STOP! PLEASE READ CAREFULLY.
CAST COMPONENTS ARE VERY FRAGILE.
USE EXTREME CARE WHEN HANDLING.
Your insert is very heavy and will require two or three people to move
it into position.
When handling cast parts, please handle with care as they can be damaged.
1) Open door to a 45° angle
2) Holding door fi rmly from top and bottom - lift door up and off to remove.
NOTE: Door is heavy.
NOTE: For Masonry installation make sure that the fi rebox is level with
the hearth using non-combustible materials and no more than 1/2 to 1
inch of the levelling bolt.
Regency CI1200 / CI1250 Wood Cast Insert

INSTALLING YOUR INSERT

3) Lift the unit up onto the Hearth and slide into the fi replace opening. Be sure
NOTE: You will be required to purchase either the standard or offset 6" di-
ameter (152mm) fl ue adaptor that is best suited for the specifi c installation.
List of Tools needed;
- Pull Rod (included with insert)
- 1/2" socket / ratchet
- 3/8 open face wrench
4) Install fl ex liner into existing chimney as per liner manufacturer's specifi ca-
5) Install the required fl ue adaptor onto the end of the fl ex liner. Secure the
to leave the unit out at least 3 to 4 inches in order to make the necessary
fl ue connections and to install the fan and faceplate.
Be sure to protect your hearth extension during the installation, ie.
with a heavy blanket.
tions. See diagram 1.
adaptor using 3 screws - 1 on the front, left and right side as shown in
diagram 2.
Alignment of the fl ue adaptor can be critical during the install, it is recom-
mended that the fl ex liner be left as compressed as possible. Before
inserting the unit the adaptor should hang, when level, slightly above the
required height.
Diagram 1
Diagram 2
Secure adaptor using 3 screws - 1 in the front
and 1 each on the left and right side.
INSTALLATION
Flex Liner
Flue Adaptor
