Heat & Glo SL-950TR-D Owner's Manual
  1. Manuals
  2. Brands
  3. Heat & Glo Manuals
  4. Indoor Fireplace
  5. SL-950TR-D
  6. Owner's manual

Heat & Glo SL-950TR-D Owner's Manual

Narural/liquefied petroleum gas
Hide thumbs
Table of Contents

Advertisement

Quick Links

Models:
SL-950TR-D
SL-750TR-D
SL-550TR-D
•
Important operating and
maintenance instruc-
tions included.
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing proper-
ty damage, personal injury, or death.
• Do not store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of this or
any other appliance.
• What to do if you smell gas
- Do not try to light any appliance
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed by
a qualified installer, service agency, or the gas
supplier.
This appliance may be installed as an OEM installation in
manufactured home (USA only) or mobile home and must
be installed in accordance with the manufacturer's instruc-
tions and the manufactured home construction and safety
standard, Title 24 CFR, Part 3280 or Standard for Installa-
tion in Mobile Homes, CAN/CSA Z240MH.
This appliance is only for use with the type(s) of gas indi-
cated on the rating plate.
CAUTION
DO NOT DISCARD THIS MANUAL
•
Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • SL-550 / 750 / 950TR-D • 2044-985 Rev. J • 6/06
Owner's Manual
Installation and Operation
•
Leave this manual with
party responsible for
use and operation.
WARNING
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot during
operation and cool down.
• Keep children away.
• CAREFULLY SUPERVISE children in same room as
appliance.
• Alert children and adults to hazards of high
temperatures.
• Do NOT operate with protective barriers open or
removed.
• Keep clothing, furniture, draperies and other
combustibles away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fixed glass panel. Do
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts:
• installation must be performed by a licensed plumber or
gas fitter;
See Table of Contents for location of additional
Commonwealth of Massachusetts requirements.
Installation and service of this appliance should be
performed by qualified personnel. Hearth & Home
Technologies suggests NFI certified or factory-trained
professionals, or technicians supervised
by an NFI certified professional.
1

Advertisement

Table of Contents
loading

Related Manuals for Heat & Glo SL-950TR-D

Summary of Contents for Heat & Glo SL-950TR-D

  • Page 1 Owner’s Manual Installation and Operation Models: SL-950TR-D SL-750TR-D SL-550TR-D CAUTION DO NOT DISCARD THIS MANUAL • • • Important operating and Read, understand and follow Leave this manual with maintenance instruc- these instructions for safe party responsible for tions included.

  • Page 2: Safety And Warning Information

    SAFETY AND WARNING INFORMATION These units MUST use one of the vent systems READ and UNDERSTAND all instructions carefully described in the Installing the Appliance section of before starting the installation. FAILURE TO the Installers Guide. NO OTHER vent systems or FOLLOW these installation instructions may result components MAY BE USED.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Safety and Warning Information ............2 Service Parts Lists ................. 4 Section 1: Approvals and Codes ............12 Appliance Certification ................12 Installation Codes .................. 12 High Altitude Installations ..............12 Requirements for the Commonwealth of Massachusetts ......13 Section 2: Getting Started ..............

