Control Panel - Sharp R-933FS Operation Manual

R-933F English 2/7/02
2
1
19
18
COOK
17
16
15
12:37 PM Page 3
DEFROST
R-933

CONTROL PANEL

Digital display and indicators:
1 COOKING IN PROGRESS indicator
2 GRILL indicator
3 CONVECTION indicator
3
4 MICROWAVE indicator
4
5 INFO indicator
5
Operating buttons:
6 INFORMATION button
6
7 LANGUAGE button
8 AUTO REHEAT button
7
9 EXPRESS DEFROST button
10 AUTO COOK button
8
11 COOKING MODE dial
9
Rotate the dial so that indicator points to
appropriate symbol:
10
for microwave cooking
for microwave cooking with GRILL
for microwave cooking with CONVECTION
for GRILL
11
for CONVECTION
12 CONVECTION button
Press to change the convection temperature.
13 TIMER/WEIGHT knob
12
Rotate the knob to enter either the
cooking/defrosting time or weight of food.
14 + 1 min /START button
15 STOP button
16 CLOCK SETTING button
13
17 MICROWAVE POWER LEVEL button
Press to change the microwave power
setting.
18 EXPRESS COOK button
19 LESS/MORE buttons
14
3
