m0058
HCruiserA EN 050117
Date Code Label
© Copyright Huffy Corporation 2017
Here
EN
Owner's Manual
for Cruiser Bicycles
This manual contains important safety, assembly,
operation and maintenance information.
Please read and fully understand this manual
before operation.
Save this manual for future reference.
See back page for Customer Service Information
Consulte el reverso para Servicio de Información al Cliente
Voir pages verso pour des renseignements le service à la clientèle
Advertisement
Table of Contents
Related Manuals for Huffy Cruiser
Summary of Contents for Huffy Cruiser
- Page 1 HCruiserA EN 050117 Date Code Label © Copyright Huffy Corporation 2017 Here Owner’s Manual for Cruiser Bicycles This manual contains important safety, assembly, operation and maintenance information. Please read and fully understand this manual before operation. Save this manual for future reference.
-
Page 2: Table Of Contents
Owner’s Manual Index Your Bike • Fitting the Rider to the Bicycle ..................3 • Warning and Safety Information ..................4 • Owner’s Responsibility ......................4 • Rules of the Road ........................5 Bicycle Assembly • Parts Assembly View ......................6 • Parts Assembly List ........................7 •... -
Page 3: Fitting The Rider To The Bicycle
Helmet Warning Information WARNING: Owner’s Bicycle Identifi cation Record ALWAYS WEAR YOUR NOTE: This information is only available on the bicycle itself. It is not available from Huff y. HELMET WHEN RIDING Each Huff y bicycle has a Recovery Code stamped into the frame. -
Page 4: Warning And Safety Information
Warning and Safety Information Meanings of Warnings: This symbol is important. See the word “CAUTION” or “WARNING” which follows it. The word “CAUTION” is before mechanical instructions. If you do not obey these instruc- tions, mechanical damage or failure of a part of the bicycle can occur. The word “WARNING”... -
Page 5: Rules Of The Road
Rules of the Road WARNING : Failure of the rider to obey the following “Rules of the Road” can result in injury to the rider or to others. • Obey all traffi c regulations, signs, and signals. • Always wear a bicycle helmet that meets safety standards, as well as local safety standards. •... -
Page 8: Introduction
Introduction to Assembly This Owner’s Manual is made for several diff erent bicycles: • Some illustrations may vary slightly from the actual product. • Follow instructions completely. • If the bicycle has any parts that are not described in this manual, look for separate “Special Instructions”... -
Page 9: Front Fender Installation
Front Fender Installation: Loosen the Front Brakes (IF EQUIPPED) (fi g. 1): Squeeze the two Brake arms together g 01 Lift out the Brake Cable Guide from the Guide Bracket ASSEMBLY - FENDER TABS (fi g. 2): NOTE: Some Tabs are Notched for easier assembly. If Tabs are not notched, remove Bolt, Washer and Nut fi rst. -
Page 10: Front Wheel Install
Front Wheel Install: WARNING • Do NOT use Axle Nuts without serrations to attach the front wheel. • Ensure wheel spins freely without contacting fork or fender. • Failure to obey these steps can allow the front wheel to loosen while riding. This can cause injury to the rider or to others. -
Page 11: Re-Attach Front Brake Cable
Re-attach Front Brake Cable (If Equipped): Re-attach Front Brake Cable: Squeeze the two Brake arms together Insert the Brake Cable Guide into the cutout in the Guide Bracket Make sure the Brake Cable Guide seated securely in the Guide Bracket cutout. -
Page 12: Mounted Wire Basket Assembly
Mounted Wire Basket Assembly (if equipped) Installation: Attach Support Legs to bottom of Basket using Bracket , 2 Screws , 2 Washers and 2 Nuts Tighten Securely. Make sure top of Support Legs between Bracket and Basket. Install the front wheel into the fork as described in the owner’s manual. -
Page 13: Rear Fender Assembly
Rear Fender Assembly Attach Lower Fender Braces: Line up the Rear Fender Braces with the Frame Mounting Tabs Insert each lower mounting Bolt into the Frame Mounting Tabs tighten securely. Make sure fender is centered over tire. Tighten Top Fender Mount: Note: Top Fender mount is loose to allow installation. -
Page 14: Handlebar And Stem Installation
Handlebar and Stem Installation WARNINGS • To prevent steering system damage and possible loss of control, the “MIN-IN” (minimum insertion) mark on the stem must be below the top of the Fork Locknut • The Front Brake (if equipped) must be positioned in FRONT of the Fork. Ensure the Fork is pointing FORWARD before proceeding. -
Page 15: Testing Stem And Handlebar Tightness
Testing Stem and Handlebar Tightness TO TEST THE TIGHTNESS OF THE STEM: • Straddle the front wheel between your legs. • Try to turn the front wheel by turning the handlebar. • If the handlebar and stem turn without turning the front wheel, realign the stem with the wheel and tighten the stem bolt(s) tighter than before (about 1/2 revolution only at a time). -
Page 16: Seat Installation
Seat Installation WARNING : To prevent the Seat coming loose and possible loss of control, the “MIN-IN” (minimum insertion) mark on the Seat Post must be below the top of the Seat Tube SEAT AND SEAT POST SETUP: If needed, loosen Nuts on Seat Clamp and rotate Seat into rid- ing position. -