  • Page 4: Service Parts Lists

    SL-550TR-D Service Parts Manufacturing Dates: 1-04 to ____ (NG, LP) Exploded Parts Diagram IPI Manufacturing Dates: 1-04 to ____ Log Set Assembly Part number list on following page. Heat & Glo • SL-550 / 750 / 950TR-D • 2044-985 Rev. J • 6/06...
  • Page 5 SL-550TR-D (NG, LP) Service Parts List IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When order- ing, supply serial and model numbers to ensure correct service parts. ITEM COMMON PARTS SERIAL # PART NUMBER Burner Orifice NG (#44C) 582-844...
  • Page 6 SL-750TR-D Service Parts (NG, LP) Exploded Parts Diagram Manufacturing Dates: 1-04 to ____ IPI Manufacturing Dates: 1-04 to ____ Log Set Assembly Part number list on following page. Heat & Glo • SL-550 / 750 / 950TR-D • 2044-985 Rev. J • 6/06...
  • Page 7 (NG, LP) Service Parts List SL-750TR-D IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When ordering, supply serial and model numbers to ensure correct service parts. ITEM COMMON PARTS SERIAL PART NUMBER Burner Orifice NG (#42C) 582-842 Burner Orifice LP (#53C)
  • Page 8 SL-950TR-D Service Parts Manufacturing Dates: 1-04 to ____ (NG, LP) Exploded Parts Diagram IPI Manufacturing Dates: 1-04 to ____ Log Set Assembly Part number list on following page. Heat & Glo • SL-550 / 750 / 950TR-D • 2044-985 Rev. J • 6/06...
  • Page 9 SL-950TR-D (NG, LP) Service Parts List IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When order- ing, supply serial and model numbers to ensure correct service parts. ITEM COMMON PARTS SERIAL #...
  • Page 10 Service Parts SL-950TR-IPI-D, SL-750TR-IPI-D, SL550TR-IPI-D (NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 1-04 Ending Manufacturing Date: ______ Intermittent Pilot Ignition Valve Assembly ITEM DESCRIPTION SERIAL # PART NUMBER Wire Assembly 2012-206 Thermostat Wire Assembly 2045-024 Burner Neck Gasket 2045-407 Pilot Assembly NG 385-510A Pilot Assembly LP...
  • Page 11 PART NUMBER Piezo Ignitor 291-513 Burner Neck Gasket 2045-407 Thermostat Wire Assembly 2045-024 Pilot Assembly NG (SL-550TR-D, SL-750TR-D) 485-510A Pilot Assembly NG (SL-950TR-D) 530-510A Pilot Assembly LP (SL-550TR-D, SL-750TR-D) 485-511A Pilot Assembly LP (SL-950TR-D) 530-511A Valve Bracket 2025-101 Valve Plate Gasket...

  • Page 12: Section 1: Approvals And Codes

    Certification changing the existing burner orifice to a smaller size. Input MODELS: SL-950TR-D, SL-750TR-D, SL-550TR-D rate should be reduced by 4% for each 1000 feet above a 2000 foot elevation in the U.S.A. or 10% for elevations LABORATORY: Underwriters Laboratories between 2000 and 4500 feet in Canada.

  • Page 13: Requirements For The Commonwealth Of Massachusetts

    Inspection NOTE: The following requirements reference various The state or local gas inspector of the side wall horizontally Massachusetts and national codes not contained in vented gas fueled equipment shall not approve the installa- this document. tion unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with Requirements for the Commonwealth of the provisions of 248 CMR 5.08(2)(a)1 through 4.

  • Page 14: Section 2: Getting Started

    Getting Started Introducing the Heat & Glo Gas Appliances The Heat & Glo Warranty will be voided by, and Heat & Glo disclaims any responsibility for, the following actions: Heat & Glo direct vent gas appliances are designed to op- •...
  • Page 15 (1218mm) (152mm) TOP STANDOFFS VENT CERAMIC COLLARS FIBER PAD HOOD RATING PLATE/LABELS BOTTOM GRILLE COVER ELECTRICAL CONTROLS ACCESS ACCESS Figure 1. Diagram of the SL-950TR-D Heat & Glo • SL-550 / 750 / 950TR-D • 2044-985 Rev. J • 6/06...
  • Page 16 30 3/4 (781mm) 15 3/8 (13mm) (391mm) 16 1/4 15 7/8 (413mm) (403mm) 8 13/16 (224mm) Ø 6 Ø (168mm) (203mm) 37 7/8 (962mm) 20 3/4 34 5/8 (526mm) (879mm) 2 3/16 3 9/16 (55mm) (90mm) GAS LINE 36 1/8 ELECTRICAL ACCESS 6 7/8...
  • Page 17 25 3/4 (653mm) 12 7/8 (326mm) 16 1/4 15 7/8 (413mm) (402mm) 8 13/16 (223mm) Ø (203mm) Ø6 5/8 (168mm) 17 1/4 31 1/8 (438mm) 32 9/16 (790mm) (828mm) 2 3/16 3 9/16 (55mm) (90mm) GAS LINE ELECTRICAL (790mm) ACCESS 6 7/8 ACCESS (174mm)

