Model No. PETL75136
Serial No.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts,
please call:
08457 089 009
Or write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road, Beeston
Leeds, LS11 8JG
UK
email: csuk@iconeurope.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.iconeurope.com

Advertisement

Table of Contents
loading

Related Manuals for ProForm 760 Air Treadmill

Summary of Contents for ProForm 760 Air Treadmill

  • Page 1 Model No. PETL75136 USER’S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, please call: 08457 089 009 Or write: ICON Health &...

  • Page 2: Table Of Contents

    ORDERING REPLACEMENT PARTS ..........Back Cover Note: An EXPLODED DRAWING is attached in the centre of this manual. PROFORM is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 12. Keep the power cord away from heated sur- that all users of this treadmill are adequately faces.
  • Page 4 21. When using iFIT.com CDs and videos, you DANGER: Always unplug the power can manually override the speed and incline cord immediately after use, before cleaning settings at any time by pressing the speed the treadmill, and before performing the and incline buttons.

  • Page 5: Before You Begin

    Thank you for selecting the revolutionary PROFORM ® ing this manual, please call our Customer Service 760 AIR treadmill. The 760 AIR treadmill offers an im- Department at 08457 089 009. To help us assist you, pressive array of features to help you achieve your fit-...

  • Page 6: Assembly

    on Leg Bolt (96)–4 ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant.
  • Page 7 2. With the help of a second person, carefully tip the Upright Base (97) down as shown. (Note: It may be help- ful to place your foot on one of the Extension Legs [92] as you tip the Uprights.) Make sure that the Extension Legs remain in the Uprights.
  • Page 8 5. Set the Console Base (101) on the Uprights (97). Thread the four Console Bolts (76) with four Internal Star Washers (77) into the Uprights and the Console Base. Be careful not to pinch the Wires (not shown) in the Uprights.

  • Page 9: How To Use The Chest Pulse Sensor

    HOW TO USE THE CHEST PULSE SENSOR HOW TO PUT ON THE CHEST PULSE SENSOR each use, it may remain activated longer than nec- essary, draining the battery prematurely. The chest pulse sensor consists of two components: • Store the chest pulse sensor in a warm, dry place. the chest strap and the sensor unit (see the drawing Do not store the chest pulse sensor in a plastic bag below).

  • Page 10: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PERFORMANT LUBE ™ WALKING BELT , a high-performance lubricant. IMPOR- Your treadmill features a walking belt coated with PERFORMANT LUBE ™ TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear.
  • Page 11 Clip Note: If there are thin sheets of clear plastic on the console, remove them. FEATURES OF THE CONSOLE cable, you can connect the treadmill to your home stereo, portable stereo, computer, or VCR and play The treadmill console offers an impressive array of special iFIT.com CD and video programs (iFIT.com features that help you get the most from your workouts.

