Veo Observer Plus User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1. System Features
- 1
Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN

Table of Contents

Advertisement

Table of Contents
loading

Related Manuals for Veo Observer Plus

Summary of Contents for Veo Observer Plus

  • Page 1: Table Of Contents

    1-3.Hardware Description and Features 1-4.Observer Plus Hardware Specification 2. Installation 2-1. Observer Plus Hardware Setup 2-2. Observer Plus Hardware Setup (Wireless LAN Setup) 2-3. Connecting to an Access Point (AP) 3. Accessing the Observer Plus 3-1.Change the Observer Plus IP Status 3-2.On the LAN with DHCP Server...
  • Page 2 9. Snapshots 10. Image Recording 10-1. Save as JPEG 10-2. Save as AVI 10-3. Save Current Picture As… 11.GPIO Function 12.Hardware Reset Function 13. Accessing Observer Plus over the Internet 14.POE(Power over Ethernet) Function Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...
  • Page 3 15.Pan and Tilt Control 15-1.Control the camera in the main window 15-2.Position Points Pre setting 15-3.Image Rotate Setting 15-4.Camera Moving Step Size Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 4: Package Contents

    1-1. Package Contents  Observer Plus Pan/Tilt Network Camera x 1  Power Adapter (5V 2A) x 1  Red Color 10/100 Mbps Ethernet LAN Cable (MDI / X, Cross over LAN cable)  Blue Color 10/100 Mbps Ethernet LAN Cable (MDI) ...
  • Page 5 Camera Pan Degree ( Mechanic angle ): 300 degree (-165° ~ +165°)  Camera Tilt Degree ( Mechanic angle ): 120 degree (Down 30° ~ up 90°)  P/T Control: Up ,Down ,Right ,Left, Up-Right ,Up-Left, Down-Right ,Down-Left, Center  Position presetting : 6 point Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 6: Motion Detection

    ActiveX controls: ActiveX controls support full functions, including the Right Mouse Button Menu control. Utility  IPEDIT.EXE to scan the Installed Observer Plus and change the Camera Name and IP Address Power  Power DC 5V 2A, switching type power supply ...

  • Page 7: 1-4.Observer Plus Hardware Specification

     Network ready, IP address able (no PC required.)  Motion-JPEG based compression  Size: 160 mm x 70 mm x 57 mm  Weight: 500g  Power Supply: 12 V , DC/ 2A Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 8: Installation

    4. Wait 45 sec to 60 sec, the camera will auto Pan and Tilt, moving to camera center 5. Use the IPEdit.exe tools to find the Observer Plus and setup camera IP address. 6. Use IE to view the Observer Plus image.
  • Page 9 Step 4. Ensure the Camera power light is lighting When the Observer Plus is connected with power, the LED light on top of the Observer Plus will light up. This indicates that the Observer Plus is powered Wait 45 sec to 60 sec, camera will auto pan tilt and moving camera center Step 5.

  • Page 10: Observer Plus Hardware Setup (Wireless Lan Setup)

    Observer Plus VIPN-2XXX Network Camera support wireless LAN USB Dongle, the USB port in camera back panel. The camera support dual mode, LAN and WLAN, when you want to use wireless LAN with Observer Plus VIPN-2XXX, please follow setup step and notes.
  • Page 11 NOTES: If you can’t find camera in IP-EDIT list , than mean is something wrong, you need use reset button to reboot camera and setup again (from step 1). Use Pin to press Reset button 10 sec, than camera will reboot - 11 Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 12: Connecting To An Access Point (Ap)

    Your 802.11g USB 2.0 USB dongle also enables a group of wireless stations to communicate with each other. It acts as bridging functions between the wireless network and the wired LAN network. e.g. ASCII : [0~9] [A~Z] [_] , 64bit/5 characters,128bit/13 characters - 12 Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 13: Accessing The Observer Plus

    If you allow outsiders to see the Observer Plus, please enter another IP address. If you only want the Observer Plus to be viewed in the internal network, you could enter a local IP number Example: 192.168.1.88.  Clicking “Submit” will update all of changes mode to the Observer Plus settings.

  • Page 14: On The Lan With Dhcp Server

    4. Update the Network Mask (255.255.255.0). 5. Http Port1 type in 80 and press ‘Submit’ it. After the button ‘Submit’ is clicked, the IP information of this Observer Plus will be updated. Access this Observer Plus by this IP address; on the Configuration -> Network, the Fixed IP address was assigned.

  • Page 15: On The Lan Use With The Adsl Router

    IP address from the DHCP server. However, if you want to access the Observer Plus from the WAN, the Observer Plus IP address needs to be setup as fixed IP. Same goes for the Virtual Server function of ADSL router, which needs to be setup as well.

  • Page 16: Change Password

    On the IE Browser, right mouse click on the video to activate a pop-up menu. You can then change the camera settings accordingly. 6-1. Quality Setting The Observer Plus provides 3 image quality settings. The user can select the Quality setting from the Quality list box. ...

  • Page 17: Resolution Setting

    6-5.Operation Mode Continuous Mode: The Observer Plus will always try to capture the image as fast as possible. This is the default setting. Periodic Mode: MS (mill-second) or s (second) can be set. The value set must be greater than 0.