  • Page 18: Section 3: Installing The Appliance

    Top (SL-550TR-D) ......1 1/2 ..38 caulked or stuffed with insulation. If the appliance is being (SL-750TR-D & SL-950TR-D) .. 3 1/4 ..83 installed on a cement slab, a layer of plywood may be placed Ceiling* ..........31 ..787 underneath to prevent conducting cold up into the room.

  • Page 19: Step 2 Framing The Appliance

    (1) inch (25.4mm) above the center of the horizontal vent pipe. Framing should be constructed of 2 X 4 lumber or heavier. Model SL-950TR-D 49” 42 1/4” 16 1/4” 44” 31 7/8” SL-750TR-D 42” 38 1/4”...
  • Page 20 DVP4 DVP6 DVP12 14-1/4 12-3/16 MAX. MIN. DVP12A 9-7/8 DVP24 45.0 10-1/4 DVP45 DVP36 11-1/4 7-1/4 1-1/4 TYP DVP48 8-9/16 1/2 TYP NOTE: PIPES OVERLAP 1-1/4 INCHES 12-9/16 (34.93mm) AT EACH JOINT. Figure 6. DVP-Series Direct Vent Component Specifications (5-inch inner pipe / 8-inch outer pipe) Heat &...
  • Page 21 6 1/2 6 3/8 9 1/4 6 1/2 9 5/8 6 3/8 6 5/8 SL-45D 6 5/8 9 5/8 SL-90D SL-09D SL-12/17D (SL12-17D) SL-24D SL-48D SL-36D 8 3/4 12-17 23 3/4 35 3/4 47 3/4 17-24 6 1/2 11 3/4 5 3/4 6 5/8 SL-17/24D...

  • Page 22: Step 3 Installing The Vent System

    Step 3. Installing the Vent System WARNING: YOU MUST NOT MIX DVP-SERIES AND SL D-SERIES COMPONENTS IN ANY VENT A. Vent System Approvals SYSTEM CONFIGURATION. These models have vent starting collars on both the top and the back of the unit. Depending upon the installation, Identifying Vent Components decide which ONE set of starting collars will be used to Approved vent system components are labeled for identifi-...
  • Page 23 36" (914 mm) Note: You may use a 45 elbow in corner installations for models SL- 550TR-D and SL-750TR-D ONLY. Use two 90 elbows for corner installations on SL-950TR-D. Use DVP-Series components only. 90-DEGREE ELBOWS For corner installation of model SL-950TR-D.
  • Page 24 Figure 12. Venting with One 90° Elbow Use SL D-Series components only. VENTING WITH ONE (1) 90 ELBOW NATURAL GAS MODEL SL-550TR-D MODEL SL-750TR-D MODEL SL-950TR-D V (MIN.) H (MAX.) H (MAX.) H (MAX.) Elbow on Top 3 FT (863mm)
  • Page 25 H + H 1' MIN. (305 mm) 2' MAX. (610 mm) 4' MAX. (1.22m) 2' MIN. (610 mm) 4' MAX. (1.22 m) 8' MAX. (2.4m) 3' MIN. (914 mm) 6' MAX. (1.86 m) 12' MAX. (3.6m) 4' MIN. (1.22 m) 8' MAX.
  • Page 26 VENTING WITH TWO (2) 90 ELBOWS NATURAL GAS MODEL SL-550TR-D MODEL SL-750TR-D MODEL SL-950TR-D V (MIN.) H + H (MAX.) H + H (MAX.) H + H (MAX.) Elbow on Top 2.5 FT (863mm) 2.5 FT (863mm) 2 FT (610mm)
  • Page 27 VENTING WITH TWO (2) 90 ELBOWS NATURAL GAS MODEL SL-550TR-D MODEL SL-750TR-D MODEL SL-950TR-D V (MIN.) H (MAX.) H (MAX.) H (MAX.) 2.5 FT (863mm) 2 FT (610mm) Elbow on Top 2.5 FT (863mm) 1 FT (305mm) 3 FT (914mm)
  • Page 28 H + H 1' MIN. (305 mm) 2' MAX. (610mm) 4' MAX. (1.22m) 2' MIN. (610 mm) 4' MAX. (1.22m) 8' MAX. (2.48m) 3' MIN. (914 mm) 6' MAX. (1.86m) 12' MAX. (3.72m) 4' MIN. (1.22 m) 8' MAX. (2.48m) 16' MAX.