  • Page 12: To Turn On The Power

    walking. As you exercise, change the speed of the HOW TO TURN ON THE POWER walking belt as desired by pressing the Speed + and – buttons. Each time a button is pressed, the speed setting will change by 0.1 mph; if a button Plug in the power cord (see page 10).
  • Page 13 To change the unit of Measure your heart rate if desired. measurement, first hold down the Stop button You can measure your heart rate using either the whilst inserting the key chest pulse sensor or the handgrip pulse sensor. into the console. An “E” for English miles or an To use the hand- “M”...
  • Page 14 The speed setting for the HOW TO USE PRESET PROGRAMS Current Segment first segment is shown in the flashing Current Insert the key fully into the console. Segment column of the matrix. (The incline set- tings are not shown in See HOW TO TURN ON THE POWER on the matrix.) The speed page 12.
  • Page 15 To stop the program at any time, press the Stop When you are finished exercising, remove the button. The Time/Pace display will begin to flash. key from the console. To restart the program, press the Start button or the Speed + button. The walking belt will begin to When the program has ended, make sure that move at 1 mph.
  • Page 16 During pulse programs, HOW TO USE PULSE PROGRAMS the matrix will show a moving graphic that rep- resents your heart rate. CAUTION: Each time a heartbeat is If you have heart prob- detected, an additional lems, or if you are over 60 years of age and peak will appear.
  • Page 17 If the speed or incline setting is too high or too low Press the Start button or the Speed + button to at any time during the program, you can adjust the start the program. setting with the Speed or Incline buttons. However, each time the console compares your heart rate to A moment after the button is pressed, the tread- the current target heart rate, the speed and/or in-...
  • Page 18 HOW TO CONNECT YOUR PORTABLE STEREO HOW TO CONNECT THE TREADMILL TO YOUR CD PLAYER, VCR, OR COMPUTER Note: If your stereo has an RCA-type AUDIO OUT jack, see instruction A below. If your stereo has a 3.5 mm LINE OUT jack, see instruction B. If your To use iFIT.com CDs, the treadmill must be connected stereo has only a PHONES jack, see instruction C.
  • Page 19 HOW TO CONNECT YOUR HOME STEREO HOW TO CONNECT YOUR COMPUTER Note: If your stereo has an unused LINE OUT jack, Note: If your computer has a 3.5 mm LINE OUT see instruction A below. If the LINE OUT jack is jack, see instruction A.
  • Page 20 HOW TO CONNECT YOUR VCR HOW TO USE IFIT.COM CD AND VIDEO PROGRAMS Note: If your VCR has an unused AUDIO OUT jack, see instruction A below. If the AUDIO OUT jack is being used, see instruction B. If you have a TV To use iFIT.com CDs or videocassettes, the treadmill with a built-in VCR, see instruction B.
  • Page 21 • Make sure that the audio cable is properly If the speed or incline settings are too high or too low, you can manually override the settings at any connected, that it is fully plugged in, and that it is not wrapped around a power cord. time by pressing the Speed or Incline buttons on the console.
  • Page 22 begin walking. During the program, an electronic HOW TO USE PROGRAMS DIRECTLY FROM “chirping” sound will alert you when the speed OUR WEB SITE and/or incline of the treadmill is about to change. CAUTION: Always listen for the “chirp” and be prepared for speed and/or incline changes.
  • Page 23 THE INFORMATION MODE/DEMO MODE An “E” for English miles or an “M” for metric kilometers will The console features an information mode that keeps appear in the Speed display. track of the total number of hours that the treadmill has Press the Speed + button to been used and the total number of miles that the walk- change the unit of measure-...

  • Page 24: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be per- manently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill.
  • Page 25 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the latch pin.

  • Page 26: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 27 With the help of a second person, carefully raise the Upright Base (97) as shown. Carefully pivot the Hood (105) off. Locate the Reed Switch (22) and the Magnet (19) on the left side of the Pulley (18). Turn the Pulley until the 3 mm Magnet is aligned with the Reed Switch.
  • Page 28 PROBLEM: The heart rate monitor does not function properly SOLUTION: a. If the heart rate monitor does not function properly, see CHEST PULSE SENSOR TROUBLE- SHOOTING on page 9. b. If the heart rate monitor still does not function properly, the battery should be changed.

  • Page 29: Conditioning Guidelines

    CONDITIONING GUIDELINES ergy. Only after the first few minutes does your body WARNING: begin to use stored fat calories for energy. If your goal Before beginning this is to burn fat, adjust the speed and incline of the tread- or any exercise program, consult your physi- mill until your heart rate is near the lowest number in cian.

  • Page 30: Part List

    PART LIST—Model No. PETL75136 R1204A To locate the parts listed below, see the EXPLODED DRAWING attached in the centre of this manual. Key No. Qty. Description Key No. Qty. Description Left Foot Rail Static Decal Foot Rail Screw 3/4” Tek Screw Isolator Bolt (Top) Belly Pan Clip Isolator Decal...
  • Page 31 Key No. Qty. Description Key No. Qty. Description Console Base Small Washer Console Back Pulley Bolt Ground Screw/Choke Screw Ferrite Box Key Clip Pulse Receiver Hood Splitter Optic Disk Console Motor Isolator Screw Controller Bracket Left Tray On/Off Switch CD Holder Circuit Breaker Right Tray 8”...
  • Page 32 EXPLODED DRAWING—Model No. PETL75136 R1204A...
  • Page 33 EXPLODED DRAWING—Model No. PETL75136 R1204A...

  • Page 34: Ordering Replacement Parts

    Fax: (44) 113 387 7125 To help us assist you, please be prepared to give the following information: • The MODEL NUMBER of the product (PETL75136) • The NAME of the product (PROFORM ® 760 AIR treadmill) • The SERIAL NUMBER of the product (see the front cover of this manual) •...