  • Page 18: View Log File

    7. View Log File The user can check the log information of the Observer Plus, including the Main Info, Appended Info, Operator IP, Operator MAC, and Time. Select the ”Camera Window” button to return to Camera mode. - 18 Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 19: Configuration

    The screen is the main menu for configuration setting, when the administrator selects the “Configuration” in the main window. Observer Plus provides 6 types of configurations:  System Setup ...

  • Page 20: 8-1.System Setup

    Select “ NTP ” button  Key in the Sever IP address like: http://www.org.ntp.org Press ”adjust” to activate  After Observer Plus get the time from NTP server, it will update the Camera’s time field.  Select “Input new time” button and click on “Synchronize with PC’s time“...

  • Page 21: Webserver Port Number

    Observer Plus. It is recommended to keep the HTTP “Port 1” as 80 to make sure the Observer Plus can be accessed by the default HTTP port setting access on the LAN. http://xx.xx.xx.xx/ If multiple Observer Plus are installed on the LAN, also required to be accessed from the WAN, the HTTP “Port 2”...

  • Page 22: Delete User

    If the check box is not checked, then the user check will not be enabled. All users can access the Observer Plus directly, with the administrator’s permission. A Login window is not required. Note: Before you select Enable user check ”Yes” button, please remember to change the administrator password.

  • Page 23: Motion Detected Mail

    Plus will send the motion-detected images to the preset email address. The maximum number of images allowed is 6 images per mail. 8-3-3. Motion detected mail The received mail will be displayed in a motion picture form. - 23 Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 24: Motion Detected Message On The Main Window

    Mail or Ftp site by manual setting Enable GPIO OUT GPIO IN GND VCC Note. About GPIO function, we only provides a set to be possible to use Please check the image what GPIO IN/OUT may use. - 24 Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 25: 8-4.Alert In Setup

     Check the “Send mail when motion detected” check box to enable the operation. If the check box is not checked, the motion detected send mail function will not be enabled.  Confirm by selecting [Save Settings] option to save the settings. - 25 Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 26: 8-4-3.Motion Detected Mail (Alert In Enabled)

     Certain FTP servers need an “Account” field. Leave it blank if it is not needed.  Enter the “Remote folder” upload path information for saving the images.  Confirm by selecting the [Save Settings] option to save the settings. - 26 Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 27: Network Setup

    The Observer Plus can directly connect to the ADSL. However, it should be setup on the LAN environment to setup the PPPoE information before connecting to the ADSL modem. Power on the Observer Plus and it will dial in to the ISP connection to the WAN via the ADSL modem.
  • Page 28  Confirm by clicking on the “Save” button to save the settings. If the Observer Plus and ADSL modem are connected by a hub, the administrator can select ”Dial Now” to perform the connect operation. On the contrary, if the Observer Plus and ADSL modem are connected directly, then there is a need: ...

  • Page 29: Audio Setup

    Check the “Enable” button First, make sure you register to DYNDNS (http://www.dyndns.org). Create a Dynamic DNS domain. In the DYNDNS configuration of your Observer Plus, fill in the “UserName“, “password“ and “DomainName“ you created in the http://www.dyndns.org. Submit to save the settings.

  • Page 30: Snapshots

    4. Click on the “Save As” button and a pop-up window displays to select the save path and file name prefix. Select “Save” to continue. 5. Click on the “Start” button to perform the image download process and save the JPEG files onto the local PC. - 30 Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 31: Save As Avi

    Each File”. When you reach the limit of frames during recording, a new AVI file would be created.  Click on the “Save As” button and a pop-up window displays to select the save - 31 Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 32: Save Current Picture As

    2. Enter the name you wish to save as into the “File name” field. Click on “Save”. 11. GPIO Function GPIO(General Purpose Input Output) 1 input and 1 output (Support extra device) - 32 Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 33: Hardware Reset Function

    When you want to reset camera, the camera must be powered on. 13. Accessing Observer Plus over the Internet If your home or business LAN is connected to the Internet through a high speed (broadband) Internet connection, with at least 128 kbps upload bandwidth, you can access your camera via the web browser from anywhere on the Internet.

  • Page 34: Poe(Power Over Ethernet) Function

    LAN infrastructure. It enables power to be provided to the network device, such as an IP phone or a network camera, using the same cable as that used for network connection. How to use Observer Plus POE Function? 1. Connect the PoE adapter (purchased separately) to the Camera.

  • Page 35: Control The Camera In The Monitor Window

    3. Pan/Tilt page Set button: Position setting Move button: Camera moving to position Clean button: Clean position setup 16-3. Image Rotate setting 1. Administrator account login 2. Configuration page 3. Pan/Tilt page - 35 Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...

  • Page 36: Camera Moving Step Size

    1. Administrator account login 2. Configuration page 3. Pan/Tilt page Default step size is “Medium” Veo Europe: Address: Western Business Park, Unit 1 Shannon, Co Clare Ireland Hotline: +35361702099 Support Email: support@veoeurope.com - 36 Veo Europe_VIPN-2xxx Observer Plus_UserManual rev1.0 EN...
