Safety Information
BEFORE YOU BEGIN
Read these instructions completely and carefully.
.
IMPORTANT-
Save theseinstructions
for local inspector's use. Observe all governing codes
and ordinances.
. Note to Installer - Be sure to leave these
instructions with the Consumer.
. Note to Consumer - Keep these instructions
with your Owner's Manual for future reference.
.Skill Level
- Installation of this refrigerator requires
basic mechanical, carpentry and plumbing skills. Proper
installation is the responsibility of the installer. Product
failure due to improper installation is not covered under
the GE Appliance Warranty. See the Owner's Manual for
warranty information.
For Monogram local service in gour area, call
1.800.444.1845.
For Monogram Parts and Accessories, call
1.800.626.2002.
www.monogrom.com
WARNING:
This appliance must be properly grounded.
See "Grounding the Refrigerator," page 5.
If you received a damaged refrigerator, you should
immediately contact your dealer or builder.
A CAUTION:
Due totheweightand size ofthis refrigerator, and to
reducetherisk o fpersonal injury ordamage tothe
product-TWO PEOPLE ARE REQUIRED FOR PROPER
INSTALLATION.
A WARNING:
. These refrigerators oretop-heavy and must
be securedto prevent thepossibility oftipping
forward. A nti-tip protection isrequired. See page 14
for details.
. Use this appliance only for its intended purpose.
. Immediately repair or replace electric service cords
that become frayed or damaged.
. Turn off the circuit breaker to disconnect power
before cleaning or making repairs.
. Repairs should be mode by a qualified service
technician.
AWARNING-R6ooa
Refrigerant
Warning: This appliance contains isobutane refrigerant,
R6OOa, a natural gas with high environmental
compatibilitg. However it is also combustible. Please
adhere to the warnings below:
i} When handling, installing and operating the appliance,
care should be taken to avoid
damage to the refrigerant tubing.
21Servicing shall be performed by factory-authorized service
personnel and component parts shall be replaced with
manufacturer-authorized replacement components.
:3)Refrigeration products contain refrigerants, which
under federal law must be removed prior
to product disposal.
41Keep ventilation openings in the appliance enclosures or
in the built-in structure clear of obstruction.
51Do not use mechanical devices or other means
to accelerate the defrosting process.
61Do not damage refrigerant circuit.
71Do not use electrical appliances insidethe
food storage compartment of the appliance.
CONTENTS
Design Guide
Cabinet Enclosure Dimensions ............ 3
Refrigerator Dimensions .......................... 4
The Installation Space .............................. 5 Step
Grounding the Refrigerator .................... 5 Step
Dimensions and Clearances .................. 3 Step
Integrated Handles Step
!15 ° Door Swing ........................................ 6 Step
Integrated Handles Step
90 ° Door Swing ............................................ 7 Step
Professional Handles Step
!!5 ° Door Swing ........................................ 8 Step
Professional Handles Step
90 ° Door Swing ............................................ 9 Step
SS Panel Accessory & Dimension ....!0
3/4" Custom Panel Dimensions ........ !!
Installation Instructions
Tools, Hardware, Materials .................. 12
Step 1, Remove Packaging .................. 13
2, Install Anti-tip Bracket ............ 14
3, Connect Water Line ................ 1/4
4, Connect Power .......................... 1/4
5, Slide Unit into Enclosure ...... 1 5
6, Remove Toekick and Vent....15
7, Level Refrigerator .................... 16
8, Install Toekick and Vent ........ 16
9, Reverse Door Swing ........ 1 7, 18
10, Adjust Door Swing ................ 18
11, Attach Hinge Guard .............. 18
12, Install Door and Drawer
Panels.......................................... 19
Step 13, Start Icemaker ........................ 20
Badge Templates .................................... 2]
Notes ...................................................... 22, 23
