Assembling The Blades - Hunter Ceiling fan Owner's Manual And Installation Manual

6-1. Your fan may include blade grommets. If your fan has grommets,
insert them by hand into the holes on the blades.
6-2. Attach each blade to a blade iron using three blade assembly
screws. If you used grommets, the blades may appear slightly
loose after screws are tightened. This is normal.
6-3. Loosen the blade iron armature screws that are holding the
shipping bumpers in place. Push the shipping bumpers in, then
lift them off.
6-4. Slide the blade irons onto the blade iron armature screws and
tighten the screws securely.
6 • Assembling the Blades
Blade Iron
Armature Screw
Shipping
Bumper
Blade
Iron
Blade Iron
Armature Screw
Step 6-3
10
42790-01 • 20080925 • Hunter Fan Company
Step 6-1
Grommet
Blade Assembly
Screw
Steps 6-1 – 6-2
Blade Assembly
Screw
Grommet
Blade
