Cybex 600T Treadmill
Owner's Manual
Cardiovascular Systems
Part Number LT-03157 Rev C
Cybex and the Cybex logo are registered trademarks of Cybex International, Inc. Stableflex and the Stableflex logo are registered
trademarks of Cybex International, Inc. Polar is a registered trademark of Polar.
DISCLAIMER:
Cybex International, Inc. makes no representations or warranties regarding the contents of this manual. We
reserve the right to revise this document at any time or to make changes to the product described within it without notice or
obligation to notify any person of such revisions or changes.
© 2000, 2002, Cybex International, Inc. All rights reserved. Printed in United States of America.
10 Trotter Drive Medway, MA 02053 • 800-766-3211 • 508-533-4300 • FAX 508-533-5183
www.eCybex.com • techhelp@cybexintl.com • techpubs@cybexintl.com • LT-03157 Rev C • April 2002

Advertisement

Table of Contents
loading

Related Manuals for CYBEX 600T

Summary of Contents for CYBEX 600T

  • Page 1 Owner’s Manual Cardiovascular Systems Part Number LT-03157 Rev C Cybex and the Cybex logo are registered trademarks of Cybex International, Inc. Stableflex and the Stableflex logo are registered trademarks of Cybex International, Inc. Polar is a registered trademark of Polar. DISCLAIMER: Cybex International, Inc.
  • Page 3 NOTE: The serial number can be found on the base of the 600T. It is located at the back of the treadmill, on the rear crossbar, under the running deck. You may wish to...
  • Page 4 NO POSTAGE NECESSARY IF MAILED IN THE UNITED STATES BUSINESS REPLY MAIL FIRST CLASS MAIL PERMIT NO. 73 MEDWAY, MA POSTAGE WILL BE PAID BY ADDRESSEE ATTN: CUSTOMER SERVICE CYBEX INTERNATIONAL 10 TROTTER DRIVE MEDWAY, MA 02053-9934...

  • Page 5: About This Manual

    English values are listed first, followed by metric units in parentheses. For example: 1” (2.54 cm). An Owner’s Manual is shipped with each 600T Treadmill. To purchase a copy of the Service Manual contact Cybex Customer Service at 800-766-3211 then press 63 or 508-533-4300.
  • Page 6 Cybex 600T Treadmill Owner’s Manual Declaration of Conformity We declare that to the best of our knowledge that the fitness equipment listed below, and manufactured by: Cybex International, Inc. 10 Trotter Drive Medway MA, 02053, USA Conforms to: Directives: 73/23/EEC, 89/336/EEC...

  • Page 7: Table Of Contents

    Caution Labels ....1-5 Assembling the Treadmill ... 5-4 Test the 600T Operation ... 5-8 Technical Specifications Setting Operation Options .
  • Page 8 Cybex 600T Treadmill Owner’s Manual...

  • Page 9: Safety

    Warning Labels ..1-4 Caution Labels... 1-5 Before you assemble your 600T, check to make sure that the treadmill has the Technical Specifications correct voltage requirements for your area, and that you have the correct Specifications .

  • Page 10: Important Safety Instructions

    Cybex 600T Treadmill Owner’s Manual treadmill are a grounded, dedicated circuit, rated for one of the following: 115 VAC ±10%, 60 Hz and 20 amps or a 220 VAC ±15%, 50 Hz/60 Hz and 15 amps. Make sure that the treadmill is connected to an outlet having the same configuration as the plug.

  • Page 11: Detailed Operation Guide

    Unpacking ....5-3 equipment and other hard surfaces. Assembling the Treadmill. . . 5-4 Test the 600T Operation . . . 5-8 Setting Operation Options. . 5-9 • Do not attempt repairs, electrical or mechanical. Seek trained repair personnel when servicing.

  • Page 12: Warning Labels

    Warning Labels Warning decals indicate a potentially hazardous situation, which, if not avoided, could result in death or serious injury. The warning decal used on the 600T is shown below. SERIOUS INJURY COULD OCCUR IF THESE PRECAUTIONS ARE NOT OBSERVED 1.

