Step 4: Connect Scanner (cont.)
To the Hi-Speed USB cable
D. Connect one end of the
Hi-Speed USB cable to your
computer.
E. Connect the other end of the
Hi-Speed cable to the
scanner's USB port.
F. Press the power button at the front panel of
your scanner, and wait for the LEDs to stop
blinking and stay on steady.
The scanner will be detected by your system
automatically.
Position the Scan Material
Position Reflective Materials
To scan reflective materials such as photos: Raise
the scanner lid, and place the photo to be
scanned face down on the scanner glass surface.
Position the top end of the photo towards the
back of the scanner. Then, close the lid and
prepare to scan.
NOTE: Make sure the
Black Mat is
attached on the
scanner lid, and close
the scanner lid before
you launch
ScanWizard Pro.
Position Transparencies
To scan transparencies such as 35mm slides,
35mm filmstrips, 4" x 5" film, or medium format
up to 6 x 17-cm panoramic film: Use the EZ-Lock™
Film Holders or Film Alignment Ruler included with
your ScanMaker i800 Plus package.
See the "Using the
TMA" section in
The Black Mat
next page of this
comes
guide to position
preattached to
the transparent
the scanner lid.
films; or refer to the
ScanMaker i800
Plus Supplement for
details.
3
Power button
Remove the
Black Mat.