Page 17: Testing Seat Clamp And Post Clamp Tightness
Seat Installation - continued Post Clamp The tightening torque of the Quick Release Lever should be tight enough so that the seat does not move during normal operation. Seat Bolt Mount (various models) Some models have a Bolt Washer and Nut instead of a Quick Release Lever. -
Page 18: Pedal Installation
Pedal Installation CAUTION: There is a RIGHT pedal marked and a LEFT pedal marked NOTE: A Pedal Wrench is preferred for attaching Ped- als. A thin open-end wrench can also be used. • The pedal marked has right-hand threads. Tighten it in a clockwise direction. •... -
Page 19: Accessories (Various Models)
Accessories (various models) LUGGAGE RACK ADJUSTMENT: Loosen Adjustment Knob by turning counter clockwise. Slide Adjustable Rack into position Tighten with Adjustment Knob by turning clockwise. NOTE: Do not over-tighten. This will damage the Knob. INSULATED BAG INSTALL: Attach Bag Handlebar by sliding the Back Brace securely into the Bracket Slots... -
Page 20: Accessories (Various Models)
Accessories (various models) BAG OR BASKET INSTALLATION: • Attach Bag or Basket to Handlebar using the two Straps. • Tighten Straps so Bag/Basket does not move. NOTE: Do not over tighten. The Straps may break. HANDLEBAR BELL INSTALLATION: Remove screws from Bell. Position Bell on handlebar within easy reach, with hands on the handlebar grips. -
Page 21: Repair And Service
Repair and Service WARNING: • Inspect the product frequently. Failure to inspect the product and to make repairs or adjustments, as necessary, can result in injury to the rider or to others. Make sure all parts are correctly assembled and adjusted as written in this manual and any “Special Instructions”. -
Page 22: Tires
Tires Maintenance: • Frequently check the tire infl ation pressure because all tires lose air slowly over time. For extended storage, keep the weight of the off the tires. • Do not use unregulated air hoses to infl ate the tire/tubes. An unregulated hose can sud- denly over infl ate tires and cause them to burst. -
Page 23: Coaster Brake And Chain Adjustment
Coaster Brakes These models are equipped with a rear ‘coaster’ brake that is operated by rotating the crank backwards. Operate the coaster brake as follows: • Push the pedals backward to move the chain backward • The chain activates the coaster brake mechanism that is inside the rear wheel •... -
Page 24: Rim Brake System: Setup And Adjustment
Linear Pull Brake System Adjustment - Before Starting IF EQUIPPED: The Following Sections Describe Final Brake System Adjustments Re- quired Before Riding. • Infl ate Tires to recommended pressure on Tire side wall. • Make sure Tire is centered in Fork. - Page 25 Linear Pull Brake System - Adjustment continued NOTE: The front and rear break adjustments are the same. WARNING : You must adjust the front and rear brakes before you ride the bicycle. Step 1: Put the brake shoes in the cor- rect position (fi g B): Loosen the Screw of each Brake...
- Page 26 Linear Pull Brake System Adjustment - continued PUT THE BRAKE SHOES THE CORRECT DISTANCE FROM THE RIM: If desired, adjust Brake Levers to a comfortable distance from the grip us- ing the Adjustment Screw . Turning the screw IN brings it closer to the grip. Make sure brake line Sheaths seated correctly.
-
Page 27: Brake Pad Replacement
Linear Pull Brake System - continued Test the tightness of the cable clamp (fi g C): Squeeze each Brake Levers with fi rm pressure. Make sure the cable does not move in the Cable Clamp If the cable moves in the cable clamp, adjust the brakes again but tighten the cable clamp tighter than before. -
Page 28: Lubrication
Lubrication WARNING: • Do not over lubricate. If oil gets on the wheel rims or the brake shoes, it will reduce brake performance and a longer distance to stop the bicycle will be necessary. Injury to the rider or to others can occur. •... -
Page 29: Inspection Of The Bearings
Inspection of the Bearings Maintenance Frequently check the bearings of the bicycle. Have a bicycle service shop lubricate the bear- ings once a year or any time they do not pass the following tests: Head Tube Bearings The fork should turn freely and smoothly at all times. With the front wheel off the ground, you should not be able to move the fork up, down, or side-to-side in the head tube. -
Page 30: Warranty
Limited Warranty General: • Used in a manner contrary to the instructions • Part or model specifi cations are subject to and warnings in this Owner’s Manual change without notice. • This Limited Warranty is the only warranty Huff y will not be liable for incidental or for the product. -
Page 31: Owner's Bicycle Identification Record
Owner’s Bicycle Identifi cation Record NOTE: This information is only available on the bicycle itself. It is not available from Huff y. Each Huff y bicycle has a Recovery Code stamped into the frame. The Recovery Code can be found on the bottom of the crank ... - Page 32 ANTES DE DEVOLVER EL RETOURNER AU MAGASIN, PRODUCTO A LA TIENDA, COMMUNIQUEZ AVEC LE SERVICE COMUNÍQUESE CON SERVICIO À LA CLIENTÈLE DE HUFFY. NOUS AL CLIENTE DE HUFFY. NOS VOUS AIDERONS VOLONTIERS AVEC COMPLACE AYUDARLO CON TOUT PROBLÈME CONCERNANT LES CUALQUIER PARTE O PROBLEMA PIÈCES OU LE MONTAGE!