  • Page 13: Caution Labels

    Caution decals indicate a potentially hazardous situation, which, if not avoided, Table of Contents ..iii may result in minor or moderate injury. The caution decals used on the 600T Safety are shown below.
  • Page 14 Cybex 600T Treadmill Owner’s Manual Page 1-6...

  • Page 15: Technical Specifications

    Unpacking ....5-3 Motor: 2.5 hp, DC. continuous duty Assembling the Treadmill. . . 5-4 Test the 600T Operation . . . 5-8 Emergency Stop: Pull the emergency stop key (lanyard) Setting Operation Options. . 5-9...

  • Page 16: Stableflex System

    Cybex 600T Treadmill Owner’s Manual Stableflex System The Cybex 600T treadmill also has a feature you can find only in Cybex treadmills, Stableflex. Stableflex is laterally stable at the back and vertically flexible at the front. As a result of its high internal dampening, Stableflex allows shock to be absorbed where it occurs, and minimizes the impact.

  • Page 17: Operation

    Ordering Parts ... 6-5 The 600T is equipped with an Automatic Stop system for the running belt. If the treadmill detects that there is nobody running or walking on it, it will stop the belt after a user-selectable delay.

  • Page 18: Selecting Programs & Options

    Displaying Heart Rate In order for the 600T to display your heart rate, you must either use a Polar compatible heart rate transmitter belt, or your treadmill must have the optional Contact Heart Rate.

  • Page 19: Detailed Operation Guide

    This can be accomplished by Assembling the Treadmill. . . 5-4 Test the 600T Operation . . . 5-8 removing the power cord from the outlet, or most effectively, by removing the Setting Operation Options. . 5-9 lanyard from the treadmill.

  • Page 20: Control During Operation

    Cybex 600T Treadmill Owner’s Manual Control During Operation Every key on the display is usable during operation. Any key may be pressed at any time to make adjustments in speed, elevation, level, program choice, workout time, or data readouts. Changing Speed — Use the Speed keys arrows to change the speed in increments of 0.1 mph or 0.10 kph.

  • Page 21: Changing Data Readouts

    Requirements ... . 5-3 Unpacking ....5-3 Assembling the Treadmill. . . 5-4 Test the 600T Operation . . . 5-8 Setting Operation Options. . 5-9 Customer Service Contacting Service .

  • Page 22: Use Of Programs

    Cybex 600T Treadmill Owner’s Manual Use of Programs Using Hills, Endurance, or Sport Programs Any workout time between one and 60 minutes may be entered. These three programs share a common 2.5-minute warm-up and cool-down. If the time is two minutes or less, only part of the warm-up is used.
  • Page 23 Your age is required to estimate the proper range of Operation heart rates; the 600T will not let you select a heart rate below 60% of your Quick Start....3-1 maximum heart rate nor above 95% of your maximum.
  • Page 24 Cybex 600T Treadmill Owner’s Manual Page 3-8...

  • Page 25: Preventive Maintenance

    Every Month — Vacuum any dust or dirt that might accumulate under or Ordering Parts ... 6-5 around the 600T. Motors are especially susceptible to dust and dirt, and restricted airflow can prevent adequate cooling that could shorten motor life.
  • Page 26 Cybex 600T Treadmill Owner’s Manual Also use a dry cloth for the areas that you can't reach with the vacuum cleaner. If the machine has not been used for some time or is excessively dirty, use a dry cloth to wipe all exposed areas.

  • Page 27: Running Belt Maintenance

    Cybex 600T Treadmill Owner’s Manual belt is slipping. If the belt does slip, use a wrench to equally tighten both rear roller Table of Contents adjustment bolts 1/2 of a turn (clockwise). Adjust the belt until no further slipping Read All Instructions & Warnings is felt.
  • Page 28 A. Slide the two side rails back on being sure to catch the rail guides. B. Attach the plastic end caps with the Phillips screwdriver. NOTE: Refer to "Running Belt" in the 600T Treadmill Service Manual for more information. Contact Cybex Customer Service to order a Service Manual, parts, or to locate the Cybex dealer nearest you.

