Summary of Contents for Chauvet Scorpion
- Page 1 LASER LIGHT AVOID DIRECT EYE EXPOSURE CLASS 3R LASER PRODUCT CLASSIFIED PER EN/IEC 60825-1:2007 Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
-
Page 2: Table Of Contents
Toll free: (800) 762-1084 Voice: +44 (0)1773 511115 Technical Support Fax: +44 (0)1773 511110 Voice: (954) 577-4455 (Press 4) Email: uktech@chauvetlighting.com Fax: (954) 756-8015 World Wide Web: www.chauvetlighting.com World Wide Web: www.chauvetlighting.co.uk Scorpion™ Storm MG User Manual Rev. 7 06/14/2013... -
Page 3: Before You Begin
If the container or the material inside the container (this product and any other accessory included) appears damaged from shipping, or shows signs of mishandling, notify the carrier immediately, not CHAUVET®, upon receipt of the damaged merchandise. Failure to do so in a timely manner may invalidate your claim with the carrier. -
Page 4: Safety Instructions
In the unlikely event your unit may require service, please contact the dealer nearest to you. · Avoid direct eye contact with laser light. Never intentionally expose your eyes or others to direct laser light. Scorpion™ Storm MG User Manual Rev. 7 06/14/2013... -
Page 5: Non Interlocked Housing Warning
The legal requirements for using laser entertainment products vary from country to country. The user is responsible for the legal requirements at the location/country of use. · Always use appropriate lighting safety cables when hanging lights and effects overhead. Scorpion™ Storm MG User Manual Rev. 7 06/14/2013... -
Page 6: Laser Safety Label Reproduction
Laser Safety Label Reproduction EXPLANATORY, MANUFACTURER’S ID & CERTIFICATION LABEL LASER HAZARD WARNING LABEL LASER APERTURE LABEL NON INTERLOCKED HOUSING LABEL Scorpion™ Storm MG User Manual Rev. 7 06/14/2013... -
Page 7: Laser Emission Data
FLPPS via the terms of Laser Notice No. 50 dated June 24, 2007. This laser device is classified 3R. (Class 3R is the international equivalent of US Class IIIa). No maintenance is required to keep this product in compliance with laser performance standards. Scorpion™ Storm MG User Manual Rev. 7 06/14/2013... -
Page 8: Introduction
2. I NTRODUCTION Product Overview Hanging bracket Power LED Bracket adjustment knob (1 of 2) Audio LED Laser Aperture Scorpion™ Storm MG User Manual Rev. 7 06/14/2013... -
Page 9: Product Dimensions
Product Dimensions Scorpion™ Storm MG User Manual Rev. 7 06/14/2013... -
Page 10: Setup
Safety cables must always be used. Note! · Never mount in places where the product will be exposed Clamp is sold separately. to rain, high humidity, extreme temperature changes or restricted ventilation. Scorpion™ Storm MG User Manual Rev. 7 06/14/2013... -
Page 11: Proper Usage
Proper Usage This product is for overhead mounting only. For safety purposes, CHAUVET® recommends mounting your lighting effect products on steady elevated platforms or sturdy overhead supports using suitable hanging clamps. In all cases, you must use safety cables. You can obtain appropriate mounting hardware from your lighting vendor. -
Page 12: Operating Instructions
Use the <UP> and <DOWN> buttons to navigate the menu map and menu options. Press the <ENTER> button to access the menu function currently displayed or to enable a menu option. To return to the previous option or menu without changing the value, press the <MODE> button. Scorpion™ Storm MG User Manual Rev. 7 06/14/2013... -
Page 13: Menu Functions
· Laser responds to low frequencies picked up by the internal Sound microphone. · Use the sound knob to adjust the sensitivity of the microphone. · Sets the product into slave mode. Slave Scorpion™ Storm MG User Manual Rev. 7 06/14/2013... -
Page 14: General Troubleshooting
ü power the product and it will automatically enter into this mode If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support. Technical Support Address: Service Dept. 5200 NW 108 Avenue, Sunrise, FL 33351 (U.S.A.) -
Page 15: Appendix
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without an RMA # will be refused. Call CHAUVET and request RMA # prior to shipping the product. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 16: Technical Specifications
Coverage Angle ........................... 100° THERMAL Maximum ambient temperature ..................... 104°F (40°C) MASTER/SLAVE LINKING Cable type ..................male-to-male 1/8” (3.5mm) TRS cable ORDERING INFORMATION Scorpion™ Storm MG ................... SCORPIONSTORMMG WARRANTY INFORMATION Warranty ......................... 1-year limited warranty Scorpion™ Storm MG User Manual Rev. 7 06/14/2013...
