Shift System

Note: Various models have different handlebar shifters and derailleurs, but the func-
tions and instructions are the same.
Parts of the Shift System:
• Right-hand Shift Lever (A) operates the Rear Derailleur (B).
• Rear Sprocket Set (C).
C
B
Operation:
Operate the shift system as follows:
1. The rider turns the rear shift control around the handlebar (for twist shift models)
or moves the shift lever (thumb shift models) to an index position
2. When the rear shift control moves into each position with a "click" sound, the shift
is complete
3. The shift control pulls a cable wire that is attached to the rear derailleur.
4. The derailleur moves and guides the chain from one sprocket to another.
5. If there is some chain noise after the shift, turn the rear shift control a small
amount to "trim" the rear derailleur.
28
A
continued >>
