HP Cisco Catalyst Blade Switch 3020 Release Note

HP Cisco Catalyst Blade Switch 3020 Release Note

Release notes for cisco catalyst blade switch 3020 for hp, cisco ios release 12.2(58)se and later
Hide thumbs Also See for Cisco Catalyst Blade Switch 3020:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Release Note
Release Notes for the Cisco Catalyst
Blade Switch 3020 for HP,
Cisco IOS Release 12.2(58)SE and Later
Revised April 23, 2011
Cisco IOS Release 12.2(58)SE images for all platforms were removed from Cisco.com because of a
Note
severe defect, CSCto62631. The solution for the defect is in Cisco IOS Release 12.2(58)SE1.
If you are using Enclosure Bay IP Addressing (EBIPA), you must upgrade the HP Onboard
Note
Administrator (OA) to firmware version 3.55 before you upgrade to Cisco IOS Release 12.2(58)SE or
later. If you do not upgrade the firmware, the HP OA will fail to assign an IP address to the Cisco Catalyst
Blade Switch 3020 module.
Cisco IOS Release 12.2(58)SE1 runs on the Cisco Catalyst Blade Switch 3020 for HP, referred to as the
switch.
If you wish to use Device Manager to upgrade the switch from Cisco IOS Release 12.2(35)SE through
Cisco IOS Release 12.2(40)SE1 (the LAN Base image) to Cisco IOS Release 12.2(50)SE or later (the IP
base image), you must first upgrade to Cisco IOS Release 12.2(40)SE2.
These release notes include important information about Cisco IOS Release 12.2(58)SE1 and any
limitations, restrictions, and caveats that apply to them. Verify that these release notes are correct for
your switch:
If you are installing a new switch, see the Cisco IOS release label on the switch packaging.
•
If your switch is on, use the show version privileged EXEC command. See the
•
Software Version and Feature Set" section on page
If you are upgrading to a new release, see the software upgrade filename for the software version.
•
See the
"Deciding Which Files to Use" section on page
For the complete list of Cisco Catalyst Blade Switch 3020 for HP documentation, see the
Documentation" section on page
You can download the switch software from this site (registered Cisco.com users with a login password):
Americas Headquarters:
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
© 2011–2012 Cisco Systems, Inc. All rights reserved.
3.
21.
"Finding the
3.
"Related

Advertisement

Table of Contents
loading

Related Manuals for HP Cisco Catalyst Blade Switch 3020

Summary of Contents for HP Cisco Catalyst Blade Switch 3020

  • Page 1 If you do not upgrade the firmware, the HP OA will fail to assign an IP address to the Cisco Catalyst Blade Switch 3020 module. Cisco IOS Release 12.2(58)SE1 runs on the Cisco Catalyst Blade Switch 3020 for HP, referred to as the switch.
  • Page 2 Cisco IOS Release 12.2(35)SE Device Manager System Requirements • “Hardware Requirements” section on page 3 • “Software Requirements” section on page 3 Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...

  • Page 3: Upgrading The Switch Software

    You must use the combined tar file to upgrade the switch through the device manager. To upgrade the switch through the command-line interface (CLI), use the tar file and the archive download-sw privileged EXEC command. Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...
  • Page 4 “Basic File Transfer Services Commands” section of the Cisco IOS Configuration Fundamentals Command Reference, Release 12.2 at this URL: http://www.cisco.com/en/US/docs/ios/fundamentals/command/reference/cf_t1.html Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...
  • Page 5 For //location, specify the IP address of the TFTP server. For /directory/image-name.tar, specify the directory (optional) and the image to download. Directory and image names are case sensitive. Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...

  • Page 6: Installation Notes

    VRRP routers on a LAN, allowing multiple routers on a multiaccess link to utilize the same virtual IP address. Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...

  • Page 7: Limitations And Restrictions

    The workaround is to configure the port for 10 Mp/s and half duplex or to connect a hub or a nonaffected device to the switch. (CSCed39091) Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...
  • Page 8 When the rate of received DHCP requests exceeds 2,000 packets per minute for a long time, the • response time might be slow when you are using the console. Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...
  • Page 9 IGMP snooping forwarding table. Use one of these workarounds: Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...
  • Page 10 Cisco Discovery Protocol (CDP), VLAN Trunking Protocol (VTP), and Port Aggregation Protocol • (PAgP) packets received from a SPAN source are not sent to the destination interfaces of a local SPAN session. Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...
  • Page 11 When the physical UID LED of the switch is on, it is blue. However, when the image of this LED on the device manager Front Panel view is on, it is green. There is no workaround (CSCsd98457). Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...

  • Page 12: Important Notes

    From Microsoft Internet Explorer: Choose Tools > Internet Options. Click Settings in the Temporary Internet files area. From the Settings window, choose Automatically. Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...

  • Page 13: Open Caveats

    When you make port security changes on an interface, such as configuring aging time, violations, or aging type, error messages and tracebacks might appear. There is no workaround. Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...

  • Page 14: Resolved Caveats

    When you configure a switch to send messages to a syslog server in a VPN Routing and Forwarding (VRF) instance, the messages are not sent to the server. The workaround is to remove the VRF configuration. Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...
  • Page 15 The workaround is to use a different authentication mode (single, multidomain or multihost). CSCti78365 • The config.text.backup file is present after the switch is restored to the factory defaults. There is no workaround. Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...
  • Page 16 Neighbor discovery fails for IPv6 hosts connected to the switch when the IPv6 MLD snooping feature is enabled globally on the switch. Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...

  • Page 17: Documentation Updates

    Correction to the “Unsupported Commands” Chapter The “Miscellaneous” section of the “Unsupported Commands” chapter should include the logging discriminator global configuration command. Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...
  • Page 18 Protocol (IGMP) message type, the third [dec] denotes the number of packets, and the second [chars] represents the letter “s” to indicate more than one packet. Recommended Action No action is required. Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...
  • Page 19 MAC address of the client, the first [chars] is the earlier interface, and the second [chars] is the newer interface. No action is required. Recommended Action Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...
  • Page 20 MAC address associated with the IP address, and the second [enet] is the MAC address that triggered this message. Change the IP address of one of the two systems. Recommended Action Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...

  • Page 21: Related Documentation

    Related Documentation Updates to the Getting Started Guide This illustration in the Cisco Catalyst Blade Switch 3020 for HP Getting Started Guide has been updated: Figure 1 The Catalyst Blade Switch 3020 for HP S Y S T S T A T...

  • Page 22: Obtaining Documentation, Obtaining Support, And Security Guidelines

    Any use of actual IP addresses in illustrative content is unintentional and coincidental. Copyright © 2011–2012 Cisco Systems, Inc. All rights reserved. Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(58)SE and Later OL-24325-01...
