Genie GCL-GH Product Manual

GCL-GH
HEAVY-DUTY GEAR HEAD HOIST OPERATOR
The GCL-GH is designed for high or full-lift sectional
and rolling doors that have up to 60-cycle/hour
duty requirement. Advanced features and robust
mechanical design combine to provide a heavy-duty
operator that sets a new standard for productivity.
UL325-2010 APPROVED
• Allows for monitored entrapment connections for protection and
momentary operation when used with select photo eyes and/or
edge-sensing devices.
• See back for approved list of monitored devices.
GCL-GH Advantages
• MultiVolt - Order phase specific operator for the job and have the
™
ability to select the right voltage on the job site.
- Single Phase: 115/208/230 VAC
- Three Phase: 208/230/460 VAC
- 575VAC voltage models available separately
• Modular design with optional expansion boards for advanced
timer to close, and auxiliary output functionality.
• LCD display with intuitive setup menu. Provides real-time status
and trouble-shooting assistance.
• Internal receiver with the ability to individually add/delete up to
50 Intellicode I transmitters directly from the LCD display.
®
• EZ Limit provides for push to set limits that remain synchronized
™
with door even during long term loss of power.
• Open/close/stop and setup keys included on control board.
Keeps all controls near the LCD display convenient for set up.
www.GenieCompany.com/commercial
GCL-GH operators are covered by the following U.S. patents: 6737823, 8014966, 8113263
GENIE CommErCIAL opErATors
®
Standard Features
• EZ Limit electro-mechanical limits.
™
• MultiVolt voltage simplification.
™
• Max run timer automatically adjusts to up and down run time.
• Heavy-duty worm gearbox for primary reduction.
• Delay on reverse.
• 16-character LCD display.
• UL325-2010 approved.
• Advanced radio receiver displays and stores activation by transmitter ID
number on the LCD screen.
• 3-button control station.
• 2-year/20,000-cycle warranty.
• Programmable mid-stop.
• Emergency hoist for manual operation. Easily changed in field from left
to right hand.
• DC disc brake with progressive braking.
