What's in the box?
Battery
cover
• If any items are missing or damaged, contact our Customer Care Line
immediately. Never use damaged products!
• Need help? Get answers 24/7 at our website: www.uniden.com.
If You...
have a question or problem
need a replacement part or an
accessory
need special assistance due to
a disability
* During regular business hours, Central Standard Time; see our website for de-
tailed business hours.
© 2013 Uniden America Corp.
Ft. Worth, Texas
D1760 Series User's Guide
D1760 base
with cordless
handset
Not pictured:
• Rechargeable
battery (BT-1021)
• AC adapter (PS-0035)
• Telephone cord
If you purchased
model number:
D1760
D1760-2
D1760-11
D1760-12
* If the model number ends in R,
your package includes a DRX100
range extender. Refer to the
DRX100 owner's manual for details.
Contact Uniden's...
Customer Care Line*
Parts Department*
Accessibility Help Line
You will also find:
Accessory handset
and charger
Not pictured:
• Rechargeable
battery (BT-1021)
• Battery cover
• AC adapter
(PS-0035)
You should
Phone Number
817-858-2929 or
800-297-1023
800-554-3988
800-874-9314
(voice or TTY)
Printed in Vietnam
U01UN546BZZ(0)
have:
None
1 of each
10 of each
11 of each
Advertisement
Table of Contents
Related Manuals for Uniden D1760 Series
Summary of Contents for Uniden D1760 Series
- Page 1 D1760 Series User's Guide You will also find: What's in the box? Accessory handset D1760 base and charger with cordless handset Not pictured: • Rechargeable battery (BT-1021) • Battery cover • AC adapter (PS-0035) You should If you purchased model number:...
-
Page 2: Table Of Contents
What’s in the manual? Getting Started ........ 3 Important Information ....14 Installing Your Phone .........3 Solving Problems ........14 Getting to Know Your Phone ....4 Resetting Handsets ........16 Using the Handset Menu ......6 Registering Handsets ......16 Adapter and Battery Information ..16 Using Your Phone ...... -
Page 3: Getting Started
GETTING STARTED Installing Your Phone Connect the Telephone Cord Use the telephone cord to connect Charge the Battery the jack on the base to a TEL LINE 1. Unpack all handsets, standard telephone wall jack. battery Test the Connection packs, and battery 1. Pick up the handset and press covers. If . The handset sounds a dial Talk you need to tone, and the display shows Talk. remove a – If you don't hear a dial tone or cover, press in on the notch and the display says Check Tel Line, slide the cover down and off. -
Page 4: Getting To Know Your Phone
Getting to Know Your Phone Parts of the Base Find Charging Handset Contacts Key (icon) What it does • In standby: page all handsets. Find hs Parts of the Handset PHONEBOOK SPEAKER MENU/SELECT TALK/FLASH DOWN Twelve-key dial pad REDIAL/PAUSE INTERCOM/CLEAR Microphone MESSAGE/MUTE Charging... - Page 5 Key (icon) What it does • In standby or during a call: open the phonebook. PhonEbook • In the menu: go back to the previous screen. • When entering text: move the cursor to the left. ) • Switch a normal call to the speakerphone (and back). sPEakEr •...
-
Page 6: Using The Handset Menu
Reading the Display Status The table shows the possible icons status icons & what they mean. Since the icons appear based Current call info on what the phone is doing, you won't see all the icons at Time & the same time. record date status Icon What it means The signal from the base is 1) strong or 2) weak. The ringer is turned off and will not ring for new calls. The speakerphone is on. - Page 7 Handset Setup Menu You can change these settings separately for each handset. Turn on T-coil mode to reduce noise on hearing aids T-coil equipped with a telecoil (T-coil) feature. T-coil mode shortens talk time, so keep your battery fully charged. Choose this handset's ring tone. As you highlight each Ringer Tones ring tone, the phone plays a sample.
