Introduction
Table 1-1. Remote Module Specifications
Specification
Size
Weight
Power Requirements
Communication
Data Type
Data Impedance
Data Tx Level
Data Rx Sensitivity
User Data Port
Data Type
Data Rate Setting
Description
8.0" x 8.0" x 1.50"
(205 mm x 205 mm x 40 mm)
1.5 pounds (0.68 kilograms)
12 vdc supplied by 120-vac adapters.
800 mA maximum
V.32terbo modem
600 Ohms
–15 dBm (+1 dBm/–3 dBm)
–40 to 0 dBm
RS-232
19.2 kbps/9.6 kbps, no parity, 8 bit,
1 stop bit
Issue 2 July 1997
1-7
