- Page 1 7/9/2008 C3-RS-601 PROFESSIONAL REMOTE CAR STARTER With Two Way data Port INSTALLATION MANUAL Compatible THIS PRODUCT IS DESIGNED FOR PROFESSIONAL INSTALLATION ONLY RS-603 REV A.
-
Page 2: Table Of Contents
7/9/2008 TABLE OF CONTENTS Installer Warning ………………………………………. System Wiring Diagram ………………………………. H1 - Main 6 Pin Heavy Gauge Harness …………….. H2 – 6 Pin Harness …………………………………… H3 – 8 White Connector Harness …………………… Installation Factory Immobilizer Systems…………… H4 – 2 Pin Blue connector ……………………….…… H5 –... -
Page 3: Installer Warning
7/9/2008 INTRODUCTION INSTALLER WARNINGS This Remote Starter System is designed to be installed on fuel-injected vehicles with an automatic transmission ONLY. Never install this remote starter on a manual transmission vehicle. This system must be installed and wired through a safety switch so it will not start in any forward or reverse gear. Some automatic transmission vehicles [mainly older GM vehicles with a purple starter wire] have a mechanical-type neutral safety switch instead of electrical safety switch. -
Page 4: System Wiring Diagram
7/9/2008 INSTALLATION DIAGRAM RS-603 REV A. -
Page 5: H1 - Main 6 Pin Heavy Gauge Harness
7/9/2008 WIRING Keep wiring away from moving engine parts, exhaust pipes and high-tension cable. Tape wires that pass through holes on the firewall to prevent fraying. Watch out for sharp edges that may damage wires and cause a short circuit. CAUTION: Do not connect the wire harness to the control module until all wiring to vehicle is complete. -
Page 6: H2 - 6 Pin Harness
7/9/2008 Connect the BROWN wire to the accessory wire in the vehicle that powers the climate control system. An accessory wire will show + 12 volts when the ignition switch is turned to the “ACCESSORY” or “ON” and “RUN” positions, and will show 0 Volts when the key is turned to the “OFF” and “START” or “CRANK” position. There will often be more than one accessory wire in the ignition harness. - Page 7 7/9/2008 The WHITE/BLACK wire provides an instant shutdown for the remote start, whenever it is grounded. Connect the wire to the hood pin switch previously installed. This wire must be routed though a grommet in the firewall and connected to the hood pin switch.
-
Page 8: Installation Factory Immobilizer Systems
7/9/2008 FACTORY SECURITY DISARM SIGNAL OUTPUT –(Factory Default Setting) -- This wire is designed to disarm a factory installed security system. This wire sends a negative (-) 1 second pulse upon a remote start and remote door unlocking. Some factory systems must be disarmed to allow remote starting. In most cases, this wire may be connected directly to the factory alarm disarm wire. -
Page 9: H4 - 2 Pin Blue Connector
7/9/2008 If the vehicle has the General Motor VATS system installed, you will need to by -pass the system while the vehicle is operating under the control of the Remote Start Unit. To do this: 1. Measure the resistance of the resistor pellet on the ignition key then select a resistor within 5% of the key’s va lue. 2. -
Page 10: H7- Serial Data Port Connection Rs-232 Port
H7 Flashing LED. Connect to LED Plug H8. RS232 C3 SERIAL TWO-WAY DATA PORT CONNECTION: This connector is to be used for Serial Data communications with I-Datalink modules by Auto Page only! DO NOT CONNECT THIS TO ANY OTHER WIRING! This connector will transmit digital codes to operate all functions of Autopage data modules. -
Page 11: Remote Transmitter Programming
7/9/2008 A. PROGRAMMING TRANSMITTER: Note: This remote start system will only retain the last 4 remote transmitters programmed. If the transmitter memory is exceeded, the security system will start deleting transmitters from memory in chronological order. PROGRAMMING THE REMOTE TRANSMITTER 1. -
Page 12: Alarm Feature "Iii" Programming
7/9/2008 FEATURE “III” PROGRAMMING: Turn the Ignition 'switch ‘ON/OFF’ 3 TIMES and stay in OFF position. 1. Push the Valet switch 3 times (holding in on the 3 push ) until three chirps with one long chirp is heard, then release the valet switch. -
Page 13: Rpm Learning
7/9/2008 ** This will be used when connected to an Autopage CI3 compatible Two-way data module that will recognize the tach signal from the vehicle. This signal will need to be learned in the same manner as the analog tachometer wire. If this learned value needs to be adjusted, use steps 7 and 8 of this programming table RPM LEARNING 1. -
Page 14: Shutdown Diagnostics
7/9/2008 SHUTDOWN DIAGNOSTICS The unit has the ability to report the cause of the last shutdown of the remote start system. Enter: Turn the Ignition 'switch to ‘ON position. Press the button on the transmitter. The LED will now report the last system shutdown by flashing for one minute in the following grouped patterns: Shutdown Mode Flashes (-) Safety Shutdown input (Hood) - Page 15 7/9/2008 3. Sitting in the vehicle, turn the ignition switch to “ON” or “RUN” position. But do not start the engine. 4. Step on the brake pedal and shift the gear selector into “DRIVE” (D). 5. Put your foot over the brake pedal but do not press down on it. Be ready to step on the brake to shut down the Remote Start Device.
-
Page 16: Notes
7/9/2008 than Park or Neutral while the key is in the ignition cylinder however, if the key is left in the ignition switch and the door is left opened, the added relay will be energized causing a 150mA drain on the battery. Method 2 will allow the safety required for the remote start unit and prevent the vehicle from starting while in any gear other than Park or Neutral while the key is in the ignition cylinder however, the original factory key in chime module will not alert the owner that the key has been left in the ignition switch. - Page 17 7/9/2008 It is recommended to have a minimal digital service plan on your cell phone Your RS-601 is C/3 compatible and will open your world to the true power of two way communication. Complete tracking and full cell phone functionality can be added to your system. For more information please visit your local authorized Autopage dealer or go to www.autopageusa.com RS-603 REV A.
