Genie GCL-GCX Product Manual

GCL-GCX
LIGHT-DUTY COUNTER DOOR OPERATOR
The GCL-GCX is designed for rolling counter doors
that have a limited-duty cycle requirement.
The GCX comes with advanced features and
is available in a fire-door version that raises
the bar in counter door operation.
UL325-2010 APPROVED
• Allows for monitored entrapment connections for
protection and momentary operation when used with
select photo eyes and/or edge-sensing devices.
• See back for approved list of monitored devices.
GCL-GCX Advantages
• Modular design with optional expansion boards for
timer to close*; and auxiliary output functionality.
• Worm gear primary drive reduction provides inherent
mechanical braking.
• Completely enclosed drive allows for mounting below
8 feet; maintains UL325 approval.
• Motor with built-in thermal protection.
• LCD display with intuitive setup menu. Provides real-time
status and troubleshooting assistance.
• Open/close/stop and setup keys included on control board.
Keeps all setup controls near the LCD display convenient
for set up.
• EZ Limit provides for push to set limits that remain
™
synchronized with door even during loss of power and
mechanical drops on fire-door versions.
*— Not available on fire-door version.
*—
www.GenieCompany.com/commercial
GCL-GCX operators are covered by the following U.S. patents: 8014966, 8113263
GENIE CommErCIaL opEraTors
®
Standard Features
• Limited-duty 4 cycles per hour rating.
• Max run timer automatically adjusts to up and down run time.
• Worm gear primary reduction.
• Delay on reverse.
• 16-character LCD display.
• UL325-2010 approved.
• 3-button control station.
• 2-year/20,000-cycle warranty.
• Programmable mid-stop.
• Pull cord release for emergency manual operation.
| 800.843.4084
