum Length: 89 mm
Maximum Length: 457 mm (Widths 89 – 127 mm ), 914 mm (Widths 152 – 305 mm)
Paper type Single side paper: Glossy /Luster
Double side paper: Luster
Ink cartridges 4 Colors (Y, M, C, K) of dye based ink (Volume: 500 ml per color)
Back printing Image information is printed on the back of the print-2 lines (80 characters)
Printer sorter 12 order sorter (Maximum size 152
Paper supply Roll paper: Double Magazine
Sheet paper: Sheet paper supply unit (Optional)
Foot print Approx. 0.87 m 2 (Included optional unit)
Installation space Approx. 2.5 m 2 (Included optional unit)
Power requirements 100-120V /200-240V (50/60Hz) auto conversion, single-phase two-wire
Dimensions (W D H) 1,180 775 1,342 mm (Including optional unit)

Weight
240 kg (Including optional unit)
Power consumption 96.8 kWh /month (in energy saving mode)
120 kWh /month (without energy saving mode)
Note: Specifications are subject to change without notice due to improvements.
306 Dimensions
1,180
997
885
230 775
203 mm -size)

254 mm /50 sheet)

Unit: mm
Ref. No. LB-1003E
(SK·10·08·F1079·F9711) ©2010 FUJIFILM Corporation
Outstanding productivity representing
a new era in the print business