-
Page 8: Using Your Phone
Entering Text on Your Phone • Use the 12-key dial pad anytime you want to enter text into your phone (a name in the phonebook, the handset banner, etc.). • If two letters in a row use the same key, enter the first letter; wait for the cursor to move to the next space and enter the second letter. To... Press... move the cursor left PhonEbook move the cursor right erase the character at the cursor inTErcoM/clEar erase the entire entry and hold inTErcoM/clEar enter a blank space switch between upper and lower case letters rotate through the punctuation and symbols USING YOUR PHONE... - Page 9 Assigning a Speed Dial Number You can assign a speed dial number to a phonebook entry when you create that entry for the first time (or when you edit it). Press and PhonEbook select Create New. As you enter the phonebook number, one of the options you will see is to assign a speed dial number to that phonebook entry. You can assign up to 10 speed dials, 0 - 9. Finding a Lost Handset With the phone in standby, press on the base. All handsets beep for Find hs 1 minute; to cancel, press again or press any handset key. Find hs Changing the Volume To change the... When... Press... you are listening to that to increase earpiece or speaker earpiece or speaker (playing the volume.
-
Page 10: Using The Phonebook
To… Press... dial the Talk/Flash sPEakEr. highlighted (If the number is a toll call but there is no 1 at the number beginning, press to add 1 before dialing.) close the lists PhonEbook For individual record options, highlight a number and press MEnu/sElEcT Delete Entry Erase the number from the list. Add the number to the phonebook. -
Page 11: Using Special Features
Adding Phonebook Entries With the phone in standby, open the phonebook. Press and MEnu/sElEcT select Create New. Enter a name, number, and then assign a speed dial number and a personal ring if desired. • Enter the phone number (up to 20 digits) exactly as you would dial it. • If you need the phone to wait before sending the next set of digits, press to insert a 2-second pause. You can insert multiple pauses, rEdial/PausE but each one counts as a digit (you’ll see P in the display). Deleting All the Phonebook Entries With the phone in standby, open the phonebook. Press and MEnu/sElEcT select Delete All. When the phone prompts you to confirm, select Yes. USING SPECIAL FEATURES Silent Mode You can silence the ringers on the base and all handsets for a specific period of time. # on any handset. The phone 1. With the phone in standby, press and hold prompts you to select the number of hours (1 - 9 or Always On) that you want it to stay in silent mode. - Page 12 • If a handset was ever registered to a base, you must reset it before it can register to a new base; see p. 16, or see the accessory handset manual. Conference Calling • When an outside call comes in, two handsets can join in a conference call with the outside caller. • To join a call that’s already in progress, just press or Talk/Flash sPEakEr • To leave the conference call, hang up normally; the other handset remains connected to the call. Call Transfer To... Press..The phone puts the call on hold and inTErcoM/clEar prompts you to select the handset you want to page. transfer a call When the other handset accepts the call, you'll be disconnected (press...
-
Page 13: Chain Dialing
To... Press... cancel a page answer a page inTErcoM/clEar Talk/Flash end an intercom call . Both handsets return to standby. Chain Dialing If you often have to enter a series of digits or a code number during a call, you can save that code number to a phonebook entry and use the phonebook to send the code number. 1. Enter the code number (up to 20 digits) into the phonebook just like a regular phonebook entry. Be sure to enter the code number into the phonebook exactly as you would enter it during a call. 2. When you hear the prompt that tells you to enter the number, open the phonebook and find the entry that contains your code number. 3. Press to send the code. If you change your mind, just close MEnu/sElEcT the phonebook. Voice Message Notification If you subscribe to a voice mail service, your phone displays the voice mail icon ( ) when you have a new message. This feature supports... -
Page 14: Important Information
4. To access your provider’s voice mail service now, press MEssagE/MuTE The system will dial the voice mail service and you can enter your security code manually when prompted. Editing Your Voice Mail Number You can add your voice mail security code to the voice mail number string. , then scroll to Global Setup/Edit Voice Mail. 1. Press MEnu/sElEcT 2. Enter your voice mail number again, then press twice to rEdial/PausE enter 2 2-second pauses. Next, enter your security code. 3. Press when you are finished. The system displays DONE! MEnu/sElEcT 4. To access your provider’s voice mail service now, just press MEssagE/ . The system will dial the access number, wait 4 seconds, and then MuTE it will dial the security code. IMPORTANT INFORMATION Solving Problems If you have any trouble with your phone, check this section first. If you need help, call our Customer Care Line listed on the front cover. General problems Possible solutions •... -
