- Page 1 MINI-EXTRACTOR Operating instructions (ENG) Read these instructions before using the machine. 86221950-H 120V MODELS 08/15/11 ONLY...
-
Page 2: Machine Data Label
Machine Data Label Warranty Registration Thank you for choosing our product. Warranty registration is quick and easy. Your registration will allow us to serve you better over the lifetime of the product. To register your product go to: http://warranty.karcherna.com/warrantyregistration.aspx 86221950 MINI-EXTRACTOR... -
Page 3: Table Of Contents
Table of Contents Machine Data Label ......2 Table of Contents ......3 How to Use This Manual . -
Page 4: How To Use This Manual
How to Use This Manual This manual contains the following sections: The PARTS LIST section contains assembled parts illustrations and corresponding parts list. The parts lists • HOW TO USE THIS MANUAL include a number of columns of information: • SAFETY REF - column refers to the reference number on •... -
Page 5: Safety
Safety IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precaution must always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE. To reduce the risk of fire, electric shock, or injury: Use only indoors. Do not use outdoors or expose to rain. Use only as described in this manual. - Page 6 Safety IMPORTANTES MESURES DE SÉCURITÉ L'utilisation d'un appareil électrique demande certaines précautions: LIRE TOUTES LES INSTRUCTIONS AVANT DE FAIRE FONCTIONNER (CET APPAREIL). Pour réduire les risques d'incendie, de chocs électriques, ou d blessures : N'utiliser cette machine qu'en intérieur. Ne jamais l'utiliser à l'extérieur ou dans la pluie. N'utiliser cette machine que comme décrit dans le présent manuel.
-
Page 7: Hazard Intensity Level
Safety The following symbols are used throughout this guide as indicated in their descriptions: HAZARD INTENSITY LEVEL There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR SAFETY. The level of hazard intensity is determined by the following definitions: WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death. - Page 8 LORS DE L'ENTRETIEN DE LA MACHINE : Éviter les parties amovibles. Ne pas porter de vêtements amples, tels que des vestes, des chemises ou des vêtements avec manches lors de l'utilisation de la machine. Utiliser les pièces détachées Windsor homologuées. 86221950 MINI-EXTRACTOR...
-
Page 9: Grounding Instructions
Safety Grounding Instructions THIS PRODUCT IS FOR COMMERCIAL USE ONLY. ELECTRICAL: In the USA this machine operates on a standard 15 amp 115V, 60 hz, A.C. power circuit. The amp, hertz, and voltage are listed on the data label found on each machine. -
Page 10: Operations
Operations Set-up and Operation 1. Upon removing your new mini-extractor from the box, loosen the latch at back end of the machine that secures the recovery tank to the solution tank. Remove the recovery tank from the solution tank. 2. Pour clean, hot water to the indicated fill line of the solution tank. - Page 11 Operations Operating vacuum with solution above the FULL To prevent possible disease hazard, before mark could draw water directly into the vac motor. attempting to clean bodily fluids spills, you must This will cause damage to the motor, therefore kill any viruses, germs or bacteria present in the voiding your warranty.
-
Page 12: Maintenance
Maintenance Daily Maintenance 3. Run a small amount of clean water through pump if chemicals were used. This will help insure the life Follow same procedure for Shut Down and Storage. of your pump. 4. Check the spray jet on the cleaning tool for full Periodic Maintenance spray pattern and inspect vac head for any 1. -
Page 13: Vacuum Motor Replacement
Maintenance Vacuum Motor Replacement 1. Turn off all switches and unplug machine. 2. Unlatch and remove recovery tank. 3. Unfasten screws holding vacuum motor retainer to vacuum motor housing 4. Lift vacuum motor from vacuum motor housing. Locate the vacuum motor wires and disconnect at the connector. -
Page 14: Troubleshooting
Maintenance Troubleshooting PROBLEM CAUSE SOLUTION Little or no solution flow Clogged spray jet on cleaning tool Remove and clean jets Faulty pump Check and replace pump Incorrectly attached solution hose Ensure solution hose coupler is securely attached to the coupler on the solution tank Loss of vacuum/Solution Incorrectly attached vacuum hose Ensure Vacuum hose is pushed completely... - Page 15 Parts PARTS 86221950 MINI-EXTRACTOR...