  • Page 29: Natural Gas

    VENTING WITH THREE (3) 90 ELBOWS NATURAL GAS MODEL SL-550TR-D MODEL SL-750TR -D MODEL SL-950TR-D V (MIN.) H (MAX.) H + H (MAX.) H (MAX.) H + H (MAX.) H (MAX.) H + H (MAX.) Elbow on Top 2.5 FT (863mm) 4 FT (1.22m)
  • Page 30 VENTING WITH THREE (3) 90 ELBOWS NATURAL GAS MODEL SL-550TR-D MODEL SL-750TR-D MODEL SL-950TR-D V (MIN.) H + H (MAX.) H + H (MAX.) H + H (MAX.) Elbow on Top 2.5 FT (863mm) 2.5 FT (863mm) 2 FT (610mm)
  • Page 31 90° VENTING WITH FOUR (4) ELBOWS NATURAL AND PROPANE GAS V (MIN.) H (MAX.) (MIN.) (MAX.) (MIN.) 5' (1.52m) 5' (1.52m) 4.5' (1.37m) 2' (609mm) 5' (1.52m) V + V + H + H MAX. = 40' (12.2m) Use SL D-Series components only.

  • Page 32: Installing Vent Components

    B. Installing Vent Components Venting Insert screwdriver Venting After determining which set of starting collars will be used or similar object Out Rear Out Top (top or rear), follow venting instructions accordingly. here to remove cap. Venting Out the Rear Vent (See Figure 21) SEAL INSULATION, SEAL...
  • Page 33 2. Continue Adding Vent Components Refer to Cinch Pipe and Termination Cap installation in- structions. • Continue adding vent components, locking each succeed- ing component into place. • Ensure that each succeeding vent component is secure- ly fitted and locked into the preceding component in the vent system.
  • Page 34 DVP, SL-D and SL-Flex Series Venting: For Vertical Runs - One ceiling firestop is REQUIRED at the hole in each ceiling through which the vent passes. STEP 4. Install Firestops To install firestops for vertical runs that pass through ceilings: For Horizontal Runs - Firestops are REQUIRED on both sides of a combustible wall through which the vent passes.

  • Page 35: Vent Termination

    C. Vent Termination If the area above the ceiling is NOT an attic, position and secure the ceiling firestop on the ceiling side of the previously SL-Series Venting Only: cut and framed hole. For Horizontal Terminations - To attach and secure the termination to the last section of horizontal vent: •...
  • Page 36 (See Note 2) U.S. (3 FT) Electrical Service J or K = VENT TERMINAL = AREA WHERE TERMINAL IS NOT PERMITTED = AIR SUPPLY INLET = 12" ....... clearances above grade, veran- = 3 ft. (U.S.A.) (See Note 1) da, porch, deck or balcony 6 ft.
  • Page 37 For Vertical Terminations - To locate the vent and install To seal the roof hole, and to divert rain and snow from the vent system: the vent sections: • Locate and mark the vent centerpoint on the underside • Attach a flashing to the roof using nails, and use a non- of the roof, and drive a nail through the centerpoint.