  • Page 29: Setup & Assembly

    Ordering Parts ... 6-5 the treadmill. Do not install the 600T in an area of high humidity, such as in the vicinity of a steam room, sauna, indoor pool, or outdoors. Exposure to extensive water vapor, chlorine, and/or bromine could adversely affect the electronics as well as other parts of the machine.
  • Page 30 Cybex 600T Treadmill Owner’s Manual Item Qty Description Base, console and uprights Screws for uprights, handlebar, and base covers Motor cover Motor cover screws Base covers Junction cover screws Junction covers Figure 1 Page 5-2...

  • Page 31: Electrical Power Requirements

    Unpacking ....5-3 Assembling the Treadmill. . . 5-4 • Owner's Operating Manual with registration card (not shown) Test the 600T Operation . . . 5-8 Setting Operation Options. . 5-9 Hardware Bag 1 •...

  • Page 32: Assembling The Treadmill

    Cybex 600T Treadmill Owner’s Manual Assembling the Treadmill To ensure correct assembly of the treadmill, carefully follow these steps: NOTE: In this manual the words “left” and “right” are from the treadmill user's point of view. 1. Move the treadmill into position.
  • Page 33 Requirements ... . 5-3 Unpacking ....5-3 Assembling the Treadmill. . . 5-4 Test the 600T Operation . . . 5-8 Setting Operation Options. . 5-9 Customer Service Contacting Service .
  • Page 34 Cybex 600T Treadmill Owner’s Manual 8. Attach the junction covers. A. Place the set of junction covers with the bottle holder over the right handlebar to upright junction and secure them with four Phillips head screws provided in bag 2. See Figure 5.
  • Page 35 Assembling the Treadmill. . . 5-4 A. Remove eleven of the screws on the console back. NOTE: It is not Test the 600T Operation . . . 5-8 necessary to remove the accessory holder’s top screw (holding the Setting Operation Options. . 5-9 accessory holder in place on the console back).

  • Page 36: Test The 600T Operation

    Cybex 600T Treadmill Owner’s Manual F. Fasten the back console with the screws removed during step 11A. NOTE: The two gold screws are for the accessory holder. ! WARNING: Be sure that all electrical requirements are met as indicated in the specifications at the front of the manual and at the beginning of this chapter prior to proceeding.

  • Page 37: Setting Operation Options

    Assembling the Treadmill. . . 5-4 during a pause in the workout or after a workout; choices are 30 Test the 600T Operation . . . 5-8 Setting Operation Options. . 5-9 seconds or 1 to 15 minutes, retaining the current workout data until a new workout begins;...
  • Page 38 Cybex 600T Treadmill Owner’s Manual D. Line Frequency: frequency of the power line that supplies power to your treadmill. The default setting is 50 Hz for metric consoles and 60 Hz for English consoles. NOTE: If you have an English console and a 50 Hz power line frequency, then you must change the default setting from 60 Hz to 50 Hz for the proper elevation frequency.

  • Page 39: Customer Service

    Unpacking ....5-3 assures that returned materials are properly handled and analyzed. Follow the Assembling the Treadmill. . . 5-4 Test the 600T Operation . . . 5-8 following procedures carefully. Setting Operation Options. . 5-9 Contact your authorized Cybex dealer on all warranty-related matters.

  • Page 40: Damaged Treadmill Or Parts

    Cybex 600T Treadmill Owner’s Manual 4. At Cybex’s discretion, the technician may request that you return the problem part(s) to Cybex for evaluation and repair or replacement. The technician will assign you an RMA number and will send you an ARS label. The ARS label and RMA number must be clearly displayed on the outside of the package that contains the item(s) to be returned.
