INS-805-2500-SKD-1box.qxd
S
MOK E
ASSEMBLY AND OPERATING INSTRUCTIONS
D
ELU X E
WARNING
READ AND FOLLOW ALL WARNINGS AND
INSTRUCTIONS IN THIS MANUAL TO AVOID
PERSONAL INJURY OR PROPERTY DAMAGE.
10/22/03
5:06 PM
Page 1
Heavy-Duty Charcoal/Wood Smoker & Grill
OWNER'S MANUAL
K
ING
300
200
400
100
°F
50
500
Advertisement
Related Manuals for BRINKMAN Smoke King Deluxe
Summary of Contents for BRINKMAN Smoke King Deluxe
- Page 1 INS-805-2500-SKD-1box.qxd 10/22/03 5:06 PM Page 1 Heavy-Duty Charcoal/Wood Smoker & Grill OWNER’S MANUAL MOK E ASSEMBLY AND OPERATING INSTRUCTIONS ELU X E WARNING READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN THIS MANUAL TO AVOID PERSONAL INJURY OR PROPERTY DAMAGE. °F...
- Page 2 INS-805-2500-SKD-1box.qxd 10/22/03 5:06 PM Page 2 IMPORTANT SAFETY WARNINGS WE WANT YOU TO ASSEMBLE AND USE YOUR COOKER AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMBOL IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR COOKER. WHEN YOU SEE THE SAFETY ALERT SYMBOL, PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND OPERATING YOUR COOKER.
- Page 3 INS-805-2500-SKD-1box.qxd 10/22/03 5:06 PM Page 3 WARNING • When grilling, grease from meat may drip into the charcoal and cause a grease fire. If this should happen close lid to suffocate the flame. Do not use water to extinguish grease fires. •...
-
Page 4: Assembly Instructions
The following tools are required to assemble this Smoke King Deluxe: • Pliers • Phillips & Flathead Screwdrivers • Adjustable Wrench PARTS LIST - SMOKE KING DELUXE: 1 Chimney 1 Firebox lid 1 Smoker box 1 Smoker box door 1 Firebox lid hinge 1 Firebox °F... - Page 5 INS-805-2500-SKD-1box.qxd 10/22/03 5:06 PM Page 5 Parts Bag Contents 10 10mm hex nuts 6 10 X 20mm hex bolts 1 Smoker box door handle 4 10 X 50mm hex bolts 1 Firebox lid handle 4 6mm hex nuts 1 Handle spring 1 Washer 2 Cotter pins 4 6 X 12mm phillips screws...
- Page 6 INS-805-2500-SKD-1box.qxd 10/22/03 5:06 PM Page 6 Choose a good, cleared assembly area and get a friend to help you put your cooker together. Lay cardboard down to protect cooker finish and assembly area. Step 1 Turn the cart frame upside down. Step 2 Attach locking casters to the bottom of cart frame.
- Page 7 INS-805-2500-SKD-1box.qxd 10/22/03 5:06 PM Page 7 Step 5 Remove the firebox side door by lifting it off its hinges. This will reduce the weight of the box and make it easier to handle in Steps 7 and 8. Step 6 Turn the smoker box on its side, with the cut out side facing up.
- Page 8 INS-805-2500-SKD-1box.qxd 10/22/03 5:06 PM Page 8 Step 9 Attach the smoker box door to the smoker box by sliding the hinge pins into the hinge holes on the smoker box. Step 10 Set the firebox lid on the firebox, sliding the hinge pin into the hinge hole.
- Page 9 Step 20 Place the smoker box cooking grills into the smoker box at the desired level. Step 21 Place the chimney over the hole on top of smoker box. °F °F Smoke King Deluxe (assembled)
- Page 10 BEFORE OPERATING YOUR COOKER. Curing Your Cooker Prior to your first use of the Brinkmann Smoke King Deluxe, follow the instructions below carefully to cure your cooker. Curing your cooker will minimize damage to the exterior finish as well as rid the cooker of paint odor that can impart unnatural flavors to the first meal prepared on your Brinkmann Smoke King Deluxe.
- Page 11 IMPORTANT: To protect your cooker from excessive rust, the unit must be cured periodically and covered at all times when not in use. A cover can be ordered directly from Brinkmann by calling 1-800-468-5252. YOUR BRINKMANN SMOKE KING DELUXE IS NOW CURED AND READY FOR USE.
-
Page 12: Operating Instructions
Smoking Follow instructions below carefully to build a fire. You may use charcoal and/or wood as fuel in the Smoke King Deluxe (see “Adding Charcoal/Wood During Cooking” section of this manual). WARNING: Never use charcoal that has been pre-treated with lighter fluid. - Page 13 INS-805-2500-SKD-1box.qxd 10/22/03 5:06 PM Page 13 Step 4 With coals burning well, carefully add wood chunks using long cooking tongs (see “Flavoring Wood” and “Adding Charcoal/Wood During Cooking” sections of this manual.) NOTE: Depending on the weather, a full pan of charcoal will burn for 5-6 hours.
- Page 14 Step 2 Follow the instructions below carefully to build a fire. You may use charcoal and/or wood as fuel in the Smoke King Deluxe (see “Adding Charcoal/Wood During Cooking” section of this manual). WARNING: Never use charcoal that has been pre-treated with lighter fluid.
- Page 15 A lot of wood is not required to obtain a good smoke flavor. A recommended amount for the Smoke King Deluxe is 5 to 6 wood chunks or sticks. Experiment by using more wood for stronger smoke flavor or less wood for milder smoke flavor.
- Page 16 INS-805-2500-SKD-1box.qxd 10/22/03 5:06 PM Page 16 Regulating Heat To increase heat and air circulation, fully open firebox air vent and chimney damper. If increased air circulation does not raise temperature sufficiently, more wood and/or charcoal may be needed. Follow instructions in “Adding Charcoal/Wood During Cooking”...
- Page 17 INS-805-2500-SKD-1box.qxd 10/22/03 5:06 PM Page 17 AFTER-USE SAFETY WARNING • Always allow cooker and all components to cool completely before handling. • Never leave coals and ashes in cooker unattended. Make sure coals and ashes are completely extinguished before removing. •...
- Page 18 15 minutes with no unpleasant fumes to affect Ideal for use in our the flavor of your food. Smoke King Deluxe. Our unique design allows Set of 12 you to pour the hot coals...
- Page 19 Smoke King Deluxe Smoker Cover Our heavy-duty, durable vinyl cover with felt backing provides years of protection for Brinkmann Smoke King Deluxe. This top-of-the-line cover comes with closure strips at both ends to prevent cover from slipping or blowing off. Black.
-
Page 20: One Year Limited Warranty
The Brinkmann Corporation requires reasonable proof of purchase. Therefore, we strongly recommend that you retain your sales receipt or invoice. To obtain replacement parts for your Smoke King Deluxe under the terms of this warranty, please call Customer Service Department at 1-800-527-0717. A receipt will be required. The Brinkmann Corporation will not be responsible for any cookers forwarded to us without prior authorization.