  • Page 38: Step 4. Positioning, Leveling, And Securing The Appliance

    Step 4. Positioning, Leveling, and Step 5. The Gas Control Systems Securing the Appliance WARNING: THIS UNIT IS NOT FOR USE WITH The diagram below shows how to properly position, level, SOLID FUEL. and secure the appliance. Two types of gas control systems are used with this model: Standing Pilot Ignition and Intermittent Pilot Ignition (IPI).

  • Page 39: Step 6 The Gas Supply Line

    Step 6. The Gas Supply Line NOTE: Have the gas supply line installed in accordance with local building codes by a qualified installer ap- proved and/or licensed as required by the locality. (In the Commonwealth of Massachusetts installation must be performed by a licensed plumber or gas fitter). NOTE: Before the first firing of the appliance, the gas USE A WRENCH ON supply line should be purged of any trapped air.

  • Page 40: Step 8 Wiring The Appliance

    NOTE: A wall switch or re- mote must be used on this appliance. Optional Accessories PIEZO Optional fan and remote con- PILOT THERMOSTAT trol kits require that 110-120 WIRE ASSEMBLY THERMOCOUPLE VAC be wired to the factory installed junction box before the appliance is permanently installed.
  • Page 41 IGNITION MODULE 3 VAC INTERMITTENT PILOT IGNITOR TRANSFORMER WHITE 3 VAC ORANGE GROUND TO FIREPLACE PLUG IN CHASSIS JUMPER WIRE BATTERY PACK (TO BROWN) THERMOSTAT WIRE ASSEMBLY VALVE Figure 37. Intermittent Pilot Ignition (IPI) Wiring Diagram For Intermittent Pilot Ignition (IPI) Wiring NOTE: A wall switch or remote must be used on this appliance.

  • Page 42: Step 9 Finishing

    CAUTION: IF JOINTS BETWEEN THE FINISHED WALLS Step 9. Finishing AND THE APPLIANCE SURROUND (TOP AND SIDES) Figure 38 shows the minimum vertical and corresponding ARE SEALED, A 300° F. MINIMUM SEALANT MATE- maximum horizontal dimensions of appliance mantels or RIAL MUST BE USED.

  • Page 43: Step 10 Installing Trim, Logs, And Ember Material

    ___________________________________________ SL-550TR-D 1/4” 3/8” ___________________________________________ SL-750TR-D 1/4” 3/8” ___________________________________________ GLASS ASSEMBLY SL-950TR-D 3/8” Full Open Figure 40. Glass Assembly GLASS SPECIFICATIONS: SL-950TR-D TEMPERED SL-750TR-D TEMPERED SL-550TR-D TEMPERED Heat & Glo • SL-550 / 750 / 950TR-D • 2044-985 Rev. J • 6/06...

  • Page 44: Step 11 Before Lighting The Appliance

    Double-check vent terminations and front grilles for Heat & Glo appliances manufactured with tempered glass may obstructions. be installed in hazardous locations such as bathtub enclosures as defined by the CPSC. The tempered glass has been tested • Before lighting the appliance, double-check the unit for and certified to the requirements of ANSI Z97.1-1984 and CPSC possible obstructions that could be blocking the vent ter- 16 CFR 1202.

  • Page 45: Section 4: Maintaining And Servicing Your Appliance

    Maintaining and Servicing Your Appliance Appliance Maintenance Checking Vent System Although the frequency of your appliance servicing and main- Frequency: Before initial use and at least annually tenance will depend on use and the type of installation, you thereafter, more frequently if possible. should have a qualified service technician perform an appli- By: Qualified service technician/Home owner.