-
Page 16: Extractor
Extractor 86226140 PRV NO. 880434 (REF) 86226130 PRV NO. 880433 (REF) 230V MODELS ONLY PART OF ITEM 16 PART OF PUMP ITEM 40 MOUNTING SURFACE DETAIL 'A' SEE DETAIL 'A' FOR INTERNAL SOLUTION TANK PARTS 86221950 MINI-EXTRACTOR... - Page 17 Extractor SERIAL PART NO. DESCRIPTION NOTES: NO. FROM 86225200 TANK, RECOVERY 86236520 FOAM, 4.00 OD X 1.0 THICK 86223730 SCREW, 8-32 X 1/2 FHMS BLK PLTD 86237440 GASKET, 4.06 X 2.50 X .38 86223440 RETAINER, VAC MOTOR 86217310 COVER, VAC MOTOR 86258440 VAC MOTOR, 120V 2ST LNP 86225500...
-
Page 18: Solution Pump
Solution Pump 86221950 MINI-EXTRACTOR... - Page 19 Solution Pump SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 86275710 SCREW, 10-32 X 3/8 PPH EX-SEMS 86068690 BRACKET, SOLENOID PUMP 86237530 GASKET, TUBE SEAL 86197590 HOSEBARB, 1/8 MPT 3/8 90° 86233150 CLAMP, HOSE 86240290 HOSE, 3/8ID WIREBOUND X 2.6” 86201110 PUMP, 110/120V 60HZ FLOJET 86201120 PUMP, 220/240V 50 HZ FLOJET...
-
Page 20: Wiring Diagram
Wiring Diagram CIRCUIT BREAKER SWITCH PUMP 100V/120V MACHINES CAPACITOR CIRCUIT BREAKER LOAD FILTER LINE SWITCH PUMP 230V MACHINES 86221950 MINI-EXTRACTOR... - Page 21 Wiring Diagram SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 86226310 WIRE, 14” GRN/18 76008 X 76008 86226100 WIRE, 13” BLK/14 76050 X 76029 86226110 WIRE, 13” WHT/14 76050 X 76059 86226120 WIRE, 9” BLK/14 76029 X 76029 86226130 WIRE, 9” BLK/14 76050 X 76029 86226140 WIRE, 9”...
- Page 22 Notes: 86221950 MINI-EXTRACTOR...
- Page 23 Options OPTIONS...
-
Page 24: Hand Tool
Hand Tool 86221950 MINI-EXTRACTOR... - Page 25 Hand Tool SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 86219340 HOUSING, HANDTOOL SPOTTER 86225670 VALVE ASM, SPOTTER OKA 86219020 HOSE ASM, VAC/SOLUTION 86200810 NIPPLE, 1/8 FPT QD FEM BRASS 86219570 JET, ASM W/O RING 86223100 PLATE, RETAINER W/HARDWARE 86221910 MANIFOLD, SPOTTER 86218000 FTTG, 1/8MPT X 3/16 COMP ENTIRE ASSEMBLY...
-
Page 26: Mini Cart
Mini Cart 86221950 MINI-EXTRACTOR... - Page 27 Mini Cart SERIAL PART NO. QTY. DESCRIPTION NOTES: NO.FROM 86222950 PLATE, WELDMENT 86259770 WHEEL, 5"D X 1" X .5" ID GRY 86137280 WASHER, M8 FLAT DIN125A PLT 86136640 SCR, M8 X 20 HHMS PLTD ENTIRE ASSEMBLY 86222030 MINI CART AS KIT 86221950 MINI-EXTRACTOR...
-
Page 28: Cart
Cart 86221950 MINI-EXTRACTOR... - Page 29 Cart SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 86089270 TUBE, CART HANDLE 86273740 SCREW, 1/4-20 X 1.5 TAP PLTD. 86271380 NUT, 1/2 STAR LOCK PUSH-ON 86005700 NUT, 10-32 HEX W/ STAR WASHER 86259970 WHEEL, 8” GREY 86005680 NUT, 1/4-20 LOCK 86092130 CART BASE ASM, SPOTTER 86006590...
-
Page 30: Suggested Spare Parts
86258440 VAC MOTOR, 120V 2ST LNP 86225500 VAC MOTOR, 230V 2ST LNP 86201110 PUMP, 110/120 60HZ FLOJET 86201120 PUMP, 220/240V 50HZ FLOJET 86135320 BRUSH SET, 120V VAC, WINDSOR 120V MOTOR ONLY 86135330 BRUSH SET, 230V VAC, WINDSOR 230V MOTOR ONLY... -
Page 31: Serial Numbers
Serial Numbers REF. MODEL: SERIAL # 86221950 MINI-EXTRACTOR...
