ProForm 760 Crosstrainer Treadmill User Manual

English manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model No. PFTL79707.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are missing,
PLEASE DO NOT CONTACT
THE STORE; please contact
Customer Care.
IMPORTANT: You must note the
product model number and
serial number (see the drawing
above) before contacting us:
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading

Related Manuals for ProForm 760 Crosstrainer Treadmill

Summary of Contents for ProForm 760 Crosstrainer Treadmill

  • Page 1 Sat. 8 a.m.–4 p.m. MST ON THE WEB: www.proformservice.com CAUTION Visit our website at Read all precautions and instruc- tions in this manual before using www.proform.com this equipment. Save this manual new products, prizes, for future reference. fitness tips, and much more!

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at ac- tual size. PROFORM is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    12. To purchase a surge suppressor, see informed of all warnings and precautions. your local PROFORM dealer or call the tele- phone number on the front cover of this man- 3. Use the treadmill only as described.
  • Page 4 20. Never leave the treadmill unattended while it 24. Inspect and properly tighten all parts of the is running. Always remove the key, unplug treadmill regularly. the power cord, and switch the reset/off cir- DANGER: cuit breaker to the off position when the Always unplug the power treadmill is not in use.

  • Page 5: Before You Begin

    And when you’re not exercis- ing, the unique 760 CROSSTRAINER treadmill can be To avoid a registration fee for any service needed under warranty, you must register the treadmill at folded up, requiring less than half the floor space of www.proformservice.com/registration.

  • Page 6: Assembly

    ASSEMBLY To hire an authorized service technician to assemble the treadmill, call 1-800-445-2480. Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant.
  • Page 7 1. Make sure that the power cord is unplugged. With the help of a second person, carefully tip the treadmill onto its left side. Partially fold the Frame (56) so that the treadmill is more stable; Hole do not fully fold the Frame yet. Cut the tie securing the Upright Wire (38) to the Base (83).
  • Page 8 4. Set the Right Upright Spacer (79) on the Base (83). Be careful not to pinch the Upright Wire (38). With the help of a second person, hold a Bolt Spacer (80) inside the lower end of the Right Upright (78). Insert a 3/8" x 4 1/2" Bolt (6) with a 3/8"...
  • Page 9 7. Press a Front Handrail Endcap (97) into the Left Handrail (35). Attach the Front Handrail Endcap with a #8 x 3/4" Handrail Screw (15). Press an Upright Insert (110) into the Left Upright (74). Set the Left Handrail (35) on the Upright Insert.
  • Page 10 10. Set the Pulse Bar Bottom (95) on the Left Handrail (35) and the Right Handrail (33). Press the Pulse Bar Bottom forward as you tighten two #10 x 3/4" Screws (5) with two #10 Star Washers (10) into the Handrails. Long Tie Remove the long tie from the Upright Wire (38).
  • Page 11 13. Identify the Storage Latch (53). Remove the tie from the end of the tube. Make sure that the sleeve has been slid over the indicated hole and that the Latch Knob (54) is locked into the hole. Pull on the sleeve to make sure that it is locked into place.