Page 15: Liquid Damage
Audio issues Possible solutions • Check for interference from appliances (microwave ovens, TVs, etc.) or wireless devices (baby monitors, WiFi equipment, etc.). Move the handset or base away There’s a lot of from the interference source. noise or static on •... -
Page 16: Resetting Handsets
Talk/Flash owner's manual. Using another charger 3. If you don’t hear a dial tone or the may damage the battery or cause it to display says Registration Failed, explode. charge the battery completely, then x As part of our commitment to try again. protecting our Adapter and Battery environment and Information conserving natural resources, Uniden AC adapter voluntarily participates in an RBRC® industry Part number PS-0035 program to collect and Input voltage 120V AC, 60 Hz recycle used Ni-MH batteries within Output voltage 8V AC @ 300mA the United States. Please call 1-800-8-BATTERY for information on x Use only the supplied AC adapters. Ni-MH battery recycling in your area. x Use the proper adapter for the base &... -
Page 17: Compliance Information
California to cause birth US:AAAEQ##TXXXX. The digits rep- defects or other reproductive resented by ## are the REN without a harm. Wash hands after handling. decimal point (e.g., 03 is a REN of 0.3). Uniden works to reduce lead If this equipment causes harm to the telephone network, the telephone com- content in our products & pany will notify you in advance that accessories. temporary discontinuance of service Compliance Information may be required. But if advance notice... -
Page 18: Fcc Rf Exposure Information
able your alarm equipment. If you have off and on, the user is encouraged to questions about what will disable alarm try to correct the interference by one or equipment, contact your telephone more of the following measures: company or a qualified installer. x Reorient or relocate the receiving Any changes or modifications to this antenna. product not expressly approved by the x Increase the separation between the manufacturer or other party respon- equipment and receiver. sible for compliance could void your x Connect the equipment into an outlet authority to operate this product. on a circuit different from that to which the receiver is connected. NOTICE: According to telephone com- pany reports, AC electrical surges, typi- x Consult the dealer or an experienced cally resulting from lightning strikes, radio/TV technician for help. are very destructive to telephone FCC RF Exposure Information equipment connected to AC power This product complies with FCC radia- sources. To minimize damage from tion exposure limits under the follow- these types of surges, a surge arrestor is ing conditions: recommended. x The base must be placed to allow a FCC Part 15 Information minimum of 20 cm (8 inches) between... -
Page 19: 1-Year Limited Warranty
1-Year Limited Warranty indicating all functions except Evidence of original purchase is charging have been disabled. To return to normal operation, required for warranty service. cycle the power for the base and WARRANTOR: UNIDEN AMERICA remove and reinstall the handset CORPORATION ("Uniden") battery ELEMENTS OF WARRANTY: Uniden Industry Canada (I.C.) Notice warrants, for one year, to the original... - Page 20 Minimum drawing size (with clear space) = 0.555 in (14.1 mm) wide OF LAW, INCLUDING, BUT NOT 4700 Amon Carter Blvd. LIMITED TO ANY IMPLIED WAR- Fort Worth, TX 76155 RANTIES OF MERCHANTABILITY As an Energy Star® Partner, OR FITNESS FOR A PARTICULAR Uniden has determined PURPOSE. THIS WARRANTY DOES that this product meets the NOT COVER OR PROVIDE FOR THE Energy Star® guidelines for REIMBURSEMENT OR PAYMENT energy efficiency. Energy OF INCIDENTAL OR CONSEQUEN- Star® is a U.S. registered mark. TIAL DAMAGES. Some states do not allow this exclusion or limitation of x Uniden® is a registered trademark of incidental or consequential damages Uniden America Corporation. so the above limitation or exclusion x The pictures in this manual are for may not apply to you. example only. Your phone may not LEGAL REMEDIES: This warranty look exactly like the pictures. gives you specific legal rights, and you may also have other rights which vary from state to state. This warranty is void outside the United States of America and Canada. PROCEDURE FOR OBTAINING PERFORMANCE OF WARRANTY: If, after following the instructions in the owner's manual you are certain that the Product is defective, pack...
