Cybex 710T Treadmill Owner's Manual
Running Belt Adjustments in the Preventive Maintenance chapter.
Then continue with step 17.
17. Attach the motor cover.
A. Lower the motor cover and in position and install the two Phillips head
screws that hold it in place.

Error Codes

Cybex provides error code descriptions for your information. Cybex
recommends that these errors be addressed by a qualified service technician.
These codes notify you of a problem condition and errors which jeopardize
safety will shut the treadmill down. The codes also help to indicate the part of
the treadmill most likely to be causing the problem.
ERROR 1:
No Speed Signal at Startup
ERROR 2:
Excessive Current Draw
ERROR 3:
Loss of Speed Signal
ERROR 50:
Overspeed (stored as ERR 6)
ERROR 70:
Loss of NOVRAM Information (stored as ERR 7)
If you have a problem that interrupts an important operational area of the
treadmill, you may see one of the above error codes displayed in the control
panel. If an Error Code is generated during operation, the treadmill's drive
motor will stop. In order to restart the treadmill, the Error Code must be cleared
by cycling the power to the machine by switching the ON/OFF switch to "OFF"
for five seconds and then switching it back "ON" again. Should a code
reappear soon after cycling off, then on again, report the problem to your
Cybex dealer, authorized Cybex service representative or directly to Cybex
Technical Support.
ERROR 1: No Speed Signal at Startup
This error code usually occurs only during start-up and indicates that the
computer in the control panel is not receiving any indication of motor speed.
To isolate the source of this problem, you need to determine whether the drive
motor tried to start up and did rotate or whether it never came on at all.
If the drive motor (and running belt) rotates, even if only for a second or so, the
error code usually indicates that the speed sensor is malfunctioning. The quick
way to check this is to remove the motor cover and the front panel to witness
the SPEED LED on the motor control board. If it blinks when the flywheel is
rotated by hand, the problem is most likely the console cable. After that,
suspect the lower board and then the display board. This signal can also be
seen on a diagnostic LED of the display board.
Control During Operation . . 3-4
Data Readouts. . . . . . . . . . . 3-5
Selecting Programs
& Options . . . . . . . . . . . . . 3-6
Displaying Heart Rate . . . . . 3-6
Use of Programs . . . . . . . . . 3-7
Manual Mode . . . . . . . . . . . 3-8
P1 - Fitness Test Program. . 3-8
P2 - Weight Loss Program 3-10
P3 - Cardiovascular Program 3-12
P4 - Speed Challenge
Program . . . . . . . . . . . . . 3-14
P5 - Express Program . . . . 3-16
P6 - Hill Interval Program . 3-17
P7 - Speed Interval
Program . . . . . . . . . . . . . 3-18
P8 - Pike's Peak Program . 3-19
P9 - River Run Program . . 3-20
P10 - 5 Kilometer Program 3-21
P11 - Demonstration
Program . . . . . . . . . . . . . 3-22
P101-P110 - Saved
Program . . . . . . . . . . . . . 3-22
Workout Tips . . . . . . . . . . . 3-24
4
Preventive Maintenance
Regular Maintenance
Activities . . . . . . . . . . . . . . 4-1
Cleaning Your Treadmill . . . . 4-1
Running Belt Maintenance . 4-2
Other Preventive
Maintenance . . . . . . . . . . . 4-6
Service Schedule . . . . . . . . . 4-7
Log Sheet . . . . . . . . . . . . . . . 4-8
5
Setup & Assembly
Quick Setup . . . . . . . . . . . . 5-1
Choosing & Preparing a Site 5-1
Electrical Power
Requirements. . . . . . . . . . 5-3
Unpacking . . . . . . . . . . . . . . 5-3
Assembling the Treadmill. . . 5-4
Testing the 710T Operation . 5-9
Setting Operation Options. 5-10
6
Customer Service
Contacting Service . . . . . . . 6-1
Serial Number & Voltage . . . 6-1
Warranty . . . . . . . . . . . . . . . 6-1
Return Material Authorization . .
(RMA) . . . . . . . . . . . . . . . . 6-4
Damaged Parts . . . . . . . . . . 6-4
Ordering Parts . . . . . . . . . . . 6-5
7
Service
Service Instruction . . . . . . . . 7-1
Motor Brushes. . . . . . . . . . . 7-1
Motor Current & Voltage . . . 7-4
Running Belt & Deck . . . . . . 7-7
Drive Belt . . . . . . . . . . . . . . . 7-9
Front Roller . . . . . . . . . . . . . 7-9
Rear Roller . . . . . . . . . . . . 7-10|
Error Codes . . . . . . . . . . . . 7-11
Diagnostic Tests . . . . . . . . 7-13
Parts List . . . . . . . . . . . . . . 7-20
Exploded View . . . . . . . . . . 7-23
710T Schematic . . . . . . . . . 7-24
Page 7-11