  • Page 12: Operation And Adjustment

    Grounded Outlet Box the right). To purchase a surge suppressor, see Adapter your local PROFORM dealer or call the telephone Surge Suppressor number on the front cover of this manual and order part number 146148, or see your local electronics store.
  • Page 13 CONSOLE DIAGRAM Clip FEATURES OF THE CONSOLE In addition to the cross training workouts, the console features nine classic aerobic workouts. Each workout The revolutionary treadmill console offers a selection automatically controls the speed and incline of the of features designed to make your workouts more treadmill as it guides you through an effective workout.
  • Page 14 HOW TO TURN ON THE POWER 2. Select the manual mode. IMPORTANT: If the treadmill has been exposed to When the key is inserted, the manual mode will be cold temperatures, allow it to warm to room tem- selected. If you have selected a workout, reselect perature before turning on the power.
  • Page 15 4. Change the incline of the treadmill as desired. • The incline setting of the treadmill. To change the incline of the treadmill, press the • The approximate number of calories you have Incline increase and decrease buttons or one of burned.
  • Page 16 6. Measure your heart rate if desired. 7. Turn on the fan if desired. Note: If you use the handgrip pulse sensor and Press the Fan button repeatedly to turn on or off the optional chest pulse sensor at the same the fan.
  • Page 17 HOW TO USE A CROSS TRAINING WORKOUT you will be, continue to select that user each time you use the treadmill. After you have selected user 1. Insert the key into the console. 1 or user 2, your user number will be saved in memory for the remainder of the workout session.
  • Page 18 4. Perform the first strength exercise when 6. Select a display mode and monitor your prompted. progress with the displays. When the first strength exercise segment begins, As you walk or run on the treadmill, the display can the walking belt will slow to a stop and the name of show the following workout information: the first strength exercise will appear in the left dis- play.
  • Page 19 HOW TO USE A CLASSIC AEROBIC WORKOUT During the workout, the profile will show your 1. Insert the key into the console. progress. The flashing segment of the profile Current Segment See HOW TO TURN ON THE POWER on page represents the current segment of the workout.
  • Page 20 HOW TO USE THE iFIT MONTHLY CHALLENGE ton below YES in the left display. Press the buttons below the right display to move the cursor. Press 1. Insert the key into the console. the Enter button to select an item. Press the but- tons below the right display to change the date or See HOW TO TURN ON THE POWER on page time.
  • Page 21 HOW TO REVIEW YOUR MONTHLY CHALLENGE THE INFORMATION MODE The console features an information mode that allows Note: The monthly challenge log will store information you to select miles or kilometers as the unit of mea- for up to five months. surement and to turn on and turn off the display demo mode.
  • Page 22 THE OPTIONAL CHEST PULSE SENSOR If you purchase the optional chest pulse sensor, follow the steps below to install the receiver in- cluded with the chest pulse sensor. An optional chest pulse sensor offers hands-free oper- ation as it tracks your heart rate during your workouts. To purchase the optional chest pulse sensor, call 1.

  • Page 23: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If you do not do this, you may damage the treadmill when you fold it. Remove the key and unplug the power cord.
  • Page 24 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand. Pull the latch knob to the left and hold it. It may be neces- sary to push the frame forward as you pull the knob to the left.

  • Page 25: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 26 Remove the three #8 x 3/4" Screws (12) and care- fully pivot the Hood (61) off. Locate the Reed Switch (71) and the Magnet (50) on the left side of the Pulley (51). Turn the Pulley until the Magnet is aligned with the Reed Switch. Make sure that the gap between the Magnet and 1/8 in.
  • Page 27 PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt is off-center, first remove the key and UNPLUG THE POWER CORD. If the walking belt has shifted to the left, use the hex key to turn the left rear roller bolt clockwise 1/2 of a turn;...

  • Page 28: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 29 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 30: Part List

    PART LIST—Model No. PFTL79707.0 R0408A To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Front Roller/Pulley #8 x 1" Tek Screw 15 1/2"...
  • Page 31 Key No. Qty. Description Key No. Qty. Description Pulse Bar Ground Wire Latch Endcap Right Top Pulse Plate Upright Insert Filter Wire 3/8" x 2" Shoulder Bolt Lift Motor Spacer – 6" Blue Wire, 2F #8 x 2" Screw – User’s Manual Key Board –...

  • Page 32: Exploded Drawing

    EXPLODED DRAWING A—Model No. PFTL79707.0 R0408A...
  • Page 33 EXPLODED DRAWING B—Model No. PFTL79707.0 R0408A...
  • Page 34 EXPLODED DRAWING C—Model No. PFTL79707.0 R0408A...
  • Page 35 EXPLODED DRAWING D—Model No. PFTL79707.0 R0408A...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
